Trust Start Series Bedienungsanleitung

www.trust.com

START-LINE

ACM-2300H

ACM-2300H BUILT-IN SWITCH

Item 71147 Version 1.0

Visit www.trust.com

for the latest instructions

USER MANUAL

MULTI LANGUAGE

5mm

0Com S N L

Com S N L

O S N L

COM

Wall switch

ACM-2300H

Wall switch

O S N L

COM

ACM-2300H

Wall switch

78.1

8.2 8.3

Com S N L

1 sec

0Com S N L

109

0Com S N L

UIT

1 SEC

OFF

ININ OUT

N N

0Com S N L

8 SEC 1 SEC

ACM-2300H BUILT-IN SWITCH

1. Disable mains power

Always turn OFF the mains power (In the meter closet) before you begin the installation or removal

of this product. The ACM-2300H can be used for either two wall switches connected with one lamp

(stairwell/hotel circuit) or for one single wall switch connected to one lamp.

2. Loosen ceiling lights

Remove the existing lighting/equipment from the ceiling, leaving the wires connected to the lighting.

Lighting/equipment may not exceed the maximum of 2300 watts. If there is no live wire present, it

must be pulled. Consult an electrician if in doubt.

3. Warning for stripping wires

3A. Make sure the wires are stripped for 5mm.

3B. When connecting the wires to the ACM-2300H make sure the stripped wires are pressed ﬁrmly

in the module, no exposed wires are visible and the wires cannot touch each other. This can cause a

short circuit.

4. Disconnect the switch wire and neutral wire

To install the ACM-2300H disconnect the switch wire and neutral wire of the lamp. (Disconnect

from terminal block or cut the wires if necessary) Consult an electrician if in doubt about wire

colours.

5. Connect the live wire and the neutral wire to a terminal block

(a) Connect the live wire from the ceiling box to a terminal block. Connect the other end of the live

wire also back into the same terminal block.

(b) Connect the neutral wire from the ceiling box to a dierent terminal block. Make sure other

Trust Smart Home receivers are placed at least 50 cm from the ACM-2300H to prevent interference.

6. Connect the switch wire and neutral wire of the lamp to the terminal block

(a) Connect the (black) switch wire from the ceiling box to the [S] contact.

(b) Connect the (blue) neutral wire from the lamp to the terminal block of the neutral wire. Connect a

new wire from the neutral terminal block on to the [N] contact.

ACM-2300H BUILT-IN SWITCH

(d) Connect two new live wires from the live wire terminal block to the [L] and [COM] contact.

(e) Tighten the terminal screws of the ACM-2300H.

This is the technical installation schematic of the ACM-2300H with two wall-switches (hotel/stairwell

circuit).

This is the technical installation schematic of the ACM-2300H with one wall-switch.

7. Enable mains power

Switch the mains power ON before proceeding with the installation.

Make sure no stripped parts of wires are touched after this step.

The LED indicator on the receiver will be lit for a few seconds when voltage is applied.

8.1 Activate pairing mode

Press for about 1 second (with a pointed object) on the Connect button to activate the pairing mode.

The pairing mode will be active for 15 seconds and the LED indicator on the receiver will ﬂash slowly.

8.2 Send an ON signal

While the LED indicator ﬂashes, press the ON button on a Trust Smart Home transmitter to pair the

transmitter to the ACM-2300H. (Or activate a Trust Smart Home sensor).

8.3 Pairing conﬁrmation

The LED on the module will blink 2x in order to conﬁrm that the code is stored. The receiver can store

up to 6 dierent transmitter codes in its memory per channel. The memory is retained when the

receiver is installed elsewhere or when there is a power failure.
