PRODUCT OVERVIEW

• Night vision of up to 7.5 meters*

• High speed wireless n connection

• Program motion detection recording, recording schedules, email alerts and more with complimentary software

• One-way audio

• Wall / ceiling mounting kit

TV-IP551WI

Rev: 01.12.2012

Wireless N Day / Night Internet Camera

TV-IP551WI (v1.0R)

The Wireless N Day / Night Internet Camera, model TV- IP551WI, transmits

real-time video over the Internet. Record crisp video in complete darkness for

distances of up to 7.5 meters. Wireless n technology provides unsurpassed

wireless coverage and improved streaming video quality. Add this camera

to your wireless network at the touch of a button with Wi-Fi Protected Setup

(WPS).

Record 640 x 480 (VGA) video at up to 20 frames per second (fps). Manage

up to 32 TRENDnet cameras with the included complimentary camera

management software. Advanced features include adjustable motion

detection recording areas, email alerts, scheduled recording sessions,

one-way audio, an adjustable lens, and four times digital zoom. A wall / ceiling

mounting kit is included and the camera’s off white housing blends into most

environments.

Wireless N Day / Night Internet Camera

TV-IP551WI (v1.0R)

TV-IP551WI

Rev: 01.12.2012

FEATURES

• Wi-Fi compliant with IEEE 802.11n standard

• Backwards compatible with IEEE 802.11g and IEEE 802.11b devices

• One touch WPS connection button

• 1 x 10/100Mbps Auto-MDIX RJ-45 port (for optional wired installation)

• Power and activity LED indicators (can be disabled)

• 1-way audio

• Reset button

• Night vision of up to 7.5 meters*

• 4x digital zoom

• Dynamic DNS support

• Supports up to 640 x 480 pixel MJPEG resolution at up to 20 frames per second

• Image controls: Brightness, contrast, saturation, ﬂ ip image vertically, mirror image horizontally, and day / night mode

• Deﬁ ne a recording schedule, continuous recording, or event based recording

• Create motion detection ﬁ elds over the viewing area

• Supports TCP/IP networking, Email, HTTP, and other Internet protocols

• System controls:

• Deﬁ ne up to 64 user login accounts

• Set the date and time or synchronize with an NTP server

• Supports wireless encryption up to WPA2-PSK

• Quick Universal Plug and Play (UPnP) installation

• Complimentary SecurView™ software: manage up to 32 cameras **

• SecurView™ software compatible with Windows operating systems

• Mounting base and mounting hardware included

• 3-year limited warranty

*This camera is designed for indoor use. For outdoor surveillance applications we recommend TRENDnet outdoor cameras

**Monitoring multiple cameras may require a high performance CPU

Wireless N Day / Night Internet Camera

TV-IP551WI (v1.0R)

TV-IP551WI

Rev: 01.12.2012

SECURVIEW PRO CAMERA SOFTWARE FEATURES

• Manage up to 32 cameras

• Compatible with Windows and Microsoft Server 2008

• Multiple language support

• Camera Viewing

• Preset viewing modes

• Program custom viewing modes

• Full screen view

• Drag and drop live feeds to a new location

• Program camera cycle viewing sequence

• Motion detection brings video forward

• Side, top, and bottom tool bars can be hidden

• Web based access from smart phones and tablets

• Recording options

• Program weekly recording schedules

• Motion detection recording

• Deﬁ ne motion detection areas of any shape

• Deﬁ ne motion detection sensitivity

• Event trigger recording

• Date and time overlay

• Mask overlay to conceal sensitive areas

• Save a single video stream to multiple locations simultaneously

• Deﬁ ne recording quotas by recording time or space allocation

• Disk clean feature condenses and optimizes old ﬁ les

• Real time recording stats to help manage ﬁ les

• Search and Playback

• Navigation timeline provides a quick visual reference to the recorded content

• Search continuous recordings by motion

• Search recordings by motion within a deﬁ ned ﬁ eld (a portion of the viewing area)

• Time laps playback search

• Map cameras on an image such as a ﬂ oor plan

• Map cameras on Google Maps™

Wireless N Day / Night Internet Camera

TV-IP551WI (v1.0R)

