TRENDnet TE-PCIWplus Bedienungsanleitung

TRENDnet's PCI Plug-and-Play (PnP) 32-bit Ethernet

adapters feature the latest PCI bus technology to process

network packets with minimal CPU utilization. The adapters

are recommended for workstations in a PC client/server

environment. Taking advan-tage of 32-bit bus width and

speed up to 33MHz, they are superior to all ISA adapters.

Equipped with both BNC and RJ-45 connec-tors they include

drivers for every popular network operating system. The PnP

and full-duplex functions increase the channel bandwidth

from 10Mbps to 20Mbps and avoid the performance-

degrading problem. TRENDnet adapters provide software

configuration of the jumperless Ethernet through a setup

program.

TE-PCIWplus

32-bit PCI Plug-and-Play Ethernet Adapter with BNC + RJ-45 Connectors

Comply with IEEE 802.3 10Base-2 and 10Base-T

industry standard

32-bit PCI local bus specification 2.0 compliant

Plug-and-Play (self-configuring), plugs into any

486/Pentium PCI bus slot

Supports PCI bus slave mode for low maintenance

cost

Compatible with all popular network operating

systems

Supports both 10Mbps (half-duplex) and 20Mbps

(full-duplex) operations

Easy-to-view LED indicators

5 Year Warranty

BENEFITSFEATURES

Easy Configuration:

Flexibility:

Performance:

Cost-Effectiveness:

Plug-and-Play function simply lets you

plug the adapter to connect to the

network.

With the full-duplex mode, PCs connect

to switch receiving and transmitting data

at the same time on a dedicated 20Mbps

bandwidth.

Provide the 32-bit high throughput data

transfer with the host - powerful

performance in very heavy traffic

environments.

With its low cost of ownership and

standard compliance, TRENDnet ISA

PnP adapters are the perfect choice for

cost-effective workgroup networking.

TE-PCIWplus (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

TE100-PCIWS: 32-bit PCI 10/100Mbps NWay Fast Ethernet Card

TE100-PCIWN: 32-bit PCI 10/100Mbps N-way Fast Ethernet Card

TE100-PCIWA: 32-bit PCI 10/100Mbps N-way Fast Ethernet Card

with ACPI Wake-on-LAN

TE-16PCTplus: 16-bit ISA PnP Ethernet Card with BNC + RJ-45

Connectors

TE-16PTplus: 16-bit ISA PnP Ethernet Card with RJ-45 Connector

TE-PCIWplus: 32-bit PCI PnP Ethernet Card with BNC + RJ-45

Connectors

TE-PCIWTplus: 32-bit PCI PnP Ethernet Card with RJ-45

Connector

NETWORKING SOLUTIONS

SPECIFICATIONS

TE-PCIWplus

32-bit PCI Plug-and-Play Ethernet Adapter with BNC + RJ-45 Connectors

TE-PCIWplus

32-bit PCI Plug-and-Play Ethernet Adapter with BNC + RJ-45 Connectors

Standards:

IEEE 802.3 10Base-2 and 10Base-T

On-board Connector:

RJ-45 and BNC

Data Bus Supported:

32-bit, PCI Local Bus Specification 2.0

IRQ’s Supported:

Assigned by the BIOS to a free IRQ (interrupt)

number

I/O Base Address:

Assigned by the BIOS to a free I/O address block

Network Drivers:

Novell IPX, ODI, NDIS, SCO Unix, NetWare 3.x,

4.x server, Windows 95/98/NT 3.x, 4.x/2000/XP,

Windows for Workgroups, LAN Manager,

LAN Server, Banyan VINES, PathWork,

Packet Driver, LANtastic, NetBIOS,

and many others

•

RAM Buffer:

16Kb

Boot ROM Size:

8Kb, 16Kb, and 32Kb

Dimensions:

5.20" x 3.27"

FCC Compliance:

FCC Class B

Power Consumption:

430mA at 5V

Operating Temperature:

0° to 55°C

Operating Humidity:

10 to 90%, non-condensing

•

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com

ORDERING INFORMATION
