UniGuard Technology Limited

GSM/GPRS/GPS Tracker

LK720

User Manual

Car/Motorcycle GPS Tracking Device

1. Features

◇Vehicle/ motorcycle tracking

◇Real-Time Tracking

◇Cut fuel/Resume fuel

◇Power removal/Ignition/Vibrate alarm

◇Support angle upload location

◇Remote upgrade via OTA

◇One-Key cut fuel (Optional remote controller)

◇SOS alarm (Optional remote controller)

UniGuard Technology Limited

2. Specs.

Content

Specs.

Dim.

31*31*57mm

Network

GSM/GPRS

Frequency

850/900/1800/1900 MHz

GPS chipset

MTK high sensitivity chip

Location accuracy

<10 meters CEP

Time To First Fix(open sky)

Cold status <35s Hot status <1s

Working voltage

9-36VDC

GPRS Protocol

TCP/IP

Operating temp.

-20°C to +70°C

consumption

3mA~50mA

2. Install SIM Card

Insert Nano 2G GSM SIM card with activated GPRS data; Make sure

SIM card with full balance; If SIM card with PIN code, must remove it

advance. Insert SIM to power on device, Take off SIM to power off device.

3. Device light description

Light

Signal

Green

⚫Flashing at every 3s after connected server

⚫Always ON: no service

Blue

⚫Flashing 1 time per second if GPS located

⚫Light off: no GPS signal or sleep

4. Wires connection

Red: Battery+

Black: Battery -

UniGuard Technology Limited

Orange: Ignition wire

Green and Blue: Relay for cut fuel

UniGuard Technology Limited

5. SMS Command List

Check Google link

WHERE#

Set IP and Port

SERVER,0,www.gpspos.net,6006,0#

Set APN

APN, [apnname]# or

APN, [apnname],[user],[pwd]#

Check IP APN

IP#

Check Device Status

STATUS#

Check Device parameters

PARAM#

Reset Device

RESET#

Upload time interval

TIMER,T1,T2#

T1=5 ~ 18000seconds ACC ON time interval

T2=300 ~ 18000seconds ACC OFF time interval

Control Relay

RELAY,0# Resume fuel

RELAY,1# Cut fuel

Open Vibration alarm

SENALM,ON,M#

M=0～2 alarm methods

0 stands for only GPRS

1 stands for SMS+GPRS

2 GPRS+SMS+CALL

Close Vibration alarm

SENALM,OFF#

Open power off alarm

POWERALM,ON,M,2,2#

M=0～2

0 stands for only GPRS

1 stands for SMS+GPRS

2 GPRS+SMS+CALL

Close power off alarm

POWERALM,OFF#

ACC ON / OFF alarm

ACCONALM,ON,M#

M=0～2 alarm methods

0 stands for only GPRS

1 stands for SMS+GPRS

2 GPRS+SMS+CALL

ACCOFFALM,ON,M#

M=0～2 alarm methods

UniGuard Technology Limited

0 stands for only GPRS

1 stands for SMS+GPRS

2 GPRS+SMS+CALL

Set timezone

GMT,<A>,<b>,<c>#

For example: GMT,E,5,00# or GMT,W,6,00#

Add Center number

CENTER,A,Number#

Delete Center number

CENTER,D#

Activate voice monitor

monitor# (set center number firstly)

Cancel voice monitor

tracker#

Add SOS number

SOS,A,15012404563,,#

SOS,A,15012404563,15012404564,15012404567#

SOS alarm ON/OFF

SOSALM,A,M#

A=ON/OFF

M=0～2 alarm methods

0 stands for only GPRS. Default

1 stands for SMS+GPRS

2 GPRS+SMS+CALL

Auto activate arm mode

autoarm,1#

autoarm,0# (default)

The arming mode is automatically activated every time the

ACC is turned off for 10 minutes without moving or

vibrating. [The ACC detection line must be correctly

connected to the car]

Manual activate arm mode

Arm#

Disarm#

Anti-theft mode

After parking, manually send cut fuel command: relay,1#,

the car will cut off the fuel and repeat it 10 times

continuously. After 10 minutes, the GPS will automatically

resume fuel. Once the vehicle drives 400 meters, the

device will cut off the fuel again.

UniGuard Technology Limited

Remote Controller buttons features (optional):

Button

Function

Description

ARM

Cut fuel

Short Press to arm (buzzer beep in emergency)

Long Press for 3s to cut off fuel/oil.

DISARM

Resume fuel

Short Press to disarm (buzzer beep will be cancel).

Long press for 3s to recover fuel/oil.

Mute buzzer

SOS

Short Press , to turn off car finding buzzer beep.

Long Press for 3s for SOS alarm

Car Finding

Short Press to activate buzzer sound for car finding.

6. Web platform & Tracking APP

Website: www.gpspos.net APP name: GPSPOS

Default IMEI as user name, password 123456.
