User manual

DUAD540 STROBE

Please read the instructions carefully before use

TABLE OF CONTENTS

1. Safety Instructions……………………………………………………………………………3-4

Technical Specifications…………………………………………………………………………4

Control Menu ………………………………………………………………………………………5

DMX Channels ……………………………………………………………………………………6-9

Trouble Shooting…………………………………………………………………………………10

Fixture Cleaning………………………………………………………… ………………………10

STATEMENT

The product has well capability and intact packing when leave factory. All of the user should

comply with warning item and manual, any misuse cause of the damages are not included in our

guarantee, and also can not be responsible for any malfunction & problem owing to ignore the

manual.

1.Safety Instructions

Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that

they also receive this instruction booklet.

•Unpack and check carefully there is no transportation damage before using the unit.

•Before operating, ensure that the voltage and frequency of power supply match the power

requirements of the unit.

•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.

•The unit is for indoor use only. Use only in a dry location.

•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent

surfaces. Be sure that no ventilation slots are blocked.

•Disconnect main power before replacement or servicing.

•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.

•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always

by taking its base.

•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher

than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand

during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before

replacing or serving.

•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit

by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please

contact the nearest authorized technical assistance center. Always use the same type spare parts.

•DO NOT touch any wire during operation as high voltage might be causing electric shock.

Warning:

•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.

•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

Caution:

•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any

repairs yourself. In the unlikely event your unit may require service, please contact your nearest

dealer.

Installation:

•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly

fixed to avoid vibration and slipping while operating. And make sure that the structure to which you

are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also

always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.

•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the

touch of people.

2.Technical Specifications

Light Source: 5*40W RGBW 4in1, 250*0.2W RGB strobe.

Power Consumption: P = 300W

Built-in Master/Slave, DMX, Sound Active, powerful effects mode.

LCD 2.4 inch TFT LCD screen, easy to operate.

Suitable for discotheques, clubs, bars, parties, mobile DJs, concerts and more.

DMX Channel: 16CH, 23CH,23CH-2 and 48CH.

Four Operational Modes: Sound (Audio) Active, Show Mode, DMX, Master / Slave;

Unlimited rotation, X/Y 360 °infinite rotation.

Voltage: AC100-240V 50-60Hz.

Fuse: F5AL250V.

Net Weight: 11kg

Size: 51.5 * 18.0 * 28.2cm

3.Control Menu

Item

Silkscreen

Function

Button:

