Transcend 32MB4GB Bedienungsanleitung

32MB–4GB JetFlash™

User’s Manual

Table of Contents

Introduction

Package Contents .....................................................................................................1

Features .....................................................................................................................1

System Requirements...............................................................................................2

Driver Installation

Driver Installation for Windows 98/98SE .................................................................2

Driver Installation for Windows Me, 2000, and XP..................................................3

Driver Installation for Mac OS 9.0 or Later ..............................................................3

Driver Installation for Linux Kernel 2.4 or Later......................................................3

Uninstall the Win98 Driver..........................................................................3

How to Safely Unplug JetFlash

To Remove JetFlash in Windows 98/98SE ..............................................................4

To Remove JetFlash in Windows Me, 2000, and XP ...............................................4

To Remove JetFlash in Mac OS................................................................................4

To Remove JetFlash in Linux ...................................................................................4

Write-Protect Function .................................................................................5

Security Function

Partition Types...........................................................................................................5

Security Function for Windows 98/98SE, Me, 2000, and XP ..................................6

Access Data in Security Area ...................................................................................9

Log Out of Security Area ........................................................................................10

Change Password ................................................................................................... 11

If You Forget the Password ....................................................................................12

Boot-Up Function

System Requirements for Boot-Up Function ........................................................12

Boot-Up Function for Windows 98/98SE and Me..................................................12

Boot-Up Function for Windows XP ........................................................................14

Error Messages of Boot-Up Function ....................................................................18

Recovery Function .......................................................................................18

Uninstall the U-Storage Tool...................................................................21

Specifications ..................................................................................................22

Ordering Information...................................................................................22

JetFlash Limited Warranty

Introduction

Thank you very much for purchasing Transcend’s JetFlash™. This small device is designed

to expedite the exchange of huge amounts of data between any desktop or laptop computers

with a USB port. With higher storage capacity and a much faster data transfer rate than other

typical portable storage media, JetFlash can easily replace floppy diskettes and hard disks. In

addition, its mobility, strong data retention ability, and impressive appearance will provide you

with a brand-new data storage experience.

Package Contents

The JetFlash package includes the following items:

• JetFlash

• Label

• Neck Strap

• Driver CD

• USB Extension Cable

• Quick Installation Guide

Features

• Fully compatible with USB 2.0 specification;

• Easy Plug and Play installation;

• Driverless (Only Windows®98/98SE needs the enclosed driver);

• Powered via the USB port. No external power or battery needed;

• Write Protection: Write-protect switch provided;

• Security Function: Password protection provided;

• Boot-Up Function: Can make JetFlash bootable device;

• Recovery Function: Return JetFlash to its initial status;

• LED indicates the usage status of JetFlash.

System Requirements

Desktop or notebook computer with USB port

One of following operating systems:

• Windows® 98/98SE

• Windows® Me

• Windows® 2000

• Windows® XP

• Mac™ OS 9.0 or later

• Linux™ kernel 2.4 or later

Driver Installation

Driver Installation for Windows 98/98SE

1. Put the Driver CD into the CD-ROM drive (Auto-Run supported). Click the Win98 Driver

button.

2. Follow the on-screen instructions to complete driver installation.

3. Plug JetFlash into an available USB port. A new Removable Disk drive with a newly

assigned drive letter appears in the My Computer window.

Driver Installation for Windows Me, 2000, and XP

No driver is required. These Windows operating systems have built-in drivers to support

JetFlash. Simply plug JetFlash into an available USB port, and Windows will install the files

needed to use your device. A new Removable Disk drive with a newly assigned drive letter

appears in the My Computer window.

Driver Installation for Mac OS 9.0 or Later

No driver is required. Just plug JetFlash into an available USB port and your computer will

automatically detect it. A new Disk icon appears on the Desktop.

Driver Installation for Linux Kernel 2.4 or Later

No driver is required. Just plug JetFlash into the USB port and mount it.

Example: 1. Create directory for JetFlash first

mkdir /mnt/jetflash

2. Mount JetFlash

mount –a –t msdos /dev/sda1 /mnt/jetflash

Uninstall the Win98 Driver

1. Click the button on the task bar and select Programs > U-Storage Driver >

Uninstall U-Storage.

2. Follow the on-screen instructions to uninstall the Windows 98/98SE driver.

Before removing JetFlash, please make sure the LED is steady and not flashing!

