Unitech MS920P Bedienungsanleitung

MS920P Quick Start Guide

The Unitech MS920P 2D Pocket Scanner 1. Flip the rubber cover up to expose the micro USB port on the scanner.

2. Plug the micro USB cable into the port on the scanner and into a free USB port of a host computer.

Charge for 4 hours.

Step 1:

connect and Charge

Test & Finish

Step 5:

Open a word processing program or app such as

Microsoft Word or Notepad on your host device.

Now scan the following barcode:

If the word “Unitech” appears on the screen

you have succesfully connected your scanner.

Congratulations!

Silence

Silence off * Silence on

silence MS920P TIPS

• The MS920P should be recognized as a generic HID device

by your host device, similar to a standard keyboard. This

allows you to scan into any field you could normally type into.

• If the MS920P is out of RF transmitting range from the host

device, it will automatically save any scan data in its buffer

memory and automatically upload the scan data to the host

when back in RF transmitting range.

• The MS920P can also operate in Batch Mode, where a

RF transmitting connection is not required. In Batch Mode,

the MS920P saves all scan data in internal memory and then

uploads the data when connected to a host. See back page

of this guide for more information about modes and settings.

RF HID *

COmmunication mode

RF SPP USB

MicroUSB

Plug the USB Dongle to a free USB port of

a host computer.

The MS920P is now ready to use.

Scan the barcode on the USB Dongle.

Connect dongle to host

Step 4:

Scan Dongle

Step 3:

COmmunication mode COmmunication mode

All-Purpose Pocket Scanner Memory Pocket Scanner 2d Pocket Scanner

mugfokcapafoeziS•

,SOihtiwelbitapmochtooteulB•

Android, Windows

yromemBM2•

gninnacshctaBdnaotuA•

sedocrabD2/D1sdaeR•

yromemBM2•

laeslatnemnorivne24PI•

Try a Unitech

wireless pocket scanner

for your smartphone,

tablet, or computer

MS920p Quick Start Guide

Scan here to send data from the MS920P to your

host device after collecting the data in Batch Mode.

Scan here to unpair the RF connection

between the MS920P and the host device.

Scan here to switch from Auto Mode to Batch Mode.

Data will now be stored in the internal memory of

the MS920P and the MS920P will no longer transmit

data via RF.

Scan here to switch back to Auto Mode.

You can now pair the MS920P with a host.

Scan these barcodes if you wish to erase the data

stored on your MS920P. Please keep in mind that

this process is irreversible.

Scan these barcodes if you wish to erase the data

stored in the MS920P’s buffer memory.

This factory default barcode will return your

scanner to its original factory settings, a useful

feature for troubleshooting purposes.

Switch to Batch mode

switch to auto Mode ( Default )

Volume

DELETE DATA ( Batch mode )

RESTORE FACTORY DEFAULT SETTINGS

TRANSFER DATA

DISCONNECT PAIRING

Enable Batch Mode Transfer Data

Enable Auto Mode Disconnect Pairing

Factory Default

vibration

Vibration on/off

. They are optional.

display f/w version

RF Module Power Saving

DELETE DATA ( auto mode )

Volume Up

Volume Down

Display F/W Version 1 Minute 3 Minute 5 Minute Never
