FEATURES
•Wi-FicompliantwithIEEE802.11b/g/nnetworks
•3xdigitalzoom
•1x10/100MbpsFastEthernetport
•1xWi-FiProtectedSetupbutton
•Pan330°side-to-sideandtilt105°up-and-downfromanyInternetconnection
•HighqualityMPEG-4andMJPEGvideorecordingwithupto30framespersecond
•Resolutionupto640x480pixelsresolution
•PowerandactivityLEDindicators(canbedisabled)
•DynamicDNSsupport
•NetworkInput/Output(GPIO)portstoanalarmsystem
•Imagecontrol:brightness,contrast,saturation,andmirror(horizontally/vertical)
•SupportsTCP/IPnetworking,SMTPEmail,HTTP,Samba,andotherInternetprotocols
•RecordstreamingvideotoyourcomputerandNetworkStorageServer
•Supports64/128-bitWEPandWPA/WPA2-PSKwirelessencryption
•Twoadjustablemotiondetectionwindowswithjust-in-timesnapshot,triggeredvideorecording,andemailalerts
•QuickUniversalPlugandPlayinstallation
•ComplimentarySecurViewProsoftware:manageupofupto32camera**
•3-yearlimitedwarranty
**MonitoringmultiplecamerasmayrequireahighperformanceCPU
SecurView Wireless N Pan/Tilt/Zoom
Internet Camera
TV-IP410WN(V1.0R)
The SecurView Wireless N Pan/Tilt/Zoom Internet Camera, model
TV-IP410WN, covers a large security surveillance area. Pan the camera
side-to-side a remarkable 330° and tilt up-and-down 105°.
Wireless n technology provides unsurpassed wireless coverage and
improved streaming video quality. Add this camera to your wireless
network at the touch of a button with Wi-Fi Protected Setup (WPS).
Manage up to 32 SecurView cameras with the included
complimentary camera management software. Advanced features
include motion detection recording, email alerts, scheduled recording
sessions, 3GPP support, preset Auto-Patrol, and digital zoom. A wall/
ceiling mounting kit is included and the off-white camera housing blends
into most environments.
TV-IP410WN
rev: 04.11.2011
SecurView Wireless N Pan/Tilt/Zoom Internet Camera
TV-IP410WN(V1.0R)
SPECIFICATIONS
Camera
General • Sensor:1/4”colorCMOSsensor•Resolution:640x480pixels•BoardLens
• FocalLength:4.0mm•Aperature(F/No):F1.8•Minimumillumination:0.5lux•DiagonalViewingangle:64degrees
Pan & Tilt • Pan:+165~-165degree•Tilt:+90~-15degree•Presetpositions:8positions
Image & Video • Compression:MPEG-4/MJPEGdualstreaming•Exposure/whitebalance/GainControl:automatic
• Resolution:upto30psforVGA(640x480),30fpsforQVGA(320x240),30fpsforQQVGA(160x120)
Hardware
Network • IEEE802.3u10/100MbpsFastEthernet,Auto-MDIX
LED • Power,Link/Act
Reset Button • Restoretofactorydefault
WPS Button • PushbuttonforWi-FiProtectedSetup
Power Consumption • 9Watts(max.)
Power • 12VDC,1.5Aexternalpoweradapter(3.5mmplug)
Dimension • 70x100x57mm(2.67x3.94x2.95in)
Weight • 340g(12oz)
Temperature • Operating:0°C~45°C(32°F~113°F)•Storage:-15°C~60°C(5°F~140°F)
Humidity • Max.90%(non-condensing)
Certications • CE,FCC
Requirement
Management Interface • InternetExplorer6.0orabove
To Run SecurView Pro • Windows7(32/64-bit),Vista(32/64-bit),XP(32/64-bit)
SecurView Pro • Channel:supportsupto32cameras•Record/Playback/MotionDetection
Network Protocols • TCP/IP,UDP,ICMP,DHCP,NTP,DNS,DDNS,SMTP,FTP,HTTP,Samba,PPPoE,UPnP,Bonjour,RTP,RTSP,RTCP
Wireless
Standard • BasedonIEEE802.11ntechnology•IEEE802.11g/bcompliant
Frequency • 2.4~2.4835GHz
Antenna • 1x2dBidipoleantenna(Reverse-SMAconnector)
Date Rate (Auto Fallback) • 802.11n:upto150Mbps•802.11g:upto54Mbps•802.11b:upto11Mbps
Security • 64/128-bitWEP,WPA/WPA2-PSK
Output Power • 802.11n:15+1dBm•802.11b:15+1dBm•802.11g:18+1dBm
Receiving Sensitivity • 802.11nHT20:-67dBm•802.11nHT40:-64dBm•802.11g:-70dBm•802.11b:-87dBm
Channels • 1~11(FCC),1~13(ETSI)
Management
Remote • Remotemanagementsupported
Backup / Restore • Save/retrievecongurationles
Settings
Image • Brightness,sharpness,saturation,ip,mirror(horizontal/vertical)
Video • Encodingtype:MJPEG•Resolution:640x480,320x240,160x120•Framerate:1~30fps•Compression:5levels
Recording • Recordingtype:continuous,scheduleormotiondetectionwithsoftware
TV-IP410WN
rev: 04.11.2011
TRENDnetisaregisteredtrademark.OtherBrandsandproductnamesaretrademarksoftheirrespectiveholders.InformationprovidedinthisdocumentpertaintoTRENDnetproductsandissubjecttochangeatanytime,
withoutnotice.Forthemostrecentproductinformationpleasevisithttp://www.trendnet.comCopyright ©TRENDnet.All Rights Reserved.
CONTACT INFORMATION
20675ManhattanPlace,Torrance,CA90501USA
Tel:1-310-961-5500
Fax:1-310-961-5511
Web:www.trendnet.com
Email:[email protected]
1-888-326-6061
PACKAGE CONTENTS
TV-IP410WN
Multi-LanguageQuickInstallationGuide
CD-ROM(Utility&User’sGuide)
Poweradapter(12VDC,1.5A)
Networkcable(1.8m/5.9ft.)
Mountingstand
RELATED PRODUCTS
TV-IP121WN SecurViewWirelessNDay/NightInternetCamera
TV-IP312WN SecurViewWirelessNDay/NightInternetCamera
TV-IP422WN SecurViewWirelessNDay/NightPan/Tilt/ZoomInternet
Camera
SecurView Wireless N Pan/Tilt/Zoom Internet Camera
TV-IP410WN(V1.0R)
SPECIFICATIONS
Settings
Port Settings • HTTPport:80(default)
Digital Zoom • 3x
Dynamic DNS • Yes
Time • SynchronizewithNTPserverorsettime/datemanually
SMTP • SMTPmailsupportedupto2accountswithsoftware
System log • 100entries(max.)
