TRENDnet TK-207K - KVM Switch - USB Bedienungsanleitung
TK-207K
User’s Guide
Table of Contents
English ......................................................................................................
Troubleshooting ........................................................................................
1
1
2
4
5
1. Before You Start .................................................................................
2. How to Connect .................................................................................
3. Operation ..........................................................................................
Table of Contents
Version 01.05.2006
System Requirements
Application
TK-207K
User’s Guide
Utility CD-ROM
2 Sets of USB KVM Cables
Type A USB keyboard
Type A USB mouse
VGA or SVGA Compatible Monitor
Windows 98/ME/2000/XP/2003, Linux, or Mac O.S.
Package Content
1. Before You Start
English
1
2-Port USB
KVM Switch
(TK-207K)
PC 1 PC 2
LCD Monitor
USB Keyboard USB Mouse
1. Turn off both computers and their
peripherals, and disconnect all
power cords.
3. Use the provided KVM cables to
connect your PC to your KVM
switch.
2. How to Connect
English
2
2. Connect the shared keyboard,
monitor, and mouse to the KVM
Switch's console port.
Note: The TK-207K USB KVM Switch does not require any drivers or software.
5. Press the face panel button on the
KVM Switch to select the second
computer.
Your installation is now complete.
English
3
4. Turn ON the first computer and
wait until startup completes.
PC 1
PC 2
6. Turn ON the second computer and
wait until startup completes.
Note: For PC switching, you can use the face-panel buttons of the KVM Switch,
a hot-key command sequence via keyboard, or the Client Switch Utility
(Windows only). For more detail on the Client Switch Utility, please consult the
Client Switch Utility manual on the CD-ROM.
After pressing the ScrLk key, you have 2 seconds to press the ScrLk key
again. If you do not press a key within 2 seconds, the switch will exit hot-key
mode.
3. Operation
English
4
Face-Panel Buttons
Hot-Key Command Sequence
Press the corresponding face-panel
button to select your PC.
Universal Hot-Key Command
Command Hot-Keys Description
Select PC ScrLk ScrLk
+Select the active PC channel,
PC Channel 1 or PC Channel 2.
Note:
Mac Users must note: Standard PC Keyboard mapping to MAC keyboard:
ScrLk ScrLkScrLk ScrLk
+ +
= =
= =
+C+F11
ScrLk ScrLk
+ + F10 ScrLk ScrLk
+ + F12
F13 F15
F14
Q1:
A1:
Q2:
A2:
Q3:
A3:
Q4:
A4:
Q5:
A5:
Where is the power supply? I did not find one in the box.
The TK-207K does not require a power supply. It draws power from
your computer's USB connection. As long as your KVM switch is connected to
the USB port, it will receive the necessary power to function.
I have the KVM switch connected properly, but my keyboard and mouse don't
work.
Please make sure your USB port is working properly by testing it with your
other USB devices. Once you confirm that the USB port is functional, please
reboot your computers, and try to use the KVM switch again.
Can I connect and disconnect the USB cables while the computers are turned
on?
Yes, you can connect or disconnect the USB cables while the computers are
turned on because the USB interface is Plug-and-Play and Hot-Pluggable.
Will the KVM switch remember the keyboard settings between computers?
Yes, the KVM switch will remember the keyboard settings when switching
between your computers. (i.e.: Cap lock, Num key, etc.)
How do I switch from one computer to another with the KVM switch?
PC User: Push Buttons, Hot-Key Commands or Client Switch Utility
Mac User: Push Buttons
Linux User: Universal Hot-Key Commands
If you have further questions, please contact TRENDnet’s Technical Support
Department.
Certifications
This equipment has been tested and found to comply with FCC and CE Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received.
Including interference that may cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE
CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS
COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
5
Troubleshooting
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you
Local Authority or Retailer for recycling advice.
Limited Warranty
TRENDnet warrants its products against defects in material and
workmanship, under normal use and service, for the following lengths of
time from the date of purchase.