SPECIFICATIONS

CAMERA

General • Sensor: 1/5” CMOS Sensor

• Board Lens

• Focal Length: 4mm

• F/No: 1.5

• Minimum illumination: 0 lux

• Focus Depth: 20 cm ~ inﬁ nity

• View:

• Horizontal: 38.0 degrees

• Vertical: 28.7 degrees

• Diagonal: 46.5 degrees

• Digital Zoom: 4x

Audio • Built-in omni-directional microphone

• Sensitivity: -38dB +/- 3dB (5 meters max)

• Frequency: 100~20000Hz

• S/N: >60dB

• Format: PCM

Day/Night • Built-in ICR

• Night vision (IR) up to 7.5 meters

HARDWARE

Network • IEEE 802.3u 10/100Mbps Auto-MDIX Fast Ethernet

LED • Power, Link/Act

WPS Button • Enable WPS connection

Reset Button • Reset to factory default

Power Consumption • Max 5 Watts

Power • Input: 100~240V, 50/60Hz, 0.2A

• Output: 5V, 1.2A external power adapter

Dimension • 75 x 115 x 30 mm (2.95 x 4.5 x 1.2 in.)

Weight • 110 g (3.8 oz.)

Temperature • Operating: 0°C ~ 40°C (32°F ~ 104°F)

• Storage: -15°C ~ 60°C (5°F ~ 140°F)

Humidity • Max 95% (non-condensing)

Certiﬁ cations • CE, FCC

REQUIREMENT

Management Interface • Internet Explorer 7.0 or higher

• Firefox 3.5 or above

• Safari 4.0 or above

To Run software • Windows 7 (32/64-bit), Vista (32/64-bit), XP (32/64-bit)

• Windows Server 2003, 2008

SecurView Software • Channel: supports up to 32 cameras

• Record / Playback / Motion Detection / Audio

Network Protocols • IPv4, ARP, TCP, UDP, ICMP

• DHCP Client, NTP Client, DNS Client, DDNS Client, SMTP Client, FTP Client

• HTTP

• PPPoE

• UPnP

TV-IP551WI

Rev: 01.12.2012

SPECIFICATIONS

WIRELESS

Standard • IEEE 802.11b, IEEE 802.11g and IEEE 802.11n

Frequency • 2.4 ~ 2.497 GHz ISM band

Modulation • DQPSK, DBPSK, DSSS, and CCK

Antenna • Built-in 2dBi antenna

Date Rate • 802.11b: up to 11Mbps

• 802.11g: up to 54Mbps

• 802.11n: up to 150Mbps

Security • 64/128-bit WEP, WPA / WPA2-PSK

Output Power • 802.11b: 17dBm (typical)

• 802.11g: 14.5dBm (typical)

• 802.11n: 14.5dBm (typical)

Receiving Sensitivity • 802.11b: -89dBm at 11Mbps

• 802.11g: -74dBm at 54Mbps

• 802.11n: -71dBm at 150Mbps

Channels • 1~11 (FCC), 1~13(ETSI)

MANAGEMENT

Accounts • Up to 64 user accounts

Remote Login • Remote management supported

Backup / Restore • Save / retrieve conﬁ guration ﬁ les

SETTINGS

Image • Brightness, contrast, saturation, sharpness, white balance, ﬂ ip, mirror (horizontal / vertical), black & white, indoor, outdoor,

schedule mode

Video Setting • Encoding: MJPEG

• Resolution: 640 x 480, 320 x 240, 160 x 120

• Max frame rate: VGA @ 20fps, QVGA @ 30fps, QQVGA @ 30fps

• JPEG quality: Very Low, Low, Medium, High, Very High

Recording • Event based (motion detection), and scheduled

Snapshot • Trigger event: motion detection

• Action: send alert email and / or upload to FTP

• Real time snapshot

Port Settings • HTTP port: 80 (default)

Time • Synchronize with NTP server or set time / date manually

Wireless N Day / Night Internet Camera

TV-IP551WI (v1.0R)

TV-IP551WI

Rev: 01.12.2012

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time,

CONTACT INFORMATION

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web: www.trendnet.com

Email: [email protected]

1-888-326-6061

PACKAGE CONTENTS

TV-IP551WI

CD-ROM (Utility & User’s Guide)

Multi-Language Quick Installation Guide

Network cable (1.5 m / 5 ft.)

Power adapter (5V DC, 1.2A)

Camera mounting kit