①

Enter/check menu

②

Check the last menu

③

DOWN

Check the next menu

④

ENTER

Enter the menu or confirm

Menu Operation

System Settings

Menu 1

Menu 2

Menu 3

Function

DMX Address

001--512

DMX Address Code

DMX Mode

CH-16

16 DMX Channel

CH-23

23 DMX Channel

CH-48

36 DMX Channel

Auto Mode

Show Mode

Auto0

Random auto run

Auto1-16

Auto 1-16

Show Speed

01-99

Slow to fast

Sound Mode

Off

Sound control off

Sound control on

Sound Sense

00-99

Sound control sensitivity

Slave Mode

Slave 1

Slave 2

Advanced

Settings

Reset

No/Yes

Reset,No/Yes

Pan Invert

No/Yes

Pan inverse,No/Yes

Tilt Invert

No/Yes

Tilt inverse,No/Yes

Display

Off/On

LCD backlight switch, Off/On

Display Inverse

No/Yes

Display inverse No/Yes

Language

English

Chinese

DMX Fail

Auto

Black

Hold

Software

V1.0

4.DMX Channels

16 CH Mode

Value

Function

CH1

000

255

Pan movement, 0-540°Adjustable

Pan

CH2

000

255

Speed fast-slow

CH3

000

049

No function

050

149

Anticlockwise unlimited rotation, fast-slow

150

155

Stop rotation

156

255

Clockwise unlimited rotation, slow-fast

CH4

000

255

Tilt movement, 0-360°adjustable

Tilt

CH5

000

255

Move speed,fast-slow

CH6

000

049

No function

050

149

Unlimited rotation(down),fast-slow

150

155

Stop rotation

156

255

Unlimited rotation(up),slow-fast

CH7

000

255

Brightness 0-100%

Dimmer

CH8

000

255

Red linear dimmer,0-100%

40W LED

CH9

000

255

Green linear dimmer,0-100%

CH10

000

255

Blue linear dimmer,0-100%

CH11

000

255

White linear dimmer,0-100%

CH12

000

255

Red linear dimmer,0-100%

SMD RGB

CH13

000

255

Green linear dimmer,0-100%

CH14

000

255

Blue linear dimmer,0-100%

CH15

000

007

LED open

LED switch/

strobe

008

015

LED close

016

131

Strobe, slow to fast, 1-25Hz

132

139

LED open

140

181

LED quick on slow off, slow-fast

182

189

LED open

190

231

LED quick off slow on, slow-fast

232

239

LED open

24040

247

Random strobe

248

255

LED open

CH16

000

199

No function

Reset

200

209

Automatic reset after 3S

210

255

No function

23 CH Mode

Value

Function

CH1

000

255

Pan movement,540°Adjustable

Pan

CH2

000

255

Speed fast-slow

CH3

000

255

X fine

CH4

000

049

No function

050

149

Anticlockwise unlimited rotation, fast-slow

150

155

Stop rotation

156

255

Clockwise unlimited rotation, slow-fast

CH5

000

255

Tilt movement, 360°adjustable

Tilt

CH6

000

255

Move speed,fast-slow

CH7

000

255

Y fine

CH8

000

049

No function

050

149

Unlimited rotation(down),fast-slow

150

155

Stop rotation

156

255

Unlimited rotation(up),slow-fast

CH9

000

255

Brightness 0-100%

Dimmer

CH10

000

255

LED1 color selection

40W,LED

CH11

000

255

LED2 color selection

CH12

000

255

LED3 color selection

CH13

000

255

LED4 color selection

CH14

000

255

LED5 color selection

CH15

000

255

LED1 color selection

SMD RGB

CH16

000

255

LED2 color selection

CH17

000

255

LED3 color selection

CH18

000

255

LED4 color selection

CH19

000

255

LED5 color selection

CH20

000

007

LED open

LED switch/

strobe

008

015

LED close

016

131

Strobe, slow to fast, 1-25Hz

132

139

LED open

140

181

LED quick on slow off, slow-fast

182

189

LED open

190

231

LED quick off slow on, slow-fast

232

239

LED open

24040

247

Random strobe

248

255

LED open

CH21

000

007

No function

Show/sound control

008

022

Show 1

023

037

Show 2

038

052

Show 3

053

067

Show 4

068

082

Show 5

083

097

Show 6

098

112

Show 7

113

127

Show 8

128

142

Show 9

143

157

Show 10

158

172

Show 11

173

187

Show 12

188

202

Show 13

203

217

Show 14

218

232

Show 15

233

247

Show 16

248

255

Random Show

CH22

000

127

Show speed, slow-fast

Speed/ sound control

sentivity

128

255

Sound control & sensitivity, low-high

CH23

000

199

No function

Reset

200

209

Reset after 3s

210

255

No function

48 CH Mode

Value

Function

CH1

000

255

Pan movement, 540° adjustable

Pan

CH2

000

255

Tilt movement, 540° adjustable

CH3

000

255

X fine

CH4

000

049

No function

050

149

Anticlockwise unlimited rotation, fast-slow

150

155

Stop rotation

156

255

Clockwise unlimited rotation, slow-fast

CH5

000

255

Tilt movement, 360°adjustable

Tilt

CH6

000

255

Move speed,fast-slow

CH7

000

255

Y fine

CH8

000

049

No function

050

149

Unlimited rotation(down),fast-slow

150

155

Stop rotation

156

255

Unlimited rotation(up),slow-fast

CH9

000

255

Brightness 0-100%

Dimmer

CH10

000

255

R1 dimmer,0-100%

40W LED1

CH11

000

255

G1 dimmer,0-100%

CH12

000

255

B1 dimmer,0-100%

CH13

000

255

W1 dimmer,0-100%

CH14

000

255

R2 dimmer,0-100%

40W LED2

CH15

000

255

G2 dimmer,0-100%

CH16

000

255

B2 dimmer,0-100%

CH17

000

255

W2 dimmer,0-100%

CH18

000

255

R3 dimmer,0-100%

40W LED3

CH19

000

255

G3 dimmer,0-100%

CH20

000

255

B3 dimmer,0-100%

CH21

000

255

W3 dimmer,0-100%

CH22

000

255

R4 dimmer,0-100%

40W LED4

CH23

000

255

G4 dimmer,0-100%

CH24

000

255

