TRENDnet TEW-673GRU Bedienungsanleitung
TEW-673GRU
1.01
Quick Installation Guide
Table of Contents
Version 12.21.2009
English 1
1. Before You Start
2. Hardware Installation 2
3. Configure the Wireless Router 4
4. Installing the Utility 8
5. Printing 10
6. Scanning 11
7. Storage 12
1
Troubleshooting 13
ENGLISHFRANÇAISDEUTSCHESPAÑOL
ÐÓÑÑÊÈÉ
1. Before You Start
Package Contents
?
?CD-ROM (Utility and User's Guide)
?Multi-Language Quick Installation Guide
?Cat. 5 Ethernet cable (1.5m / 5ft.)
?AC Power Adapter (12V DC, 2A)
TEW-673GRU
System Requirements
1
Note:
1. Verify that any software that is required to operate your USB device is installed
before installing the TEW-673GRU.
2. Do not install the TEW-673GRU utility and connect any USB devices to the
TEW-673GRU until instructed to do so.
3. The TEW-673GRU utility must be installed on each computer in order to use
any USB device that is connected to the network hub.
4. The TEW-673GRU does not support USB hubs.
?
?
?
?
A computer with a wired or wireless network adapter properly installed
Web Browser: Internet Explorer (5.0 or higher)
Broadband Internet
Installed Cable or DSL Modem
ENGLISHFRANÇAISDEUTSCHESPAÑOL
ÐÓÑÑÊÈÉ
2. Hardware Installation
2. If you plan on connecting a multi-function
printer to the USB port on the TEW-673GRU,
install the printer drivers on your computer.
Then shutdown the printer and disconnect the
printer from your computer.
Note: Please refer to your printer's manual for
printer installation instructions.
2
Note: Gather all information related to your Internet Connection before you
start. If necessary, contact your Internet Service Provider (ISP).
Cable/DSL Modem
Internet
1. Verify that you have an Internet connection
when connecting your computer directly to the
Cable or DSL modem. Open your browser
(e.g. Internet Explorer) and type in a URL (e.g.
http://www.trendnet.com) in the address bar.
5. Connect one end of a RJ-45 cable to one of the
TEW-673GRU's LAN ports. Connect the other
end of the cable to the computer's Ethernet
port.
3. Connect one end of a RJ-45 cable to the
TEW-673GRU's WAN port. Connect the other
end of the cable to your modem.
ENGLISHFRANÇAISDEUTSCHESPAÑOL
ÐÓÑÑÊÈÉ
3
8. Verify that the following panel lights are on:
Power, LAN, WAN, WLAN and USB.
5. Connect the 3dBi detachable antennas to the
TEW-673GRU.
6. Connect the USB printer or USB storage device
to a USB port on the TEW-673GRU.
7. Connect the AC Power Adapter to the wireless
router and then to a power outlet.
ENGLISHFRANÇAISDEUTSCHESPAÑOL
ÐÓÑÑÊÈÉ
4
Note: It is recommended that you configure the Wireless Router from a wired computer.
1. Open your web browser, type
http://192.168.10.1 in the Address bar, and
then press Enter.
2. Enter the User Name and Password, and then
click Login.
User Name: admin
Password: admin
3. Configure the Wireless Router
3. The Wizard will automatically appear. Click
Wizard if the Wizard does not automatically
appear.
4. Click Next.
ENGLISHFRANÇAISDEUTSCHESPAÑOL
ÐÓÑÑÊÈÉ
5
6. Select your Time Zone and then click Next.
5. Enter a Password, verify the Password and
then click Next. By default, the Password is
admin.
7. Click Next. Note: Do not change default
settings unless it is conflicting with your existing
hardware.
8. Configure the settings based on information
provided by your ISP. Follow the wizard
instructions to complete the configuration.
Note: Each Internet Connection type may have
different options.
ENGLISHFRANÇAISDEUTSCHESPAÑOL
ÐÓÑÑÊÈÉ
6
Note: It is recommended that you enable encryption on the wireless router. Please refer
to the User Guide on the User's Guide CD-ROM for information on setting up encryption
on the wireless router.
9. Enter the desired SSID. Then click Next. By
default, the SSID for 2.4GHz WLAN is
TRENDnet673N. By default, the SSID for 5GHz
WLAN is TRENDnet673A.
10. Click Restart.
11. Click Close.
12. Click OK.
ENGLISHFRANÇAISDEUTSCHESPAÑOL
ÐÓÑÑÊÈÉ
7
Your Installation is complete
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.trendnet.com/register
Thank you for choosing TRENDnet.
For detailed information regarding the configuration and advanced settings,
please refer to the Troubleshooting section, User's Guide on the Utility CD-ROM, or
TRENDnet's website at http://www.trendnet.com.
TEW-673GRU’s
13. Open up your browser and enter in a URL
(e.g. www.trendnet.com) to verify that you
have Internet connection.
ENGLISHFRANÇAISDEUTSCHESPAÑOL
ÐÓÑÑÊÈÉ
8
4. Install the Utility
Windows 7 / Vista / XP / 2000
Note:
1. Before installing the utility, install the printer drivers on your computer. Then
shutdown the printer and disconnect the printer from your computer. Please refer to
your printer's manual for printer installation instructions.
2. For Mac OS X (10.1~10.4) instructions, please refer to the User's Guide on the Utility
CD-ROM.
1. Insert the Utility CD-ROM into your computer's
CD-ROM Drive.
2. Click Run Autorun.exe
(Windows 7/ Vista only).
3. Click Install Utility.