TK-207K - 2 Years Warranty
If a product does not operate as warranted above during the applicable
warranty period, TRENDnet shall, at its option and expense, repair the
defective product or part, deliver to customer an equivalent product or
part to replace the defective item, or refund to customer the purchase
price paid for the defective product. All products that are replaced will
become the property of TRENDnet. Replacement products may be new
or reconditioned.
TRENDnet shall not be responsible for any software, firmware,
information, or memory data of customer contained in, stored on, or
integrated with any products returned to TRENDnet pursuant to any
warranty.
There are no user serviceable parts inside the product. Do not remove
or attempt to service the product by any unauthorized service center.
This warranty is voided if (i) the product has been modified or repaired
by any unauthorized service center, (ii) the product was subject to
accident, abuse, or improper use (iii) the product was subject to
conditions more severe than those specified in the manual.
Warranty service may be obtained by contacting TRENDnet office within
the applicable warranty period for a Return Material Authorization (RMA)
number, accompanied by a copy of the dated proof of the purchase.
Products returned to TRENDnet must be pre-authorized by TRENDnet
with RMA number marked on the outside of the package, and sent
prepaid, insured and packaged appropriately for safe shipment.
6
WARRANTIES EXCLUSIVE: IF THE TRENDnet PRODUCT DOES NOT
OPERATE AS WARRANTED ABOVE, THE CUSTOMER'S SOLE
REMEDY SHALL BE, AT TRENDnet'S OPTION, REPAIR OR
REPLACEMENT. THE FOREGOING WARRANTIES AND REMEDIES
ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES,
EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF
LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
TRENDnet NEITHER ASSUMES NOR AUTHORIZES ANY OTHER
PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN
CONNECTION WITH THE SALE, INSTALLATION MAINTENANCE OR
USE OF TRENDnet'S PRODUCTS.
TRENDnet SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS
TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED
DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY
CUSTOMER'S OR ANY THIRD PERSON'S MISUSE, NEGLECT,
IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED
ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE
BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT,
FIRE, LIGHTNING, OR OTHER HAZARD.
LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW
TRENDnet ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY
LIABILITY, WHETHER BASED IN CONTRACT OR TORT (INCLUDING
NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT,
SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF
REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF
INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT
OF OR IN CONNECTION WITH THE SALE, INSTALLATION,
MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION
OF THE POSSIBILITY OF SUCH DAMAGES, AND LIMITS ITS LIABILITY
TO REPAIR, REPLACEMENT, OR REFUND OF THE PURCHASE PRICE
PAID, AT TRENDnet’S OPTION. THIS DISCLAIMER OF LIABILITY FOR
DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED
HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.
Governing Law: This Limited Warranty shall be governed by the laws of
the state of California.
AC/DC Power Adapter, Cooling Fan, and Power Supply carry 1 Year
Warranty
7
Copyright ©2006. All Rights Reserved. TRENDnet.
3135 Kashiwa Street
Torrance, CA 90505
USA
TRENDnet Technical SupportTRENDnet Technical Support
US/Canada Support Center
Tech Support Hours
7:30am - 6:00pm
Pacific Standard Time
Monday - Friday
Contact
Telephone: 1(888) 777-1550
Fax: 1(310) 626-6267
Email: [email protected]
European Support Center
Contact
Tech Support Hours
Telephone:
Deutsch :+49 (0) 6331 / 268-460
Français :+49 (0) 6331 / 268-461
0800-907-161 (numéro vert)
Español :+49 (0) 6331 / 268-462
English :+49 (0) 6331 / 268-463
Italiano :+49 (0) 6331 / 268-464
Dutch :+49 (0) 6331 / 268-465
Fax: +49 (0) 6331 / 268-466
8:00am - 6:00pm
Middle European Time
Monday - Friday
Product Warranty RegistrationProduct Warranty Registration
Please take a moment to register your product online.
Go to TRENDnet’s website at http://www.trendnet.com
