DDR-E04AA
Hardware User Manual
2015 FEB V1.0
DDR-E04AA Hardware User Manual
i
Contents
A. CAUTION ..............................................................................................................................................1
B. Introduction.........................................................................................................................................2
1. Product Overview.....................................................................................................................2
2. Main functions...........................................................................................................................2
C. Unpacking............................................................................................................................................4
1. Accessories .................................................................................................................................4
2. Unpacking...................................................................................................................................4
D. Installation............................................................................................................................................4
E. Product appearance.........................................................................................................................6
1. Front Panel..................................................................................................................................6
2. Rear Panel ...................................................................................................................................8
3. Installation Illustration............................................................................................................9
Video input.......................................................................................................................9
Connections for video outputs.............................................................................. 10
AlarmIn/AlarmOut connections............................................................................ 10
F. Q & A and Maintenance.............................................................................................................. 11
1. Q & A.......................................................................................................................................... 11
2. Maintenance ........................................................................................................................... 15
G. Appendix : Specifications ............................................................................................................ 16
DDR-E04AA Hardware User Manual
1
A. CAUTION
To our dear customers!
Thank you for using our products. If you encounter any problems when using,
please do not hesitate to contact our resellers. We will provide excellent services to
you via our resellers.
The software/hardware improvements of this series are subject to change without
notice to you in advance. Before using, please read this user manual carefully to
ensure that you can use the device correctly and safely
Caution for this DVR series
After installation, never put anything heavy over this device. Owing to the use
of the hard drive(s) insides this device, check the cooling fan periodically to
see if it works. Never use this device when the cooling function is out of order!
Do not allow any solid object or liquid fall into or penetrate into the device.
Use cleaning tools (brushes) regularly to clean circuit boards, connectors, fans,
chassis, etc. Before cleaning, turn off the power and unplug the power.
Do not attempt to disassemble the equipment, repair, or replace parts. In case
the machine does not work properly, please contact the resellers or
manufacturers. In the shortest time, we will solve the problems you have
during using.
When not using the remote control for a long time, take out the inside battery
To prevent the control from the damage coming from battery leakage!
If this equipment connects to outdoor cameras or other external alarm devices,
ground this equipment to prevent it from electrical surges.
This DVR supports remote video monitoring via internet. Free or non-free
domain names provided by ISPs are needed for the monitoring functions.
Free domain names may sometimes have problems and nothing to do with
DVR. Non-free domain names have less problems. Choose the domain names
carefully before using the networking function.
Operating environment
Keep and use this device at places where temperature ranges 0℃~40℃. Avoid
DDR-E04AA Hardware User Manual
2
direct sunlight or near heat sources.
Do not install this equipment in a humid environment
Do not expose this equipment in smoky, dusty environments;
Avoid strong collision, do not drop the machine
Keep the installation level, install in a stable place, avoid the product falling;
Do not block any ventilation openings. And ensure well ventilation around the
machine
Please use this equipment within rated input and output current/voltage
range.
This device is for long-time use. For safety, do not have flammable items
placed next to the device.
B. Introduction
1. Product Overview
This equipment is an excellent digital surveillance product designed
specifically for the security use. Using embedded LINUX operating system, it
makes the system more stable. Using standard H.264 video compression and
G.711A audio compression technology achieves audio and video functions
such as high-quality, low bit rate and single-frame playback. Using TCP / IP
and other network technologies, it provides strong network data transmission
capacity and remote control capabilities.
This equipment can be used individually or be connected to form a powerful
security monitoring network. Using professional network video surveillance
software platform, be fully experienced the powerful networking and remote
monitoring capabilities.
This equipment can be used for security in banks, telecommunications, power
stations, justice, transport, intelligence communities, factories, warehouses,
resources, water conservancy facilities and other categories.
2. Main functions
Hisilicon SoC CPU special design for NVR/DVR with the best image
process efficiency.
Support 1 units of SATA/SATA II device up to 4TB HDD recording capacity.
DDR-E04AA Hardware User Manual
3
Advanced H.264 compress technology provides the best HDD space
usage.
Embedded Linux system, to eliminate the threat from virus and hacking.
Support 4CHs of Dtv Camera (1080P) video.
Support HD output.
Support CAMERA position layout and editable user definition.
The USB mobile storage device.
Support 3 users log on by Client-side software or browser.
DDR-E04AA Hardware User Manual
4
C. Unpacking
1. Accessories
★Power cable and adaptor AC100-240V/DC12V 3A x 1PCS
★HDD screws x 4pcs
★Mouse (optional)
2. Unpacking
When you receive the product, check first whether the packing of the
equipment has obvious damage. The protective material used for the package
during transport can cope with most of the accidental impact;
Then, take out the device, remove the protective film of the digital video
recorder and check if there is any visible damage;
Finally, open the case, check the front panel data cable, power cord, power
supply fan and motherboard to see if they are connected firmly.
Front/Rare panels
The key functions of the front panel and the interfaces of the rear panel are
described in detail in the manual.
Please carefully check the plate or foil on the rear panel of the product to see
if it is the model you ordered.
Information on the rear panel is important for our service, so keep it properly.
Before contacting us, you will need to provide your model type and serial
number.
Inside check
In addition to checking for visible signs of damage, be careful to check the
connections between the front panel data cable, power cord and
motherboard.
D. Installation
Steps and cautions:
1、Ensure room temperature below 35℃
2、Reserve space for air circulation around 15 cm (6 inches).
DDR-E04AA Hardware User Manual
5
3、Chassis installation starts from bottom to up
4、With multiple components in the chassis, take precautions to avoid
overloading to the power outlet.
DDR-E04AA Hardware User Manual
6
E. Product appearance
1. Front Panel
MENU
MENU
Under the live viewing mode, press MENU to enter the
main menu.
ESC
ESC
Exit the current menu.
REC
Under the live mode, press the REC button to enter
recording menu.
STOP
Stop the playback under the playback mode.
Step Forward
To playback frame by frame when paused in playback
mode. ( Press Pause before operation )
Play
Pause
Under the live viewing mode, press the Play button to
enter the playback mode.
Under the playback mode, press to play back.
When playbacking, press to pause playback.
Fast Forward
Under the playback mode, there are 4 choices for the
speed.
Choose your choice to forward.
Slow Forward
Under the playback mode, there are 4 choices for the
speed.
Choose your choice to forward.
UP
DOWN
To move up or down of the selection setting in the UI
menu.
LEFT
RIGHT
To move left or right of the selection setting in the UI
menu.
ENTER
Press the Enter button to confirm the setup or go into
main menu in live mode.
Preview CH1
Preview CH1.
Preview CH2
Preview CH2.
Preview CH3
Preview CH3.
Preview CH4
Preview CH4.
Power
Power Indicator
DDR-E04AA Hardware User Manual
7
Indicator
Recording
Indicator
Recording Indicator
DDR-E04AA Hardware User Manual
8
2. Rear Panel
4ch DVR illustration
1
1~4 CH Video Input (BNC)
2
Video Output
3
HD digital output
4
VGA output
5
LAN Port
6
USB Mouse Port
7
DC12 Power Input
8
Alarm IN
9
Alarm OUT
Alarm In/Alarm Out
DC12V
