TRENDnet TE100-S86FX Bedienungsanleitung

Fast Ethernet Switch

Fast EthernetSwitch 1

User’s Guide

Preface

This manual describes how to install and use the provided eight-

port Fast Ethernet Switch, which features that 10/100BASE-TX

ports automatically sense the presence of 100Mbps or 10Mbps

Ethernet networks. 100BASE-FX Multi-mode and Single-mode

fiber ports are also available for this product series.

To get the most out of this manual, you should have an

understanding of networking concepts such as bridging, IEEE

802.3 Ethernet and 100BASE-TX/FX Fast Ethernet, and local

area networks (LANs).

For more information about these topics, please refer to the

Appendix.

Fast Ethernet Switch

2 Fast Ethernet Switch

User’s Guide

Table of Contents

Preface .............................................................................1

Table of Contents...........................................................2

Chapter Overview ..........................................................3

Introduction .............................................................................3

Installation ...............................................................................3

Specifications..........................................................................3

Connector Pinouts..................................................................3

Introduction to LAN & Ethernet Technologies.......................3

Introduction.....................................................................4

Benefits of Switching ..............................................................4

Eight Ports Ethernet Switch ...................................................5

Product Features ....................................................................7

Packing List.............................................................................7

Front Panel .............................................................................8

Ports ...................................................................................8

LEDs.................................................................................10

Installation.................................................................... 14

Selecting a Site for the Switch .............................................14

Connecting to Power............................................................15

Connecting to Your Network................................................16

Specifications .............................................................. 17

Appendix A - Connector Pinouts ............................. 18

Appendix B –Introduction to LAN & Ethernet

Technologies............................................................ 19

Fast Ethernet Switch

Fast EthernetSwitch 3

User’s Guide

Chapter Overview

Introduction

A general overview of switching benefits and the features of the

Switch this manual accompanied with.

Installation

Everything you need to know to install and configure the Switch

with your network.

Specifications

The Switch’s specifications at a glance.

Connector Pinouts

See Appendix A for more information.

Introduction to LAN & Ethernet Technologies

See Appendix B for more information.

Fast Ethernet Switch

4 Fast Ethernet Switch

User’s Guide

Introduction

Benefits of Switching

Ethernet switching technology has dramatically boosted the total

bandwidth of a network. It puts configuration flexibility and

bandwidth adaptability into the local workgroups where the

majority of work is generated.

It further eliminates congestion problems inherent to the

CSMA/CD protocol and improves predictable response time

under heavy network loads. Expensive routing equipment was

used in the past to reduce the congestion under heavy loads.

The new wave of object-oriented client and server applications

demands higher bandwidth and tighter integration of client

work stations with servers. The old shared-access Ethernet

technology provides neither enough bandwidth nor predictable

response time for this new wave of workgroup computing.

Fast Ethernet switching not only satisfies both technical and

business requirements, but also preserves the user’s existing

investment in the huge 10BASE-T Ethernet installed base.

This compatibility ensures a path for users to add, change, and

migrate to Fast Ethernet as demands emerge. It also provides

a low cost and flexible bandwidth solution directly to local

workgroups where the majority of work is generated, reducing

the need for expensive network equipment.

Fast Ethernet Switch

Fast EthernetSwitch 5

User’s Guide

Eight Ports Ethernet Switch

The eight-port Fast Ethernet switch offered here adds 100Mbps

switching performance in a cost-effective desktop package.

The Switch has RJ-45 ports, each a 10/100 port capable of

autosensing both speed and half/full duplex mode.

With the demand for fiber, this eight-port switch provides multi-

mode fiber ports.

This switch makes it possible to join a 100Mbps Fast Ethernet

network to an existing 10Mbps Ethernet network. Its internal

cache buffers the traffic from the higher bandwidth 100Mbps

segment to the 10Mbps segment. If you later decide to make

both segments 100Mbps Fast Ethernet, the ports of the switch

will automatically sense the change and adjust to 100Mbps

operation (for RJ-45 ports only).

In addition to the benefits of integrating 10Mbps and 100Mbps

networks, this switch is also useful for segmenting networks

that is bogged down with excess traffic. By splitting a network

into several segments and bridging them, you can cut the

traffic load on your network and reduce collisions on each

segment, especially if you can minimize intersegment traffic by

placing users and devices that normally talk to each other on

the same segment.

This switch fully complies with IEEE802.3u, 100BASE-TX/FX,

and IEEE802.3, 10BASE-T standards. It features "wire-speed”

switching mechanisms as well as the ability to filter local traffic,

collisions, and error packets to maximize network performance.

This eight-port switch also facilitates an affordable and efficient

migration path to 100Mbps Fast Ethernet and can continue to

enhance your network's performance even if you upgrade your

Fast Ethernet Switch

6 Fast Ethernet Switch

User’s Guide

existing network with standard Ethernet applications,

internetworking systems and client-side adapters to minimize

migration costs.

Fast Ethernet Switch

Fast EthernetSwitch 7

User’s Guide

Product Features

This eight-port switch provides the following features:

♦ Eight dual-speed 100BASE-TX/10BASE-T or 100BASE-FX

switching ports or 6 100BASE-TX/10BASE-T + 2 100BASE-

FX switching ports

♦ Full- and Half-Duplex capability on every TX ports.

♦ Auto MDIX on every TX ports.

♦ Dip Switch for Full- and Half-Duplex setting on Fiber ports.

♦ Designed in compliance with IEEE802.3, 10BASE-T,

IEEE802.3u, 100BASE-TX and 100BASE-FX standards.

