TRENDnet TV-IP672W Bedienungsanleitung

TV-IP672W

rev: 05.23.2012

PRODUCT OVERVIEW

• See more with Megapixel resolution up to 1280 x 800 (WXGA)

• Pan 340° side-to-side and tilt 115° up-and-down

• High speed wireless n connection

• Program motion detection recording, recording schedules, email alerts and more with complimentary software

• 2-way audio

Megapixel Wireless N PTZ Internet Camera

TV-IP672W (V1.0R)

The Megapixel Wireless N PTZ Internet Camera, model TV-IP672W,

provides security over a large area. Pan the camera side-to-side

a remarkable 340°and tilt up-and-down 115°from any Internet

connection. Wireless n technology provides unsurpassed wireless

coverage and improved streaming video quality. Add this camera to

your wireless network at the touch of a button with Wi-Fi Protected

Setup (WPS).

Record 1280 x 800 Megapixel (WXGA) video at up to 30 frames per

second (fps). Manage up to four video proﬁ les to record HD video

while streaming low resolution video to a compatible smart phone at

the same time. Manage up to 32 TRENDnet cameras with the included

complimentary camera management software. Advanced features

include adjustable motion detection recording areas, email alerts,

scheduled recording sessions, pan / tilt, Auto-Patrol,

H.264 / MPEG-4 / MJPEG image compression, date-and-time overlays,

a Micro-SD card slot for backup storage, two-way audio (speakers not

included), an adjustable lens, and four times digital zoom. A

wall / ceiling mounting kit is included and the camera’s off white housing

blends into most environments.

TV-IP672W

rev: 05.23.2012

Megapixel Wireless N PTZ Internet Camera

TV-IP672W (v1.0R)

FEATURES

• Wi-Fi compliant with IEEE 802.11n standard

• Backwards compatible with IEEE 802.11g and IEEE 802.11b devices

• One touch WPS connection button

• 1 x 10/100 Mbps Auto-MDIX RJ-45 port (for optional wired connection)

• Power and activity LED indicators (can be disabled)

• 2-way audio: built-in microphone and audio out port for third party speakers

• 4x digital zoom

• Micro SD card slot*

• Manual focus lens

• Stream and record up to 4 different video proﬁ les simultaneously

• Pan left or right 170° for a total of 340°

• Tilt the camera up 90° and down 25° for a total of 115°

• Stream Internet camera video to a 3GPP compatible wireless device

• Dynamic DNS support

• Supports up to 1280 x 800 pixel resolution at up to 30 frames per second

• Image controls: brightness, contrast, auto gain control, noise reduction, saturation, sharpness, back light control, hue, frequency,

ﬂ ip image vertically, mirror image horizontally, and black and white mode

• Event Trigger: motion detection or digital input signal

• Event Action: send real-time snapshots (up to 3 before and 3 after the event) or video recording (up to 5 seconds before and 10

seconds after the event) to FTP or email

• Samba client support to record to a NAS drive

• Supports TCP/IP networking, email, HTTP, Samba and other Internet protocols

• System controls:

• Deﬁ ne up to 20 user login accounts

• Set the date and time or synchronize with an NTP server

• Supports wireless encryption up to WPA2-PSK

• Quick Universal Plug and Play (UPnP) installation

• Mounting base and mounting hardware included

• 3-year limited warranty

* Micro SD card sold separately

TV-IP672W

rev: 05.23.2012

Megapixel Wireless N PTZ Internet Camera

TV-IP672W (v1.0R)

SECURVIEW PRO CAMERA SOFTWARE FEATURES

• Manage up to 32 cameras

• Compatible with Windows and Microsoft Server 2008

• Multiple language support

• Camera Viewing

• Preset viewing modes

• Program custom viewing modes

• Full screen view

• Drag and drop live feeds to a new location

• Program camera cycle viewing sequence

• Motion detection brings video forward

• Side, top, and bottom tool bars can be hidden

• Web based access from smart phones and tablets

• Recording options

• Program weekly recording schedules

• Motion detection recording

• Deﬁ ne motion detection areas of any shape

• Deﬁ ne motion detection sensitivity

• Event trigger recording

• Date and time overlay

• Mask overlay to conceal sensitive areas

• Save a single video stream to multiple locations simultaneously

• Deﬁ ne recording quotas by recording time or space allocation

• Disk clean feature condenses and optimizes old ﬁ les

• Real time recording stats to help manage ﬁ les

• Search and Playback

• Navigation timeline provides a quick visual reference to the recorded content

• Search continuous recordings by motion

• Search recordings by motion within a deﬁ ned ﬁ eld (a portion of the viewing area)

• Time laps playback search

• Map cameras on an image such as a ﬂ oor plan

• Map cameras on Google Maps™

TV-IP672W

rev: 05.23.2012

Megapixel Wireless N PTZ Internet Camera

TV-IP672W (v1.0R)

SPECIFICATIONS

CAMERA

General • Sensor: 1/4” CMOS Sensor

• Board Lens

• Focal Length: 4 mm

• F/No: 1.5

• Minimum illumination: 1 lux

• Focus Depth: 20 cm ~ inﬁ nity

• View:

• Horizontal: 51.8°

• Vertical: 33.8°

• Diagonal: 59.6°

• Digital Zoom: 4x

Audio • Built-in omni-directional microphone

• Sensitivity: -40 dB +/- 3 dB (5 meters max)

• Frequency: 100~20000 Hz

• S/N: >60 dB

• Format: PCM / ADPCM

• External speaker output (speaker sold separately)

• Two-way audio with echo canceling

Pan & Tilt • Pan: -170° ~ +170°

• Tilt: up 90°and down 25°

• Auto-Patrol preset positions: 10

HARDWARE

Network • IEEE 802.3u 10/100 Mbps Auto-MDIX Fast Ethernet

LED • Power, Link/Act

WPS Button • Enable WPS connection

Reset Button • Reset to factory default

Privacy Button • Privacy mode on / off

Power Consumption • Max 10.5 Watts

Power • Input: 100~240V, 50/60 Hz, 0.5A

• Output: 12V, 1.25A external power adapter

Dimension • 113 x 113 x 130 mm (4.5 x 4.5 x 5.1 in.)

