UniGuard BT01 Bedienungsanleitung

UniGuard Technology Limited

-www.uniguardgps.com

BT01 Taillight Bike GPS Tracker

User Manual

UniGuard Technology Limited

-www.uniguardgps.com

1 Product Instructions

It is a taillight bike GPS Tracker, built-in GPS Antenna and GSM Antenna,

Size: 70*55*20 mm, Weight: 75g, it can send bike location and status to

mobile and Internet. It can track the bikes remotely. Track the bike on the

computer Web and mobile APP.

UniGuard Technology Limited

-www.uniguardgps.com

1.1 Features

1 Real time location tracking

2 Tracking by Web/APP/SMS command

3 Over speed alarm

4 Vibration alarm

5 Low power alarm

6 Remote voice monitoring

1.2 Specifications

Item

Descriptions

Dimension

70*55*25 mm

Weight

75g

GSM Frequency

850/900/1800/1900Mhz

GPS Module

MTK2503D

GPS Sensitivity

-159dBm

GPS Accuracy

10m

Time to first fix

Cold start 32s

Warm start 30s

Hot start 1s

Working current

35mA

Battery

Built-in 3.7V 1500mAh

Storage Temperature

-40°C to +85°C

Working Temperature

-20°C to +55°C

Working Humidity

5%--95% non-condensing

LED Light

Blue for GPS, Green for GSM

UniGuard Technology Limited

-www.uniguardgps.com

1.3 Installation Figure

1.3.1 Check products to see if there is any accessory missing. Please

1.3.2 Insert SIM card

Don't insert the SIM card up-side-down. Make sure the SIM card with

GPRS service.

If the SIM card has been inserted, but it requires you to input SIM PIN,

please close the SIM PIN function under the instruction of your mobile phone

user ’s manual. Make sure the SIM card account has enough credit.

1.3.3 LED Indicator

LED

Status

Explanation

Green-GSM

Flash

GPRS OK

Initialize GSM Signal

OFF

GSM Standby

Blue-GPS

Flash

GPS OK

Search GPS Signal

OFF

GPS Not Working

UniGuard Technology Limited

-www.uniguardgps.com

2 SMS Operation Instruction

Function

Command

Reply / Remarks

Open SMS Reply

dxhf,1

No Reply (Without sending this, device does not reply to

SMS command)

Smart Tracking Mode

mode,1,10

Set mode1 successfully

(Device updates at 20 secs interval. When there is shock,

otherwise it goes to sleep in 3 mins and does not update.)

Fixed Time Tracking

upload123456 X

Upload ok. X=10 to 300. Unite is second.

Device updates at interval of 10 secs always.)

Open vibration alarm

vibalm,1

Open vibration alarm successfully.

Set Vibration level

vib,3

Set vibration sensitivity successfully

Vibration call alarm

vibcall123456

Vibrate phone alarm set ok.

Set alarm number

sos,a,Tel

SOS number added successfully.

Reset device

reset,1

Device will restart after 10s

Restore device

factory,1

Will restore factor setting after 10s

Check device status

check123456

Set APN

apn123456 apn

E.g apn123456 cmnet

apnuser123456 user

E.g apnuser123456 user

apnpasswd123456 pw

E.g apnpasswd123456 1234

Set Domain and Port

SZCS,123456,DOMAIN=gpspos.net:8000

Check location

google

Google map link

Low power alarm

low,1

low,0

Set battery low level alarm success

Close battery low level alarm success

LED setup

ledset,1

ledset,0

Turn on led.

Turn off led.

UniGuard Technology Limited

-www.uniguardgps.com

3 GPS tracking system on website

4.1Login www.gpspos.net to start web tracking service with your own

account

4.2 APP Download: Search GPSPOS at Appstore or Search POSGPS

at Google play to download it and use same account to login