♦ Supports 802.3x Flow Control pause packet for Full-Duplex

in case buffer is full.

♦ Supports Back Pressure function for Half-Duplex operation

in case buffer is full.

♦ Supports Store & Forward architecture and performs

forwarding and filtering at non-blocking full wire speed.

♦ Broadcast Storming Filter function.

♦ Comprehensive array of LED indicators that communicate

the status of the switch and troubleshooting information.

Packing List

When you unpack the switch, you should find the items listed

below. Please inspect the contents, and report any apparent

damage or missing items immediately to your authorized

reseller.

The Eight-port Switch

User’s Manual

AC power cord

Fast Ethernet Switch

8 Fast Ethernet Switch

User’s Guide

Front Panel

The front panel of the switch has eight ports and an array of LED

indicators to provide you with instant feedback on the status of

the switch.

Figure 1: Front Panel

Ports

The TX ports of the switch automatically senses and adapts itself

to the presence of both 10BASE-T and 100BASE-TX network

standards. The switch can auto MDIX on any TX ports,

provide easy uplink with any TX port. For 100BASE-FX ports,

since the ports are fiber, they are capable of accepting

100BASE-FX connections only.

When connects to a 100BASE-TX network, the ports operate at

100Mbps in half-duplex mode and 200Mbps in full-duplex

mode. When connects to a 10BASE-T network, the ports

operate at 10Mbps in half-duplex mode and 20Mbps in

full-duplex mode. With 100BASE-FX ports, when it connects

to a 100BASE-FX network, the ports operate at 100Mbps in

half-duplex mode and 200Mbps in full-duplex mode.

Fast Ethernet Switch

Fast EthernetSwitch 9

User’s Guide

The maximum range of a 100BASE-TX network connected to the

switch is 100 meters with Category 5 shielded twisted-pair and

unshielded twisted-pair (STP/UTP) cable. A 10BASE-T

network may range up to 100 meters with Category 3, 4, or 5

STP/UTP cable. As for the length of FX fiber link between a

switch and Data Terminal Equipment, FX is capable to span at

least 2 Kilometers using 62.5/125-micron fiber-optic cable in

full-duplex mode and 412 meters in half-duplex mode.

The following table summarizes the port and cable specifications

for this switch.

Speed Connector Port Speed

Half/Full

Duplex

Cable

00BASE-TX RJ-45 00/200 Mbps 100M, Category 5

STP/UTP

10BASE-T RJ-45 10/20 Mbps

00M, Category 3, 4,

or 5 STP/UTP

00BASE-FX

traigh

-tip (ST

or SC)

00/200 Mbps 62.5/125 micron

Multi-Mode

fiber-optic cable

Fast Ethernet Switch

10 Fast Ethernet Switch

User’s Guide

LEDs

The array of LED indicators on the front panel conveys status

and configuration information to help you monitor and

troubleshoot the switch.

Figure 2: LED & Button Indicators

nPort Status

10/100BASE-TX Ports

Each port has an array of three LEDs to show status information.

The LEDs are identified by a corresponding array of captions

located below the LEDs on the front panel.

LNK/ACT: The link indicator is the top LED. It is illuminated

whenever the port is connected to another

working networked device.

The LED flashes when the port is transmitting

or receiving data.

100: The middle LED comes on whenever the switch

detects that the corresponding port is connected

to a 100BASE-TX segment.

Andere Handbücher für TE100-S86FX

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere TRENDnet Schalten Handbücher

TRENDnet

TRENDnet TE100-S810Fi - Switch Bedienungsanleitung

TRENDnet

TRENDnet TE-500 Bedienungsanleitung

TRENDnet

TRENDnet TE100-S50g Bedienungsanleitung

TRENDnet

TRENDnet TPE-80WS - Web Smart PoE Switch Bedienungsanleitung

TRENDnet

TRENDnet TEG-S5 Bedienungsanleitung

TRENDnet

TRENDnet TE-800 Bedienungsanleitung

TRENDnet

TRENDnet TE100-S16R Bedienungsanleitung

TRENDnet

TRENDnet TL2-G244 Bedienungsanleitung

TRENDnet

TRENDnet TPE-T80H Bedienungsanleitung

TRENDnet

TRENDnet TI-PG80 Bedienungsanleitung

TRENDnet

TRENDnet TEG-2248WS - Gigabit Web Smart Switch Bedienungsanleitung

TRENDnet

TRENDnet TO-PG541 Bedienungsanleitung

TRENDnet

TRENDnet TPE-224WS - Web Smart PoE Switch Bedienungsanleitung

TRENDnet

TRENDnet TK-217i Bedienungsanleitung

TRENDnet

TRENDnet TL2-F7120 Bedienungsanleitung

TRENDnet

TRENDnet TEG-S8g Bedienungsanleitung

TRENDnet

TRENDnet TPE-S88 - Web Smart PoE Switch Bedienungsanleitung

TRENDnet

TRENDnet TE100-DX16E Bedienungsanleitung

TRENDnet

TRENDnet TU2-400 Bedienungsanleitung

TRENDnet

TRENDnet TK-200 Bedienungsanleitung

TRENDnet

TRENDnet TK-408K Bedienungsanleitung

TRENDnet

TRENDnet TEG-448WS - Switch Bedienungsanleitung

TRENDnet

TRENDnet TFU-430 Bedienungsanleitung

TRENDnet

TRENDnet 1602R - KVM Switch - PS/2 Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
