300Mbps Wireless N ADSL 2/2+ Modem Router

TEW-658BRM(V1.0R)

The 300Mbps Wireless N ADSL 2/2+ Modem Router, model TEW-

658BRM, provides both Internet access and a high-performance wire-

less n network in a single solution.

No need to buy a separate modem and router. Install this device quickly

and browse the Internet, download ﬁ les, and talk online with the latest

in wireless n technology.

Connect computers, game consoles, media players, and DVRs to the

built-in 4-port switch. The latest in wireless encryption and a double

ﬁ rewall protect your valuable data. WMM® Quality of Service (QoS)

technology prioritizes online gaming, Internet calls, and video streams.

One-touch Wi-Fi Protected Setup (WPS) connects WPS peripheral

devices at the touch of a button.

FEATURES

•4x10/100MbpsAuto-MDIXRJ-45LANports

•1xRJ-11WANport(Internet)

•On/offpowerbutton

•Wi-FicompliantwithIEEE802.11nstandard

•BackwardscompatiblewithIEEE802.11b/gdevices

•2xxed2dBiantennasforhighspeedperformanceandexpansivecoveragewithMIMOantennatechnology

•Router+ModemorModemOnlymodes

•CompliantwithADSL,ASDL2,andADSL2+standards

•Supportsupto8PVCs

•VLANsupportandQualityofService(QoS)technologyprioritizesgaming,Internetcalls,andstreamingvideo

•AdvanceFirewallprotectionwithNetworkAddressTranslation(NAT)andStatefulPacketInspection(SPI)

•InternetAccessControlviaIP/MACAddressFilteringandDomain/KeywordFiltering

•Wi-FiMultimedia(WMM)QualityofService(QoS)dataprioritization

•Advancedwirelessencryption:64/128bitWEP,WPA/WPA2-RADIUS,andWPA/WPA2-PSK

•OnetouchwirelessconnectionusingtheWPSbutton

•UniversalPlugandPlay(UPnP)

•EasyWebbrowsercongurationandremotemanagement

•SupportsTR069remotemanagementandcommandlineinterface(CLI)viatelnet

•3-yearlimitedwarranty

*MaximumwirelesssignalratesarereferencedfromIEEE802.11theoreticalspecications.Actualdatathroughputandcoverage

willvarydependingoninterference,networktrafc,buildingmaterialsandotherconditions.

300Mbps Wireless N ADSL 2/2+ Modem Router

TEW-658BRM(V1.0R)

• ComplieswithADSLstandards

•ANSIT1.413Issue2

•G.992.1(G.dmt,AnnexA)

•G.992.2(G.lite)

•ComplieswithADSL2standard

•992.3(G.dmt.bis)

•ComplieswithADSL2+standard

•G.992.5AnnexM

TEW-658BRM

rev: 02.17.2011

SPECIFICATIONS

HARDWARE

Standards • IEEE802.3u,IEEE802.11b,IEEE802.11g,IEEE802.11n

RJ-11 Port

(ADSL line Interface)

ATM • VCandLLCMultiplexing•Bridged/RoutedEthernetoverATM(RFC1483/2684)•OAMF4/F5loop-back

• PPPoverATM(RFC2364)•PPPoverEthernet(RFC2516)•ATMTrafcQoS(UBR,CBR,rt-VBR,nrt-VBR)

Management • WebbasedConguration(HTTP)•CommandLineInterface(CLI)viaTelnet•TR-069RemoteManagement

• IGMPv1/v2Support•SWupgrade

LAN • 4x10/100MbpsAuto-MDIXports

Button • Power:On/offpowerbutton•WPS:EnablesWi-FiProtectedSetup(WPS)function•Reset:Resettofactorydefaults

Firewall • NAT,SPI,ContentFilter;IP,MAC,Domain,andKeyword

LED Indicator • Power,LAN1~LAN4,WLAN,ADSLandInternet,WPS

Power Adapter • 12VDC,1Aexternalpoweradapter

Power Consumption • 8.4watts(max)

Dimension (L x W x H) • 201x116x31mm(8x4.6x1.2in.)

Weight • 301g(10.6oz)

Temperature • Operating:0°~40°C(32°~104°F)•Storage:-10°~70°C(14°~158°F)

Humidity • Max.95%(non-condensing)

Certications • CE,FCC

Wireless

Frequency • 2.415~2.484GHzband

Modulation • DBPSK/DQPSK/CCK/OFDM(BPSK/QPSK/16-QAM/64-QAM)

Antenna • 2x2dBixeddipoleantennas

Data Rate • 802.11b:upto11Mbps•802.11g:upto54Mbps•802.11n:upto300Mbps

Security • WEP(HEX/ASCII):64/128-bit•WPA(AES/TKIP):WPA/WPA2-RADIUS,WPA-PSK/WPA2-PSK

Output Power • 802.11b:15dBm(typical)•802.11g:12dBm(typical)•802.11n:11dBm(typical)

Receiving Sensitivity • 802.11b:-80dBm(typical)@11Mbps•802.11g:-65dBm(typical)@54Mbps•802.11n:-64dBm(typical)@300Mbps

Channels • 1~11(FCC),1~13(ETSI)
