TP-Link TPL-202E Bedienungsanleitung

TPL-202E

TPL-202E2K

H/W: V1.1R

Quick Installation Guide

Table of Contents

Version 02.22.2008

English .....................................................................................................

Troubleshooting ........................................................................................

1. Before You Start

2. ....................................................................................

................................................................................

How to Install

System Requirements

Application

?TPL-202E

?Utility CD-ROM

?Quick Installation Guide

?1 x Cat.5 Ethernet Cable (1.8m/5.9ft)

Package Contents

1. Before You Start

English

?A Desktop or Laptop PC with Network Adapter Installed

?CPU: 300MHz or above / 800MHz or above (Windows Vista)

?Existing 10/100Mbps wired network when TPL-202E is used as a bridge

device

Memory: 256MB RAM or above / 512MB RAM or above (Windows Vista)

D-ROM drive

Software Requirements

?Windows 98SE/ME/2000/XP/Vista

Fast Ethernet Powerline

85Mbps Powerline

Fast Ethernet Adapter

(TPL-202E)

Workstation with

Fast Ethernet PCI Adapter

(TE100-PCIWN)

4-Port Cable/DSL

Broadband Router

(TW100-S4W1CA)

Internet

Cable/DSL

Modem

Electrical

Outlet

Electrical

Outlet

2. How to Install

English

Important! DO NOT install the TPL-202E until instructed to do so

Note:

1. DO NOT plug the TPL-202E into a power strip or surge protector.

2. In order for the TPL-202E to see each other, each unit must be on the same

circuit breaker.

3. A maximum of 16 TPL-202E can be networked.

1. Insert the Utility CD-ROM into

your computer's CD-ROM Drive

and then click Install Utility.

3. Copy down the 12 digit device

password for each TPL-202E.

For Windows Users

2. Follow the InstallShield Wizard

instructions and then click Finish.

Outlet

English

6. Then connect an Ethernet cable

from an available LAN port on your

router to your computer.

7. Plug the second TPL-202E into an

outlet where your remote PC or

network appliance is located.

5. Connect an Ethernet cable from

the TPL-202E to an available LAN

port on your router

(e.g. TEW-633GR).

4. Plug a TPL-202E into an

available power outlet.

8. Double-click the TRENDnet

Powerline Utility Icon on your

desktop.

English

12. Repeat steps 8-10 for additional

remote TPL-202E's.

9. Select the remote TPL-202E and

click Enter Password.

10. Enter the remote TPL-202E's 12-

digit password and click OK. See

step 3 to find the remote

TPL-202E's password.

11. Click OK.

Note: The remote TPL-202E refers to the TPL-202E that is connected to your

remote PC or network appliance.

Note: The default network name is HomePlug. If the network name of your

existing Powerline network is NOT HomePlug, you must change this in the

utility.

Outlet

English

15. Connect a CAT 5 cable from the

TPL-202E into your remote PC,

or network applicance.

Your installation is now complete.

For detailed information regarding the TPL-202E configuration and advanced

settings, please refer to the User's Guide included on the Utility CD-ROM or

TRENDnet's website at www.trendnet.com

14. Click OK.

13. Click the Privacy tab. If you

would like to change the

Private Network Name, enter the

desired Private Network Name,

then click Set All Devices.

Q1:

A1:

Q2:

A2:

Q3:

A3:

I inserted the TPL-202E CD-ROM into my computer's CD-ROM Drive and the

installation menu does not appear automatically. What should I do?

If the installation menu does not appear automatically, click Start, click Run,

and type D:\Autorun.exe where "D" in "D:\Autorun.exe" is the letter assigned to

your computer's CD-ROM Drive. And then click OK to start the installation.

I have verified that my Powerline device is connected to my workstation, but I

cannot detect other Powerline devices. What should I do?

First, verify that you are using Cat-5 Ethernet cables. Second, open up the

Powerline AV Utility and click scan. Third, verify the network name of your

Powerline network. Then click on the security link in the TRENDnet Powerline

Utility, type in the network name and click Save changes. Fourth, verify that the

power outlet the TPL-202E is plugged into is on the same electrical power

distribution and/or circuit breaker.

I can detect my Powerline devices on my Powerline network, but I cannot

connect to the Internet. What should I do?

First, make sure you are not connecting the device into a power strip or surge

protector. Second, make sure that your Router is connected to the internet. Third,

verify that the TCP/IP settings are set to Obtain an IP address automatically.

Troubleshooting

1. Go into the Control Panel and double-click the

Network Connections icon, and then right-click the

Local Area Connection icon and then click

Properties.

2. Click Internet Protocol (TCP/IP) and then click

Properties. Click on Obtain an IP automatically and

then click OK.

Q4:

A4:

Q5:

A5:

I tried changing the Private Network Name and applying it to all of my

TPL-202E devices, but “Some devices could not be added to your network” error

appears. I can no longer see any of the remote TPL-202Es. What should I do?

First, open up the TRENDnet Powerline Utility, click the Privacy tab, click Use

Default (Public Network) and then click Set Local Device Only. Second, make

sure to add each remote TPL-202E's password. See step 9 in Section 2 (How to

Install).

I have a HomePlug 1.0 or HomePlug turbo network. Can I use this with my

network?

The TPL-202E is backwards compatible with HomePlug 1.0 or HomePlug

turbo.

If you still encounter problems or have any questions regarding the TPL-202E, please

refer to the User's Guide included on the Utility CD-ROM or contact TRENDnet's

Technical Support Department.

Limited Warranty

- 3-Year Warranty

TRENDnet warrants its products against defects in material and workmanship, under

normal use and service, for the following lengths of time from the date of purchase.

TPL-202E

If a product does not operate as warranted above during the applicable warranty period,

TRENDnet shall, at its option and expense, repair the defective product or deliver to

customer an equivalent product to replace the defective item. All products that are

replaced will become the property of TRENDnet. Replacement products may be new or

reconditioned.

TRENDnet shall not be responsible for any software, firmware, information, or memory

data of customer contained in, stored on, or integrated with any products returned to

TRENDnet pursuant to any warranty.

There are no user serviceable parts inside the product. Do not remove or attempt to

service the product through any unauthorized service center. This warranty is voided if

(i) the product has been modified or repaired by any unauthorized service center, (ii) the

product was subject to accident, abuse, or improper use (iii) the product was subject to

conditions more severe than those specified in the manual.

Warranty service may be obtained by contacting TRENDnet office within the applicable

warranty period for a Return Material Authorization (RMA) number, accompanied by a

copy of the dated proof of the purchase. Products returned to TRENDnet must be pre-

authorized by TRENDnet with RMA number marked on the outside of the package, and
