TRENDnet TEG-S16Dg Bedienungsanleitung

The 16-Port Gigabit GREENnet Switch, model TEG-S16Dg, provides high

bandwidth performance, ease of use, and reliability, all while reducing

power consumption by up to 70%*.

GREENnet technology automatically adjusts power voltage as needed,

resulting in substantial energy savings. Embedded GREENnet technology

works right out of the box with no management requirement.

Boost office network efficiency and eliminate network congestion with

Gigabit speeds and a total switching capacity of 32Gbps with Full-Duplex

mode. A built in universal power supply reduces cable clutter and

diagnostic LEDs help with network troubleshooting. Plug and Play this

sturdy metal switch for reliable high-speed network connectivity.

TEG-S16Dg (V1.0R)

16-Port Gigabit GREENnet Switch

Features

• 16 x 10/100/1000Mbps Auto-MDIX Gigabit Ethernet ports

• On / off power switch

• Features a 32Gbps forwarding capacity

• Internal power supply reduces clutter GREENnet technology reduces electrical power consumption when:

a. Ethernet port is not in use

b. Connected device is turned off

c. Connected device is in power-saving mode

d. Based on Ethernet cable length

• IEEE 802.3x Flow Control for full-duplex mode

• Back pressure Flow Control for half-duplex mode

• Store-and-Forward switching architecture with non-blocking wire-speed performance



• Integrated address look-up engine with an 8 K MAC address table, and 2 MBits RAM data buffer

• Operates and maximizes packet filtering and forwarding rate

• Jumbo Frame support up to 9216Bytes

• Sturdy metal housing

• Diagnostic LEDs and Plug & Play support

• 3-year limited warranty

gigabit

TEG-S16Dg

rev:09.18.2010

*Max power savings compared with conventional TRENDnet switches.

SPECIFICATIONS

Network Media

Standards

Data Rate

Protocol / Topology

Power Consumption

Switch Fabric

• IEEE 802.3 10Base-T; IEEE 802.3u 100Base-TX

• IEEE 802.3ab 1000Base-T; IEEE 802.3x Flow Control; IEEE 802.3az (draft 2.0)

• Ethernet: Cat. 5 up to 100 m • Fast Ethernet: Cat. 5 and 5e up to 100 m • Gigabit Ethernet: Cat. 5e and 6 up to 100 m

• Ethernet: 10Mbps/20Mbps (half/full-duplex) • Fast Ethernet: 100Mbps/200Mbps (half/full-duplex)

• Gigabit Ethernet: 2000Mbps (full-duplex)

• CSMA/CD, Star

• 7.2 Watts (max.)

• 16 x 10/100/1000Mbps Auto-MDIX RJ-45 ports

Hardware

Jumbo Frame Support • Up to 9216Bytes

Diagnostic LED

Power

Dimension

Weight

Temperature

Humidity

Certifications

• On / off power button

Interface

Power Button

• 2 MBits

Data RAM Buffer

• Power, Link/ACT, 100Mbps, 1000Mbps

• 100~240VAC, 50/60Hz Internal universal switching power

• 280 x 180 x 44 mm (11 x 7 x 1.7 in.)

• 1.5 kg (3.3 lbs.)

• Operating: 0° ~ 40° C (32° ~ 104° F) • Storage: -10° ~ 70° C (14° ~ 158° F)

• Max. 90% (non-condensing)

• CE, FCC

Filtering Table

• 32Gbps

• 8K entries

• Multi-Language Quick Installation Guide

CONTACT INFORMATION

RELATED PRODUCTS

PACKAGE CONTENTS

NETWORKING SOLUTIONS

• TEG-S16Dg

• Power cord (1.8m / 6ft.)

TEG-PCITXR

TEW-639GR

Gigabit PCI Adapter

300Mbps Wireless N Gigabit Router

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

1-888-326-6061

www.trendnet.com

TEG-S24Dg 24-Port 10/100Mbps GREENnet Swich

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

TEG-S16Dg (V1.0R)

16-Port Gigabit GREENnet Switch

Regular

Switch

GREENnet

Switch

Full Power

60m 100m20m

Reduces power consumption with shorter cable lengths

60m 100m20m

Reduces power consumption when devices are off

or in standby mode

Reduces power consumption of unused ports

less power on

offon

less power

70%

Savings

Power Meter

up to

70%

Savings

Power Meter

up to

70%

Savings

Power Meter

up to
