TRX GE-E1050 Bedienungsanleitung
G E - E 1 0 5 0
Read this manual completely before riding
Your Electric Scooter
Name
Telephone
Address
Purchase Date
Mobile Phone#
Product quality certification
HL CORP(SHEN ZHEN)/SPORTING GOODS DIVISION.
THE 3RD INDUSTRIAL AREA, BITOU VILLAGE,
SONG GANG TOWN, BAOAN DISTRICT,
SHE NZHEN 518105 P. R. CHINA
TEL:86-755-27130185 EXT 311
FAX:86-755-27130380
E-MAIL:sales-e@hlcorp.com.cn
Thanks for purchasing the Electric scooter product from our company,
there is 6 months warranty from the date you purchase .Any un- void
disaster,such as earth quake...etc to cause the damage of this vehicle
will not be covered under the warranty. The Ruber tire and PU wheel
and braking stopper is the consuming product and will not cover under
the warranty.
TECHNICAL SPECIFICATION.................1
WARNING..............................................2
LIST OF PARTS......................................3
ASSEMBLING........................................4-6
RIDING THE SCOOTER..........................7
MAINTENANCE......................................8
8 1
GE-E1050
Motor power:150W side motor x2
Battery:12V/7AH x3
Charger:100~240V(50~60HZ) 1.5A
Charge time:6~8hours
Wheel:16"rubber tire(Front)
8"airless tire(Rear)
Max.speed:12MPH
Average travel distance:12~18miles
Max. Load capacity:220lbs
Product size:
36~3/4" x20~3/4" x44~3/4"~47 ~1/2"
N.W.: 58.7 lbs
G.W.: 66.1 lbs
CAUTION-ELECTRICALLY
OPERATED PRODUCT
2
WARNING & SAFETY INSTRUCTION RIDING THE TRX SCOOTER
7
36
16. 17.Thumb throttle Brake
ON-OFF Switch
Handlebar
Tool bag
Fuse(inside battery bag)
1
43 2
5
1
2
3
1 6
1
1 7
45
1.Before you ride the scooter for the first time, you must completely charge the
batteries for 6-8 hours.
Quick
release
AS S E MB L I N G T H E SC O O TE R
