TE100-PIP

Quick Installation Guide

Table of Contents

Version 07.21.2010

English 1

1. Before You Start

2. How to Install 2

3. 3

Configure the Print Server

4.Add the Printer to your PC 5

Troubleshooting 7

1. Before You Start

?Wired or Wireless Router

?An available DHCP server – routers usually have a built-in DHCPserver

CD-ROM Drive

Package Contents

?Utility CD-ROM

?Multi-Language Quick Installation Guide

?AC PowerAdapter (5V DC, 2.5A)

TE100-P1P

System Requirements

Supported Operating Systems CPU Memory

Windows 7 (32/64-bit)

Windows Vista (32/64-bit)

Mac OS X (10.6)

Windows XP

(32/64-bit) / 2000 / ME / 98SE

2003 Server /

1GHz or above

800MHz or above

Intel Processor

300MHz or above

1GB RAM or above

512MB RAM or above

1GB RAM or above

256MB RAM or above

Mac OS X (10.5)

Mac OS X (10.4)

Mac OS X (10.1-10.3)

867MHz or above

333MHz or above

300MHz or above

512MB RAM or above

256MB RAM or above

2. How to Installation

4. Power ON the printer.

Note: Please power off all printers before connecting them to the print server. Then turn

on each printer after you make your hardware connections.

3. Connect the Parallel Printer to the Parallel port

on the Print Server.

1. Connect a RJ-45 network cable from a Switch/

Router to the LAN port on the Print Server.

2. Connect the AC PowerAdapter to the Print

Server and then to a power outlet.

2. Click RunAutorun.exe (Windows 7/Vista only).

1. Insert the Utility CD-ROM into your computer's

CD-ROM Drive.

3. Configure the Print Server

Note: The Print Server can be managed using the PS Utility or a web browser. For MAC

users, change your computers IP address to 192.168.0.X (where X is an available

number from 2-254). Since the Print Server's default IP address is 192.168.0.1, make

sure no other network devices are assigned an IP address of 192.168.0.1.Then enter

http://192.168.0.1 in your web browser to access the Print Server's Web Utility.

For Windows Users

3. Click Install Utility PS Utility.

6. Click OK.

Print Server configuration is now complete.

5. Select the Print Server and click Change IP

Address. Manually assign the IPAddress of

the Print Server and then click OK.

Note: The IPAddress must match the network

segment of your network.

7. Click Show Web Setup.

4. Follow the InstallShield Wizard instructions.

Click Finish.

4.Add the Printer to your PC

Note: For printing instructions for Windows ME, 98SE, and Mac OS X, please consult

the User's Guide included on the Utility CD-ROM.

Windows 7/Vista/2003 Server/XP/2000

2. Select the print server, select the desired port

and then click Add Printer.

3. Click Select from manufacturer list. Select

the appropriate driver for your printer and then

click Next.

1. Click PS Wizard and then click Windows

7/Vista/2003 Server/XP/2000.

7. Click Finish.

8. Repeat steps 1 to 7 to add the printer to other

computers on the network.

Add Printer is now complete.

For detailed information regarding the TE100-P1P configuration and advanced settings,

please refer to User's Guide on the Utility CD-ROM, or TRENDnet's website at

http://www.trendnet.com.

To ensure the highest level of customer service and support, please take a moment to

Thank you for choosing TRENDnet

4. Click Next.

5. Click Print Test Page.

6. Click OK.

1. I inserted the Utility CD-ROM into my computer's CD-ROM Drive but the installation menu does

not appear automatically. What should I do?

1. For Windows 7, if the installation menu does not appear automatically, click on the Windows

Icon on the bottom left hand corner of the screen, click the “Search programs and files” box,

type D:\autorun.exe, where “D” in “D:\autorun.exe” is the letter assigned to your CD-ROM

Driver, and then press the ENTER key on your keyboard

2. For Windows Vista, if the installation menu does not appear automatically, click Start, click

the Start Search box, type D:\autorun.exe where "D" in "D:\autorun.exe" is the letter

assigned to your CD-ROM Drive, and then press the ENTER key on your keyboard.

3. For Windows 2000/XP, if the window does not appear automatically, click Start, click Run, type

D:\autorun.exe where “D” in “D:\autorun.exe” is the letter assigned to your CD-ROM Drive,

and then press the ENTER key on your keyboard.

2. The PS Wizard / PS Utility is unable to see my printer server. What should I do?

1. Double check your hardware connections; make sure that the print server and printer are

powered ON and are properly connected.

2. Click Discover.

3. Disable any software firewall programs (e.g. ZoneAlarm). If your computer is running

Windows 7, Vista, or XP, disable the built in firewall program.

3. I successfully added a printer to my computer and I can print a test page, but I cannot print

anything from Microsoft Word or other applications.

Make sure the printer is set as your default printer.

1. On Windows 7, click the Windows icon Devices and Printers and verify that your printer icon

has a check on it.

2. On Windows Vista, click the Start Icon Control Panel Classic View Printers and verify

that your printer icon has a check on it.

3. On Windows XP/2000/20003 Server, click Start and then click Printers & Faxes, verify that your

printer icon has a check on it.

4. My printer does not print the entire document. What should I do?

Windows 7

1. Click on the Windows icon on the bottom left-hand corner of the screen.

2. Click Devices and Printers.

3. Right click on the printer and select Printer Properties.

4. Click the Advanced tab.

5. Uncheck Enable advanced printing features.

6. Click Apply.

7. Click OK.



  

Troubleshooting

Windows Vista

1. Click on the Windows icon on the bottom left-hand corner of the screen.

2. Click Control Panel.

3. Click Classic View.

4. Click Printers.

5. Right click on the printer and select Properties.

6. Click the Advanced tab.

7. Uncheck Enable advanced printing features.

8. Click Apply.

9. Click OK.

5. I configured my print server to automatically receive an IPAddress from a DHCP server, and

now I cannot go into the Print Server's web utility.

Open PS Wizard (See 4.Add the Printer to your PC) to locate your print server's IPAddress.

6. How do I setup the TE100-P1P on a Mac?

Type in http://192.168.0.1 in you browser to logon to the built-in web configuration

7. I forgot the administration password. How do I reset my TE100-P1P?

Factory reset the TE100-P1Pusing the following procedure. This procedure will reset all settings

to default. By default, there is no password.

1. Open up PS Utility.

2. Copy down the last 4 digits of the MAC address.

3. Press the Factory Reset button.

4. When prompted for a password, enter SYSXXXX, where XXXX represents the last 4 digits of the

MAC address. Note:All letters must be uppercase.

If you still encounter problems or have any questions regarding the TE100-P1P, please contact

TRENDnet's Technical Support Department.
