UbiBot SP1 Bedienungsanleitung
Wireless Smart Plug SP1
01
Note: The sensor interface is a 3.5 mm audio jack.
Introduction
Package List: Smart Plug SP1 (×1) User Guide (×1)
Indicator
Power Button
Socket
Sensor interface (RS485)
Sensor Interface (DS18B20)
02
When the indicator flashes alternately yellow and blue, it means the device
is in the setup mode.
When the indicator is constantly blue, the device is powered on and the
network is connected.
When the indicator is constantly yellow, the device is powered on but the
network is disconnected.
When the indicator is off, the device is powered off.
When the indicator flashes blue, the device is resetting to default settings.
When the indicator flashes yellow, it means there are hardware errors.
Press the power button once to turn on/off the device.
Press and hold the button for 5 seconds to enter the setup mode.
Under“setup mode”, press the button three times in quick succession to
reset the device.
Indicator Status & Operations
03
Launch the App and log in. Please make sure your phone's Bluetooth is
enabled and then click "+" to add a device.
STEP 1.
Enter device WiFi setup mode: Plug the socket into the power supply, then
press and hold the button for 5s until the indicator light flashes alternately
yellow and blue. Follow the instructions on APP to complete the setup.
STEP 2.
If the setup fails, please make sure that WiFi is 2.4 GHz and the password is entered
correctly.
Quick Start on Mobile Phone
04
Insert a Nano-SIM card in the correct direction as instructed.
STEP 1.
Launch the App and log in. Please make sure your phone's Bluetooth is
enabled and then click "+" to add a device. Please follow the instructions
on APP to complete the setup process.
STEP 2.
Mobile Data* Setup
Nano-SIM Slot
*Text marked with asterisk means the feature depends on the specific model
purchased.
05
RS485 Probe DS18B20 Probe
Plug the external sensor into Smart Plug.
(sensors need to be purchased separately)
Sensor Connection
06
①
②
③
④
⑤
⑥
⑦
This device is warranted to be free of defects in materials and workmanship
for a period of up to one year from the original purchase date.
Issues arising after the warranty period has ended.
Malfunction or damage caused by improper handling or not operating the device
according to the instructions.
Accidental or man-made product damage.
Natural wear and aging of materials.
Failure or damage caused by unauthorized removal of the product.
Failure or damage caused by .
Other faults or damage not caused by product design, technology, manufacturing,
quality, etc.
Warranty Information
The following situations are not covered by the warranty:
force majeure
