TRENDnet TV-IP201W Bedienungsanleitung

TV-IP201W Internet Camera Server is the perfect device for remote

monitoring and transmitting real-time events over the Internet. The

TV-IP201W functions as a video/audio/surveillance camera

allowing you to view live events with your web browser via Internet or

Intranet. Up to 16 cameras can be remotely managed with the

bundled IPView software. This Internet Camera Server has M-JPEG

quality streaming video, automatic image capture, and event

notification via e-mail, making it the ideal solution for Internet video

broadcasting applications.

TV-IP201W

Wireless Internet Camera Server with Audio

TV-IP201W

rev:08.30.2006

• Wi-Fi Compliant with IEEE 802.11b/g Devices on 2.4 GHz ISM Frequency Band

• Wireless Supports Infrastructure and Ad-Hoc Modes

• Wireless Supports WEP 64/128-Bit Encryption (ASCII & HEX),

• Supports M-JPEG Compression and Audio Monitoring

• Built-in RS-485 connectors for Pan & Tilt control device (additional Pan & Tilt control device required)

• Supports ActiveX Control for Internet Explorer and Java applet for Internet Explorer and Netscape Navigator

• Allows for Remote Access from Web Browser for Live Image Viewing and listening

• Supports TCP/IP networking, SMTP e-mail, HTTP and other Internet related protocols

• Supports Web Configuration with Password Protection

• Powerful Windows IPView Application Software for multiple cameras monitoring, motion detection alerts, image capturing, and

video recording (Windows 98/ME/2000/XP)

• Built-in I/O Ports to Trigger Alarm and Email Notification

• Broad Range of Applications for Monitoring Homes, Offices, Banks, Hospitals, and a Variety of Private and Public Monitoring

• 3-Year Warranty

FEATURES

Wireless Internet Camera Server with Audio

TV-IP201W

SPECIFICATIONS

Resolution

Resolution / Light Frequency

Lens

MIC Input

Volume Control

Compression

Frame Rate Setting

Mirror Function

LAN

Supported OS

Application

Browser

Control

Protocol

• ¼” Color CMOS Sensor

• 176 x 144, 320 x 240, 640 x 480 • Outdoor/Indoor/50Hz/60Hz

• 640 x 480 pixel

• 1, 3, 7, 12, 15, 25, 30 (Depends on video format)

• Vertical / Horizontal

• HTTP, FTP, TCP/IP, UDP, ARP, ICMP, DHCP, PPPoE, DDNS, SMTP, UPnP

• Internet Explorer (5.0 or above) or Netscape Navigator (6.0 or above)

• f :6.0mm F1.8 Lens (CS-Mount Standard, Replaceable)

• Internal MIC (mono)

• Adjustable

• Yes (Brightness/ Contrast/ Saturation/ Sharpness)

• ADPCM/PCM

• 30fps@CIF, QCIF, VGA

• Windows 98SE, ME, 2000, XP

• 10/100Mbps Auto-Sense, Auto-MDIX

• IP View and Active X

Image Frame Rate

Compression

Audio

Video/Image

Communication

Sensor

Image Sensor

• M-JPEG

RAM/Flash ROM

Input

Output

RS-485

• ADMtek 5120

• 16MB/4MB

• Linux

• 1 set, 2 pin (photo relay; Active High: 9~40V DC; Dropout: 0V DC)

• 1 set, 2 pin (photo relay. Close circuit current: 70mA~100mA; 30Ohm. Open circuit voltage: 240V AC or 350V DC)

• Half Duplex (to control external pan/tilt device

• 512MB or above

Memory Size

Requirements

NO & Control

CPU

System

Software

• Intel Celeron 1.1GHz or above (Pentium 4 Recommend) VGA card resolution: 800 x 600 or above

Note: According to Engineer, to record 8 Cameras at the same time, will require at least P4 3.0GHz, 1GB RAM.

Minimum Illumination • IR On: 2.5 Lux

• IR Off: 2.5 Lux

Frequency

Module Technique

Encryption

Data Rate

• IEEE 802.11b/g

• 2.4 ~ 2.4835Ghz

• 82.11b: DSSS • 802.11g: OFDM

• 64/128-Bit WEP

• 802.11g: 54, 48, 36, 24,12, 9 &6Mbps • 802.11b: 11, 5.5, 2 & 1Mbps

Standard

Wireless

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

Wireless Internet Camera Server with Audio

TV-IP201W

RELATED PRODUCTS

PACKAGE CONTENTS

• Multi-Language Quick Installation Guide

• Power Adapter (5V DC 2.5A)

• TV-IP201W

• Utility CD-ROM

• RJ-45 Ethernet Cable

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

3135 Kashiwa Street,Torrance, CA 90505 USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.trendnet.com

NETWORKING SOLUTIONS

TV-IP100

TV-IP300

TV-IP100W

TV-IP201

TV-IP300W

Internet Camera Server with Audio

Advanced Wireless Day/Night Internet Camera Server

Internet Camera Server

Advanced Day/Night Internet Camera Server

Wireless Internet Camera Server

Dimension

Weight

Stand Height

Consumption

Humidity

LED

Safety Emissions

Power

Temperature

• xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx

• 180 x 83 x 47 mm (7.1 x 3.3 x 1.9 in.)

• Camera: 247 g (8.7 oz.); Stand: 116 g (4.1 oz.)

• 128 mm (4.7 in.)

• 5% ~ 95% Non-Condensing

• CE, FCC

• 4.5 Watt max.

• Operating: 5° C ~ 40° C (41° F ~ 104° F) • Storage: -25° C ~ 50° C (-13° F ~ 122° F)

• 5V DC, 2.5A External Adapter

• Power: Blue • Link/Active: Orange

Physical/Environmental

SPECIFICATIONS

Office Monitoring

(TV-IP201)

Parking

Monitoring

(TV-IP201W)

Warehouse

Monitoring

(TV-IP201W)

Wireless Access Point

(TEW-430APB)

Firewall Router

(TW100-BRF114)

Workstation with

PCI Adapter

(TE100-PCIWN)

Cable/DSL

Modem

Internet

Front Gate

Monitoring

(TV-IP201)
