Uplus Lighting 400 BLINDER Bedienungsanleitung

User manual

400 BLINDER

Please read the instructions carefully before use

TABLE OF CONTENTS

1. Safety Instructions……………………………………………………………………………3-4

Technical Specifications…………………………………………………………………………4

Control Menu ………………………………………………………………………………………5

DMX Channels ……………………………………………………………………………………6

Trouble Shooting…………………………………………………………………………………7

Fixture Cleaning………………………………………………………… ………………………7

STATEMENT

The product has well capability and intact packing when leave factory. All of the user should

comply with warning item and manual, any misuse cause of the damages are not included in our

guarantee, and also can not be responsible for any malfunction & problem owing to ignore the

manual.

1.Safety Instructions

Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that

they also receive this instruction booklet.

•Unpack and check carefully there is no transportation damage before using the unit.

•Before operating, ensure that the voltage and frequency of power supply match the power

requirements of the unit.

•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.

•The unit is for indoor use only. Use only in a dry location.

•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent

surfaces. Be sure that no ventilation slots are blocked.

•Disconnect main power before replacement or servicing.

•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.

•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always

by taking its base.

•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher

than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand

during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before

replacing or serving.

•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit

by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please

contact the nearest authorized technical assistance center. Always use the same type spare parts.

•DO NOT touch any wire during operation as high voltage might be causing electric shock.

Warning:

•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.

•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

Caution:

•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any

repairs yourself. In the unlikely event your unit may require service, please contact your nearest

dealer.

Installation:

•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly

fixed to avoid vibration and slipping while operating. And make sure that the structure to which you

are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also

always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.

•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the

touch of people.

2.Technical Specifications

Input Voltage:AC90-240V,50/60Hz

Power Consumption:400W

Light Source:4X50W RGB COB LED,

Each LED can be controlled individual

Lamp life:50000hrs

Beam Angle: 60 ゜

Display :Digital display

Control Mode:DMX512,Master/Slave,Auto,Sound Active

DMX Channel:16/12/7 DMX Channels

Dimmer:0-100% smooth linear adjustment

Strobe:High speed strobe effect with 1-25 flashes per second

Cooling mode: Fan cooling(Temperature control)

IP Rate:IP20

Net Weight:8.5 Kg

Packing size:260*420*410 mm

3.Control Menu

Display:

MENU To select the programming functions

DOWN To go backward in the selected functions

UP To go forward in the selected functions

ENTER To confirm the selected functions (unlock screen)

Operations:

Press "MENU" to unlock screen, then press “Menu” to select 7 different functions, Press the "UP or

DOWN"keys to increase or decrease the value,Press "ENTER" to save and Exit.

Number

display

Function Explain

D001

12 channels address(001-512)B.C add minus address

A001

16 channels address(001-512)B.C add minus address

H001

7 channels address(001-512)B.C add minus address

R255

Red dimming(000-255) from dark to light

G255

Green dimming(000-255) from dark to light

B255

Blue dimming(000-255) from dark to light

AU01

20 self-propelled outputs(01-09)

SP01

99 speed outputs(01-99)

FH99

Strobe ,speed form slow to fast

Sound

Sound,9 effects

4.DMX Channels

DMX Channels(12 channels)

Channel

Display

Function Explain

1CH

R1 Dimmer

From dark to light

2CH

G1 Dimmer

From dark to light

3CH

B1 Dimmer

From dark to light

4CH

R2 Dimmer

From dark to light

5CH

G2 Dimmer

From dark to light

6CH

B2 Dimmer

From dark to light

7CH

R3 Dimmer

From dark to light

8CH

G3 Dimmer

From dark to light

9CH

B3 Dimmer

From dark to light

10CH

R4 Dimmer

From dark to light

11CH

G4 Dimmer

From dark to light

12CH

B4 Dimmer

From dark to light

DMX Channels(16 channels)

Channel

Display

Function Explain

1CH

Total Dimmer

From dark to light

2CH

R1 Dimmer

From dark to light

3CH

G1 Dimmer

From dark to light

4CH

B1 Dimmer

From dark to light

5CH

R2 Dimmer

From dark to light

6CH

G2 Dimmer

From dark to light

7CH

B2 Dimmer

From dark to light

8CH

R3 Dimmer

From dark to light

9CH

G3 Dimmer

From dark to light

10CH

B3 Dimmer

From dark to light

11CH

R4 Dimmer

From dark to light

12CH

G4 Dimmer

From dark to light

13CH

B4 Dimmer

From dark to light

14CH

Total strobe

From slow to fast

15CH

Feature Selection

Self-propelled effect 1-20

16CH

Feature speed

From slow to fast

DMX Channels(7 channels)

Channel

Display

Function Explain

1CH

Total Dimmer

From dark to light

2CH

R Dimmer

From dark to light

3CH

G Dimmer

From dark to light

4CH

B Dimmer

From dark to light

5CH

Total strobe

R,G,B total strobe,From slow to fast

6CH

Feature Selection

Self-propelled effect

7CH

Feature speed

From slow to fast

5.Trouble Shooting

ollo

ing

few

oble

y occu

uring

ope

tion

. He

tion

leshooting

The

does

work

, no

ght

Check

nect

ion of p

owe

eas

ure

ins

volt

Check

pow

LED

responding

LED

on.

che

nectors,

link

ope

If th

nd no

espons

el,

che

ess

etti

s a

ity

nter

ittent

oble

che

ins

onn

ecto

PCB

nit

the

iou

ntroller

Check

or run

lon

volta

les

terfer

ence

inter

face

circui

. One

the

cha

ing

tep

moto

dam

the

nect

to th

PCB

oken.

oto

’

ive

PCB

ndition

6.Fixture Cleaning

The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to

optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,

smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.

Clean with soft cloth using normal glass cleaning fluid.

Always dry the parts carefully.

Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
