JetFlash™

User’s Manual

(Version 2.1)

Table of Contents

Introduction................................................................................................... 2

Package Contents.................................................................................................................... 2

Features.................................................................................................................................... 2

System Requirements.............................................................................................................2

Driver Installation.......................................................................................... 3

Driver Installation for Windows®98SE................................................................................... 3

Driver Installation for Windows®Me, 2000, XP and Vista™.................................................. 3

Driver Installation for Mac™OS 9.0, or Later......................................................................... 3

Driver Installation for Linux™Kernel 2.4.2, or Later ............................................................. 3

Formatting the JetFlash™............................................................................ 4

Safely Remove the JetFlash™ from a Computer....................................... 5

Remove the JetFlash™in Windows®98SE............................................................................. 5

Remove the JetFlash™in Windows®Me, 2000, XP and Vista™............................................ 5

Remove the JetFlash™in Mac®OS 9.0, or Later and Linux®Kernel 2.4.2, or Later........... 5

JetFlash™ 150 Series................................................................................... 6

JetFlash™ 120 Series................................................................................... 7

JetFlash™ 110 Series................................................................................... 8

JetFlash™ 2A Series..................................................................................... 9

JetFlash™ V20 Series................................................................................. 10

JetFlash™ V30 Series..................................................................................11

JetFlash™ V60 Series................................................................................. 12

JetFlash™ 130 Series................................................................................. 13

JetFlash™ 160 Series................................................................................. 14

JetFlash™ 168 Series................................................................................. 15

JetFlash™ 210 Series................................................................................. 16

JetFlash™ V10 Series................................................................................. 17

JetFlash™ 180 Series................................................................................. 18

JetFlash™ V90 Series................................................................................. 19

JetFlash™ T2 Series................................................................................... 20

Introduction

Congratulations on purchasing Transcend’s JetFlash™. This tiny device allows you to exchange

huge amounts of data and information between it and any desktop or notebook computer with a

USB port. The JetFlash™plugs directly into your desktop or notebook computer, has a large

storage capacity and much faster data transfer rates, making it perfect for storing and transferring

your files, folders, documents, photos and other personal digital content. In addition, the

JetFlash™’s small convenient size, superior data retention and impressive appearance will provide

you with a brand-new data storage experience.

Package Contents

The JetFlash™package includes the following items:

z JetFlash™

z Quick Instruction Guide

Features

z Hi-Speed USB 2.0 compliant and USB 1.1 backwards compatible

z Easy Plug and Play installation

z Driverless (Only Windows®98SE needs driver)

z Powered via the USB port. No external power or battery needed

z Additional bundled software (helps you manage your data)

System Requirements

Desktop or notebook computer with a USB port and one of following operating systems:

z Windows®98SE

z Windows®Me

z Windows®2000

z Windows®XP

z Windows Vista™

z Mac™OS 9.0, or later

z Linux™Kernel 2.4.2, or later

Driver Installation

Driver Installation for Windows®98SE

Put the Driver CD into the CD-ROM (Auto-Run supported). Click the Win98SE Driver button. If the

product does not attach CD, you can download the Windows 98SE driver from Transcend’s website,

http://www.transcendusa.com/Support/DLCenter/Driver/JF_win98driver.zip.

Driver Installation for Windows®Me, 2000, XP and Vista™

No drivers are required. These Windows operating systems have built-in drivers to support the

JetFlash™. Simply plug the JetFlash™into an available USB port and Windows will install the files

needed to use your device. A new Removable Disk drive with a newly assigned drive letter will

appear in the My Computer window.

Driver Installation for Mac™OS 9.0, or Later

No drivers are required. Just plug the JetFlash™into an available USB port and your computer will

automatically detect it.

Driver Installation for Linux™Kernel 2.4.2, or Later

No drivers are required. Just plug the JetFlash™into the USB port and mount it.

Example: 1. First create a directory for the JetFlash™

mkdir /mnt/jetflash

2. Mount the JetFlash™

mount –a –t msdos /dev/sda1 /mnt/jetflashU

Formatting the JetFlash™

1. Plug the JetFlash™into a USB port and right-click on the removable disk.

2. Select “Format” in the drop down menu to format the JetFlash™.

WARNING! Formatting the Disk will erase all of the data on your JetFlash™

3. Click on the “Start” button to begin formatting the JetFlash™and follow the on-screen

instructions.