Weight • 503 g (1.1 lbs.)

Temperature • Operating: 0°C ~ 40°C (32°F ~ 104°F)

• Storage: -25°C ~ 70°C (-13°F ~ 158°F)

Humidity • Max 90% (non-condensing)

Certiﬁ cations • CE, FCC

REQUIREMENT

Management Interface • Internet Explorer 7.0 or above

• Firefox, Safari, and Chrome

To Run software • Windows 7 (32/64-bit), Vista (32/64-bit), XP (32/64-bit)

• Windows Server 2003, 2008

SecurView Pro Software • Channel: supports up to 32 cameras

• Record / Playback / Motion Detection / Audio

TV-IP672W

rev: 05.23.2012

Megapixel Wireless N PTZ Internet Camera

TV-IP672W (v1.0R)

SPECIFICATIONS

REQUIREMENT

Network Protocols • IPv4, ARP, TCP, UDP, ICMP

• DHCP Client, NTP Client, DNS Client, DDNS Client, SMTP Client, FTP Client

• HTTP

• Samba Client

• PPPoE

• UPnP

• LLTD

• RTP (Real Time Protocol)

• RTCP (Real Time Control Protocol)

• RTSP (Real Time Streaming Protocol)

• 3GPP (video only)

WIRELESS

Standard • IEEE 802.11b, IEEE 802.11g, and IEEE 802.11n

Frequency • 2.4 ~ 2.483 GHz ISM band

Antenna • 1 x detachable 2 dBi dipole antenna (Reverse-SMA connector)

Date Rate • 802.11b: up to 11 Mbps

• 802.11g: up to 54 Mbps

• 802.11n: up to 150 Mbps

Security • 64/128-bit WEP, WPA / WPA2-PSK

Output Power • 802.11b: 17 dBm (typical)

• 802.11g: 15 dBm (typical)

• 802.11n: 14 dBm (typical)

Receiving Sensitivity • 802.11b: -88 dBm at 11 Mbps

• 802.11g: -74 dBm at 54 Mbps

• 802.11n: -68 dBm at 150 Mbps

Channels • 1~11 (FCC), 1~13(ETSI)

MANAGEMENT

System • Web based administration

Access • Up to 20 user accounts

Backup / Restore • Save / retrieve conﬁ guration ﬁ les

Log • System log up to 500 entries

Micro SD • View, download, delete ﬁ les

• Format and remove Micro SD card

Megapixel Wireless N PTZ Internet Camera

TV-IP672W (v1.0R)

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time,

SPECIFICATIONS

SETTINGS

Image • Brightness, contrast, saturation, sharpness, white balance, ﬂ ip, mirror (horizontal / vertical), black & white, indoor, outdoor,

schedule mode

• Shutter: 1/3.25s, 1/7.5s, 1/10s, and 1/15s

Video Setting • Proﬁ le 1: H.264 / MPEG-4

• Resolution: 1280 x 800, 640 x 400, 320 x 192, 160 x 96

• Max frame rate: 30fps

• Proﬁ le 2: H.264 / MPEG-4

• Resolution: 640 x 400, 320 x 192, 160 x 96

• Max frame rate: 30fps

• Proﬁ le 3: MJPEG

• Resolution: 1280 x 800, 640 x 400, 320 x 192, 160 x 96

• Max frame rate: 1280 x 800 @ 5fps, 640 x 400 / 320 x 192 @ 30fps

• JPEG quality: Low, Fair, Standard, Good, Excellent

• Proﬁ le 4: H.264 / MPEG-4

• Resolution: 640 x 400, 320 x 192, 160 x 96

• Max frame rate: 30fps

• RTSP: http://ipcamera_ip/3gpp

3GPP • Audio format: AMR

• Video format: MPEG-4

• Protocols: RTSP, RTP, RTCP

Recording • Resolution: Deﬁ ne individual resolution for up to 4 proﬁ les

• Required storage: 32 MB (minimum per proﬁ le)

• Recording type: event based (motion detection and digital input trigger), continuous, and scheduled

Event Action • Trigger event: motion detection or digital input signal

• Action: send real-time snapshot or video recording to FTP or email

Port Settings • HTTP port: 80 (default)

• RTSP port: 554 (default)

Time • Synchronize with NTP server or set time / date manually

NETWORKING SOLUTIONS

CONTACT INFORMATION

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web: www.trendnet.com

Email: [email protected]

1-888-326-6061

PACKAGE CONTENTS

TV-IP672W

CD-ROM (Utility & User’s Guide)

Multi-Language Quick Installation Guide

Network cable (1.5 m / 5 ft.)

Power adapter (12V, 1.25A)

Camera mounting kit