If you remove JetFlash while the LED is flashing, unpredictable damage to the files

and/or JetFlash may occur due to a write cache issue.

How to Safely Unplug JetFlash

To Remove JetFlash in Windows 98/98SE

Unplug JetFlash from your system directly when data are not transferring.

To Remove JetFlash in Windows Me, 2000, and XP

1. Click the icon on the system tray.

2. The Safely Remove Hardware pop-up menu appears. Click to continue.

3. Follow the on-screen instructions to complete the procedure.

4. The Safe To Remove Hardware message balloon appears. JetFlash is now ready to be

unplugged.

To Remove JetFlash in Mac OS

Drag and drop the Disk icon corresponding to JetFlash into the trashcan. Then unplug

JetFlash from the USB port.

To Remove JetFlash in Linux

Unmount the device from the Linux environment.

Example: umount /mnt/jetflash

Write-Protect Function

When the Write-Protect switch is set to Unlocked “ ”, you can write and read data to and

from JetFlash. When the Write-Protect switch is set to Locked “”, you can read data from

JetFlash, but you can’t write data to JetFlash or format it. Please set the switch to Unlocked

“” before attempting to format JetFlash.

Security Function

 The Security Function is not supported by Mac or Linux Operating Systems.

You must install the U-Storage Tool found on the Driver CD to enable the Security Function.

Before installing the U-Storage Tool, ensure that the Write-Protect switch is set to Unlocked

“” and carefully read the following sections.

Partition Types

U-Storage Tool can be used to partition JetFlash into two partition types. Before partitioning,

you need to understand the following terms and concepts.

Type 1: “Public Area Only”

This is the default partition type for JetFlash. It allows the entire volume of JetFlash memory

to be accessed by anyone. No secure data area is established.

“Public Area Only”

Type 2: “Public Area + Security Area”

JetFlash is partitioned into a single Logical Unit Number (LUN) identified device, which

contains a Public Area and a Security Area. Secure data can be established in the Security

Area, which is protected by password. Access to data in the Public Area is unrestricted.

“Public Area + Security Area”

Public Area

Security Area

Log Out / Log In

Public Area

 Only one data area can be seen at a time. You must “Log In” by entering the correct

password to access data in the Security Area. You switch from Security Area to Public

Area by using “Log Out.”

Security Function for Windows 98/98SE, Me, 2000, and XP

The default configuration of JetFlash is“Public Area Only”. To establish a Security Area

on JetFlash, follow the procedures below to partition JetFlash as “Public Area + Security

Area”.

1. Put the Driver CD into the CD-ROM drive (Auto-Run supported). Click the U-Storage Tool

button.

 When using Windows 2000 or XP, you must plug JetFlash into an available USB

port before clicking the U-Storage Tool button.

 When using Windows 98/98SE, the Win98 Driver will be uninstalled after clicking

the U-Storage Tool button. Follow the on-screen instructions to uninstall the Win98

Driver.

2. Follow the on-screen instructions to complete the U-Storage Tool installation.

3. Plug JetFlash into an available USB port of your computer. A or icon will appear

on the Windows system tray.

 If a or icon does not appear, remove JetFlash and plug it in again.

 If a icon appears in the Windows system tray, follow the steps below to reinstall

the Driver for JetFlash.

i. Click the button on the task bar and select Programs >

U-Storage > U-Storage Driver Install.

ii. Follow the on-screen instructions to reinstall the driver for JetFlash.

4. Backup the data on your JetFlash. Make sure the Write-Protect switch is set to the

position.

5. Double-click on or in the system tray. The U-Storage window appears.

6. Select the partition type you need.

a. To partition your JetFlash to the default type, i.e., “Public Area Only”, select

Public Area Only and click OK.

b. To partition your JetFlash to“Public Area + Security Area”, select Public Area

+ Security Area and click OK. The following window appears.

i. Drag the horizontal slider to set the memory sizes to be apportioned to

the Public Area and Security Area.

ii. Key in a New Password.(Maximum size for password is 8 characters.)

iii. Key in a Password Hint, if you want to set up a reminder for your new

password.

iv. Click OK.

7. The Confirmation window appears to remind you to back up all the data on your

JetFlash. Click OK to continue or Cancel to stop.

8. Once the partition is finished, the Resize information window appears. Click OK.
