TRENDnet TEW-624UB Bedienungsanleitung
TEW-624UB
Quick Installation Guide
Table of Contents
Table of Contents
Version 04.05.2006
English .....................................................................................................
Troubleshooting ........................................................................................
1
1
2
5
7
1. Before You Start
2. How to Install ....................................................................................
3. Wireless Configuration ......................................................................
................................................................................
System Requirements
Application
Package Contents
1. Before You Start
English
1
?TEW-624UB
?Quick Installation Guide
?Utility & Driver CD-ROM
?USB Extension Cable
?USB port: 1.1 or 2.0
?CD-ROM Drive
?CPU: 300MHz or above (XP/2000)/ 800MHz or above (Windows Vista)
?Memory: 256MB RAM or above (XP/2000)/ 512MB RAM or above
(Windows Vista)
?Windows Vista/XP/2000
HD
DATA
300Mbps, share multimedia throughout the house
300Mbps Wireless N
USB 2.0 Adapter
(TEW-624UB)
2. How to Install
English
2
1. Insert the Utility & Driver CD-
ROM into your computer's
CD-ROM Drive and then click
Install Utility.
2. Follow the InstallShield Wizard
instructions.
Important! DO NOT install the USB adapter in the computer until instructed to
do so.
Note: For Windows Vista, proceed to step 5.
3. Click Continue Anyway.
(Windows XP only).
4. Click Yes, I want to restart my
computer now. Then click Finish.
English
3
5. Connect the wireless adapter to an
available USB port on your
computer.
Note: For Windows Vista and 2000, drivers will install automatically. Please
proceed to Section 3.
Windows XP
6. Select No, not this time and then
click Next.
7. Click Install the software
automatically (Recommended)
and then click Next.
English
4
For detailed information regarding the TEW-624UB configuration and advanced
settings, please refer to the User's Guide included on the Utility & Driver
CD-ROM or TRENDnet's website at www.trendnet.com
Your installation is now complete.
9. Click Finish.
8. Click Continue Anyway.
English
5
1. On the bottom right-hand corner of
the screen, double-click on the
wireless client utility icon.
3. Wireless Configuration
2. Click Site Survey.Click the SSID
that matches your wireless access
point and then click Connect.
Windows XP/2000
1. On the bottom right-hand corner of
the screen, right click the wireless
network connection icon and select
Connect to a network.
Windows Vista
3. Enable/Enter the WEP/WPA
information when your wireless
network is encrypted. Then click
Apply.
English
6
Wireless configuration is now complete.
For detailed information regarding the TEW-624UB configuration and advanced
settings, please refer to the User's Guide included on the Utility & Driver CD-
ROM or TRENDnet's website at www.trendnet.com
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.TRENDnet.com/register
Thank you for choosing TRENDnet
3. Click Connect Anyway.
2. Select the desired network and
then click Connect.
4. Click Close.
7
Q1:
A1:
Q2:
A2:
Q3:
A3:
Q4:
A4:
I inserted the Utility & Driver CD-ROM into my computer's CD-ROM Drive but
the installation menu does not appear automatically. What should I do?
If the window does not appear automatically, click Start, click Run, and type
D:\autorun.exe where "D" in "D:\autorun.exe" is the letter assigned to your
CD-ROM Drive, and then press the ENTER key on your keyboard.
I completed all the steps in the quick installation guide, but my Wireless USB
Adapter is not connecting to my access point. What should I do?
First, verify that the Network Name (SSID) matches your wireless router or
access point’s Network Name (SSID). Second, please check with your network
administrator for security key in order to access a secured wireless access point or
router. Please refer to the User’s Guide for more information regarding wireless
network security. Third, check your TCP/IP properties to ensure that Obtain an IP
address automatically is selected. Fourth, double-click the Wireless Client Utility
icon, click Site Survey and then click Refresh to check and see if there are any
available wireless networks listed.
Windows is unable to recognize my hardware. What should I do?
Make sure your computer meets the minimum requirements as specified in
Section 1 of this quick installation guide. Also, you must complete the installation
of the wireless configuration utility (as described in Section 2) before connecting
the Wireless USB Adapter to your computer. Lastly, you may consider moving the
Wireless USB Adapter to a different USB port of your computer.
I cannot open the wireless configuration utility. What should I do?
Access your device manager to make sure the adapter is installed properly. If
you see a networking device with a yellow question mark or exclamation point, you
will need to reinstall the device and/or the drivers. To access your device manager,
right-click My Computer, click Properties, under the Hardware tab click Device
Manager.
If you still encounter problems or have any questions regarding the TEW-624UB, please
refer to the User's Guide included on the Utility & Driver CD-ROM or contact Trendnet's
Technical Support Department.
Troubleshooting
Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may cause undesired
operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE
CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS
COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.
ADVERTENCIA
En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de
alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al
mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador
de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria
existente en el pais o zona de instalación.