B4 dimmer,0-100%

CH25

000

255

W4 dimmer,0-100%

CH26

000

255

R5 dimmer,0-100%

40W LED5

CH27

000

255

G5 dimmer,0-100%

CH28

000

255

B5 dimmer,0-100%

CH29

000

255

W5 dimmer,0-100%

CH30

000

255

R1 dimmer,0-100%

SMD 1

CH31

000

255

G1 dimmer,0-100%

CH32

000

255

B1 dimmer,0-100%

CH33

000

255

R2 dimmer,0-100%

SMD 2

CH34

000

255

G2 dimmer,0-100%

CH35

000

255

B2 dimmer,0-100%

CH36

000

255

R3 dimmer,0-100%

SMD 3

CH37

000

255

G3 dimmer,0-100%

CH38

000

255

B3 dimmer,0-100%

CH39

000

255

R4 dimmer,0-100%

SMD 4

CH40

000

255

G4 dimmer,0-100%

CH41

000

255

B4 dimmer,0-100%

CH42

000

255

R5 dimmer,0-100%

SMD 5

CH43

000

255

G5 dimmer,0-100%

CH44

000

255

B5 dimmer,0-100%

CH45

000

007

LED open

LED switch/

strobe

008

015

LED close

016

131

Strobe, slow-fast, 1-25Hz

132

139

LED open

140

181

LED quick on slow off, slow to fast

182

189

LED open

190

231

LED quick off slow on, slow-fast

232

239

LED open

240

247

Random strobe

248

255

LED open

CH46

000

007

No function

Show/ sound control

008

022

Show1

023

037

Show2

038

052

Show3

053

067

Show4

068

082

Show5

083

097

Show6

098

112

Show7

113

127

Show8

128

142

Show9

143

157

Show10

158

172

Show11

173

187

Show12

188

202

Show13

203

217

Show14

218

232

Show15

233

247

Show16

248

255

Random Show

CH47

000

127

Show speed, slow-fast

Speed/Sound control

sensitivity

128

255

Sound control & sensitivity, low-high

CH48

000

199

No function

Reset

200

209

Reset after 3s

210

255

No function

6.Trouble Shooting

ollo

ing

few

oble

y occu

uring

ope

tion

. He

tion

leshooting

The

does

work

, no

ght

Check

nect

ion of p

owe

eas

ure

ins

volt

Check

pow

LED

responding

LED

on.

che

nectors,

link

ope

If th

nd no

espons

el,

che

ess

etti

s a

ity

nter

ittent

oble

che

ins

onn

ecto

PCB

nit

the

iou

ntroller

Check

or run

lon

volta

les

terfer

ence

inter

face

circui

. One

the

cha

ing

tep

moto

dam

the

nect

to th

PCB

oken.

oto

’

ive

PCB

ndition

7.Fixture Cleaning

The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to

optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,

smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.

Clean with soft cloth using normal glass cleaning fluid.

Always dry the parts carefully.

Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.

Inhaltsverzeichnis

Andere Uplus Lighting Beleuchtungsausrüstung Handbücher

Uplus Lighting

Uplus Lighting 100SPOT Bedienungsanleitung

Uplus Lighting

Uplus Lighting BL6 Bedienungsanleitung

Uplus Lighting

Uplus Lighting IP-Z740 Bedienungsanleitung

Uplus Lighting

Uplus Lighting MINI740 Bedienungsanleitung

Uplus Lighting

Uplus Lighting 250 LED BEAM Bedienungsanleitung

Uplus Lighting

Uplus Lighting W3725 Bedienungsanleitung

Uplus Lighting

Uplus Lighting BR360 Bedienungsanleitung

Uplus Lighting

Uplus Lighting 6 EYE RETRO BAR Bedienungsanleitung

Uplus Lighting

Uplus Lighting PIXEL IP20X15 BAR Bedienungsanleitung

Uplus Lighting

Uplus Lighting 300 MZ-SPOT PR Bedienungsanleitung

Uplus Lighting

Uplus Lighting PF350 Bedienungsanleitung

Uplus Lighting

Uplus Lighting 400 IP BLINDER Bedienungsanleitung

Uplus Lighting

Uplus Lighting 400 BLINDER Bedienungsanleitung

Uplus Lighting

Uplus Lighting 230 BEAM Bedienungsanleitung

Uplus Lighting

Uplus Lighting IP-L360 Bedienungsanleitung

Uplus Lighting

Uplus Lighting IR 1210 PAR Bedienungsanleitung

Uplus Lighting

Uplus Lighting 200 MZ-SPOT PR Bedienungsanleitung

Uplus Lighting

Uplus Lighting 200 LED RETRO Bedienungsanleitung

Uplus Lighting

Uplus Lighting 200 LED BSW Bedienungsanleitung

Uplus Lighting

Uplus Lighting 19X15Z WASH Bedienungsanleitung

Uplus Lighting

Uplus Lighting COB400 ZOOM Bedienungsanleitung

Uplus Lighting

Uplus Lighting IP1000 Strobe Bedienungsanleitung

Uplus Lighting

Uplus Lighting 200 LED BSW Bedienungsanleitung

Uplus Lighting

Uplus Lighting 280 LED BSW Bedienungsanleitung

Beliebte Beleuchtungsausrüstung Handbücher anderer Marken

Brizo

Brizo 8SP-MU-4 Bedienungsanleitung

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Bedienungsanleitung

IKEA

IKEA BJÖRKSPIREA Bedienungsanleitung

Laserworld

Laserworld Evolution Series ES-400RGB Bedienungsanleitung

Alien

Alien RG STAR Bedienungsanleitung

EuroLite

EuroLite LED B-40 Bedienungsanleitung

Qazqa

Qazqa Suplux SL 3 Black 103062 Bedienungsanleitung

Commercial Electric

Commercial Electric 54568141 Bedienungsanleitung

CREE LIGHTING

CREE LIGHTING 304 Series Bedienungsanleitung

Goobay

Goobay 49867 Bedienungsanleitung

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Bedienungsanleitung

Alkalite

Alkalite Krypton KT-81 Bedienungsanleitung

Clas Ohlson

Clas Ohlson GU10 Bedienungsanleitung

DTS

DTS DELTA 10 F Bedienungsanleitung

ring

ring Solar Steplight Bedienungsanleitung

One Stop Gardens

One Stop Gardens 57696 Montageanleitung

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Bedienungsanleitung

SIREM

SIREM Swimeo A2 Bedienungsanleitung
