TRENDnet TE100 PCIWN Bedienungsanleitung

TRENDnet

TRENDware, USA

What's Next in Networking

TE100-P21

Version 12.14.04

2-port USB 2.0 and 1 port Parallel Print Server

Quick Installation Guide

Guide d'installation rapide du

serveur d'impression à 2 ports USB 2.0 et 1 port parallèle

Druckserver mit 2 USB-2.0-Ports und 1 Parallelport

Kurzanleitung zur Installation

Guía de instalación rápida del

servidor de impresora de 1 puerto paralelo y 2 puertos USB 2.0

Table of Contents

English ......................................................................................................

Troubleshooting ........................................................................................

1. Prepare for Installation ......................................................................

2. Product Detail .....................................................................................

3. Hardware Installation ........................................................................

4. Configure the Print Server ................................................................

5. Add the Network Printer to your PC ..................................................

Thank you for purchasing TRENDnet's TE100-P21 2-port USB 2.0 and 1 port

Parallel Print Server.

This guide will help you set up your Print Server. Following the installations

should be quick and easy. If you run into problems, please refer to the

Troubleshooting section. If you need further technical support, please visit

www.TRENDNET.com or call technical support by phone.

Verify Package Contents

Minimum System Requirements

Please make sure you have everything in the box:

1. Pentium 100Mhz or faster processor

2. 8MB RAM or more

3. Windows 95/98/NT/ME/2000/XP/2003, HP-UX, Sun O.S, Solaris, SCO Unix,

AIX, Unixware, Linux, Mac O.S.

1. Prepare for Installation

English QIG

English

TE100-P21

Driver CD-ROM

Quick Installation Guide

Power Adapter (5 V, 2.5A)

TRENDnet

TRENDware, USA

What's Next in Networking

TE100-P21

Version 12.14.04

2-port USB 2.0 and 1 port Parallel Print Server

Quick Installation Guide

Guide d'installation rapide du

serveur d'impression à 2 ports USB 2.0 et 1 port parallèle

Druckserver mit 2 USB-2.0-Ports und 1 Parallelport

Kurzanleitung zur Installation

Guía de instalación rápida del

servidor de impresora de 1 puerto paralelo y 2 puertos USB 2.0

2. Product Detail

The Print Server has a RJ-45 connector, two USB 2.0 slots, and one parallel

port. It also has five LEDS that indicate power, network activity, and printer

activity.

English

Parallel Port

Power LED

Reset Button

Power Adapter

Connector

USB Ports

Network LED

RJ-45 Connector

Printer LEDs

3. Hardware Installation

1. Power off the Print Server and Printers.

2. Connect the Print Server's printer port to the printers.

3. Connect the RJ45 cable to the LAN port and to your network hub or switch.

4. Plug the AC power adapter into the power connector on the back of the Print

Server.

5. Power on the printer.

English

1. Insert the TE100-P21 CD-ROM into your computer's CD-ROM drive.

2. Click Install Utility.

3. Click Next.

4. Configure the Print Server

English

NOTE: For MAC Users, change your computers IP address to

192.168.0.X (where X is an available number from 1-253), and enter

192.168.0.1 in your web browser to access the Print Server's Web

Utility.

For Windows Users

5English

4. Click Next.

5. Click Yes.

6. Click Finish.

6English

7. Double-click PS-Utility icon.

8. The utility will detect any available Print Servers on the network. Select the

Print Server you need to configure and click Change IP Address.

9. Type in the IP address that applies to your existing network. Type in the

Default Gateway (i.e. your router's local IP address).

7English

10. Click OK.

11. Click Show Web Setup.

12. Please take note and write down the Server Name and the Printer Name.

If you connected a USB printer to the USB1 slot, use the Printer Name

that is by the USB1 heading in the web configuration utility. If you

connected a Parallel printer, use the Printer Name that is by the LPT3

heading in the web configuration utility.

Print Server's configuration is now complete. For detail information, please

check the User's Guide that's included on the CD-ROM.

8English

5. Add the Network Printer to your PC

1. For Windows 2000/XP, Click Start Control Panel.

For Windows 95/98/ME, Click Start Settings Control Panel.

2. Double-Click the Printers and Faxes Icon.

3. Click or Double-Click Add Printer.

4. Click Next.

5. Select Network Printer option and click Next.

Note: If you are using Windows 95/98/ME, then make sure that

NETBEUI is installed before you follow the instructions below. If you are

using Windows 2000/XP, then you can simply add your printer using the

instructions below. For TCP/IP Printing instructions, please consult the

User’s Guide on the CD-ROM for details.

For Windows 95/98/ME/2000/XP
