PEGASUS

TREADMILL

CARE INSTRUCTIONS AND ASSEMBLY MANUAL

CAUTION

READ ALL PRECAUTIONS AND

INSTRUCTIONS IN THIS MANUAL

BEFORE USING THIS EQUIPMENT

KEEP THIS MANUAL FOR

FUTURE REFERENCE

CALL

08-93015557 www.trojanﬁ tness.com.au

1458AU-3

INDEX

SAFETY INSTRUCTION 3

BEFORE YOU BEGIN 4

HARDWARE LIST 5

ASSEMBLY STEP 6

COMPUTER FUNCTION 8

FITNESS TIPS AND TRCHNIQUES 9

CONDITIONING GUIDELINES 10

WARM-UP AND COOL-DOWN 11

PART LIST 12

EXPLODED DRAWING 13

TROJAN 1 YEAR LIMITED WARRANTY 14

TROJAN REPAIRS PROCEDURE 15

PROOF OF PURCHASE 16

1458AU-4

SAFETY INSTRUCTION

WARNING :

Safety Instruction before using the TROJAN PEGASUS TREADMILL.

To reduce the risk of serious injury, read the following.

1. Use the TROJAN PEGASUS TREADMILL only on a level surface.

2. Keep children and pets away from this equipment at all times.

3. The TROJAN PEGASUS TREADMILL should not be used by persons weighing more than 110kgs.

4. The TROJAN PEGASUS TREADMILL should be used by only one person at a time.

5. Be careful to maintain your balance while using, mounting, dismounting, folding, unfolding or assembling the TROJAN

PEGASUS TREADMILL, loss of balance may result in a fall and serious bodily injury.

6. Use the TROJAN PEGASUS TREADMILL only as described in the manual.

7. Do not attempt to adjust the back rest cushion while you are on the TROJAN PEGASUS TREADMILL.

8. Before using this equipment to exercise, always do stretching exercises to properly warm up.

9. Always make sure all bolts and nuts are tightened prior to each use.

WARNING

Before starting any exercise or conditioning program you should consult with your personal physician to see if you

require a complete physical exam. This is especially important if you are over the age of 35, have never exercised before,

are pregnant, or suffer from any illness.

1458AU-5

BEFORE YOU BEGIN

Thank you for choosing the TROJAN PEGASUS TREADMILL. We take great pride in producing this quality product and

hope it will provide many hours of quality exercise to make you feel better, look better and enjoy life to its fullest.

Yes, it’s a proven fact that a regular exercise program can improve your physical and mental health. Too often, our busy

lifestyles limit our time and opportunity to exercise. TROJAN PEGASUS TREADMILL provides a convenient and simple

method to begin your assault on getting your body in shape and achieving a healthier lifestyle.

Before reading further, please review the drawing below and familiarize yourself with the parts that are labeled.

• Read this manual carefully before using the TROJAN PEGASUS TREADMILL.

Console

Safety Key

Speed Adjutment Switch

Handpulse

Incline Adjustment Switch

Handgrip Tube

Handrail

Running Belt

Wheel

Main Frame

1458AU-6

HARDWARE LIST

NOTE :

The described parts are all you need to assemble this machine.

Before starting assembly, please check the hardware packing to make sure they are included.

No. Description Q’ty

Curved Washer (ø5/16” x 19 x 1.5T)

Button Head Socket Screw (5/16” x15m/m)

Phillips Head Screw (M5 x 15m/m)

Safety Key

No. Description Q’ty

Lubricant

Combination M5 Allen Wrench & Phillips

Head Screwdriver

Allen Wrench (M6)

1458AU-7

ASSEMBLY STEP

1458AU-8

Recheck

all bolts and nuts are

tightened securely

before use the machine

ASSEMBLY STEP

STEP 1

Remove all parts from the carton.

STEP 2

Connect Computer Cable (Lower) (38) with Computer Cable (Middle) (37).

STEP 3

• Hand tighten Right and Left Handrails (4,5) into the Frame Base (2) with 8 pcs of5/16”x 15m/m

• Button Head Socket Screws (94) and 2pcs of 5/16” x 19 x 1.5T

• Curved Washers (95) by using the Combination M5 Allen Wrench & Phillips Screwdriver (97).

STEP 4

Connect Computer Cable (Middle) (37) with Computer cable (Upper) (36).

STEP 5

• Install the Console Support (6) into the Right and Left Handrails (4,5) with 6 pcs of 5/16” x15m/m Button Head

Socket Screws (94) 2pcs of 5/16” x 19 x 1.5T Curved Washers (95) byusing the Combination M5 Allen Wrench &

Phillips Screwdriver (97).

• Install Computer Cable (Upper) (36) into the Console (39).

• Install Speed Adjustment Switch W/Cable (25) into the Console (39).

• Install Incline Adjustment Switch W/Cable (26) into Console (39).

• Install Handpulse Cable (27-1) into Console (39).

STEP 6

Install the Console (39) onto Console Support (6) with 4 pcs of M5 x15m/m Phillips HeadScrews (96) by using the

Combination M5 Allen Wrench & Phillips Screwdriver (97).

1458AU-9

COMPUTER FUNCTION

Getting started:

Power the treadmill on by plugging it into an appropriate wall outlet, then turn onthe power switch located at the front

of the treadmill below the motor hood.Ensure that the safety key is installed, as the treadmill will not power on withoutit.

When the power is turned on, all the lights on the display will light for a shorttime. Then the Time and Distance

windows will display Odometer readings for ashort time. The Time window will show how many hours the treadmill has

been inuse and the Distance window will show how many miles (or Kilometers if thetreadmill is set to metric readings)

the treadmill has gone. Then a message willscroll across the dot matrix showing the current software version. The

treadmillwill then enter idle mode, which is the starting point for operation.

1458AU-10

COMPUTER FUNCTION

Quick-Start Operation

STEP 1

Press and release theStartkey to wake display up(if not already on).Note:Installing the tether key will also wake up the

console.

STEP 2

Press and release theStartkey tobegin belt movement,at 1.0kmph (0.6 mph), thenadjust to the desired speed using theFast

/ Slowkeys (console or hand rail). You mayalso use the rapid speed keys 2 through 12 to adjust the speed.

STEP 3

To slow tread-belt press and hold theSlowkey (console or hand rail) to the desiredspeed. You may also press the rapid

speed adjust keys, 2 through 12.

STEP 4

To stop the tread-belt press and release theStopkey.

STEP 4

To stop the tread-belt press and release theStopkey.

Pause/Stop/Reset Feature

STEP 1

When the treadmill is running the pause feature may be utilized by pressing theStopkeyonce. This will slowly decelerate the

tread-belt to stop. The incline will go to zero percent.The Time, Distance and Calorie readings will hold while the unit is in

the pause mode.After 5 minutes the display will reset and return to the start up screen.

STEP 2

To resume your exercise, when in Pause mode, press theStart key. The speed and inclinewill return to their previous

settings.Pause is executed when theStopbutton is pressed once. If theStop key is pressed asecond time, the program will

end and a workout summary will be displayed. If theStopbutton is pressed a third time, the console will return to the idle

mode (start up) screen. IftheStop button is held down for more than 3 seconds the console will reset.

Incline Feature

• Incline may be adjusted anytime after belt movement.

• Press and hold theUp / Down keys (console or hand rail) to achieve desired level of effort. You may also choose a more

rapid increase / decrease by selecting desired key, 2 through 12,on left hand side of console (incline).

• The display will indicate incline percent as adjustments are made.

• Incline will remain in it’s position when display is turned off.
