HF85-FM-C/HF85-FM-CA

Let’s get started

FLOORMATE

Basic

safety

precautions

Don’ts

Do’s

This Floormate Cordless is intended for household use only

and NOT for commercial or industrial use.

• This Floormate Cordless is for use on hard oors only.

• Only use the Floormate Cordless indoors and keep the area

you’re cleaning well lit.

• Keep ngers, hair and loose clothing from moving parts and

openings whilst using the Floormate Cordless.

• This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the

hazards involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children

without supervision.

• Don’t use this Floormate Cordless if it has been dropped,

damaged, immersed in water or left outdoors.

• Don’t run over the power cord or use Floormate Cordless

if the power cord or plug is damaged.

• Don’t handle the plug or use the Floormate Cordless with

wet hands.

• Don’t unplug the charger by pulling on the power cord.

• Always turn o the Floormate Cordless before carrying out

any maintenance.

• The clean water tank should only be lled with warm water (max

40°C). Filling the clean water tank with hot or boiling water may

damage your machine and invalidate your guarantee.

• Turn o all controls on the Floormate Cordless before

disconnecting or connecting the battery.

• Always replace the fuse in the plug with a British 13amp fuse.

• Use only the battery (Vax part no. BH03120UK) supplied by Vax.

Other batteries may burst causing serious personal injury

or damage.

• Only use Vax hard oor cleaning detergent. Using other solution

may cause excess foaming.

Let’s talk safety

• Please refer to oor manufacturer’s care recommendations before use, and

test your ooring by running the Floormate Cordless over a small hidden

area, if no damage or discolouration occurs continue cleaning. Not suitable

for use on water sensitive ooring.

• Replace battery with Vax battery only. Use of another battery may present

a risk of re or explosion.

• Prior to disposal, protect exposed terminals with heavy insulating tape to

prevent shorting. The battery is to be disposed of safely at your local battery

recycling centre.

• In case of battery leakages, avoid any contact with skin and contact our

Customer Care Line on: 0330 026 8455 (Mon-Fri 8:30am to 6:30pm, Sat

9:00am to 5:00pm).

• In the eventuality of scrapping the product, please remove the battery from

the unit.

• The appliance is only to be used with the power supply unit provided with

the appliance.

• Don’t use this Floormate Cordless if it has been dropped,

damaged, immersed in water or left outdoors.

• Don’t run over the power cord or use Floormate Cordless

if the power cord or plug is damaged.

• Don’t handle the plug or use the Floormate Cordless with

wet hands.

• Don’t unplug the charger by pulling on the power cord.

• Don’t attempt to remove blockages with sharp objects as this may cause

damage to your Floormate Cordless.

• Don’t use the Floormate Cordless with incorrect voltage as this may result in

damage or injury to the user. The correct voltage is listed on the ratings label.

• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning

items or use in an area where there may be harmful uids (chlorine, bleach,

and ammonia drain cleaner).

• Don’t try to short the terminals of the battery and the charger.

• Always turn o the Floormate Cordless before carrying out

any maintenance.

• The clean water tank should only be lled with warm water (max

40°C). Filling the clean water tank with hot or boiling water may

damage your machine and invalidate your guarantee.

• Turn o all controls on the Floormate Cordless before

disconnecting or connecting the battery.

• Always replace the fuse in the plug with a British 13amp fuse.

• Use only the battery (Vax part no. BH03120UK) supplied by Vax.

Other batteries may burst causing serious personal injury

or damage.

• Only use Vax hard oor cleaning detergent. Using other solution

may cause excess foaming.

• Always protect the charger cord from heated surfaces or near open ames.

• Use only CE approved 13amp extension cords, non-approved extension cords

may overheat. Care should be taken to arrange the extension cord as it can be

a trip hazard.

• Always carry the Floormate Cordless by the handle.

• Always use the Floormate Cordless in an upright position. To prevent motor

damage from dirty water, never hold the Floormate Cordless upside down or

lay on its side.

• Store your Floormate Cordless in a cool, dry area. Before storing your

Floormate Cordless please ensure all water/detergent tanks and lters are

thoroughly clean and dry.

PLEASE KEEP INSTRUCTIONS FOR FURTHER USE AND USE ONLY

AS INSTRUCTED IN THIS GUIDE.

Thank you for buying this Floormate Cordless.

Taking care of your hard oors

The Floormate Cordless is designed to make washing hard oors regularly, as eective and

ecient as possible and this user guide will help you get the most out of your machine.

Maintaining your hard oors will ensure they keep their appearance for longer. You’ve chosen

hard oors for your home for a reason and Vax will help you take good care of them.

Taking care of your Floormate Cordless

Also inside this guide are instructions on maintaining your new machine, so that it’s always ready

when you are to tackle your hard oors.

Let us know what you think @VaxUK

Taking care of you

We’re here if you need us. Instead of taking me back

to the shop, simply visit:

vax.co.uk/support or call:

(UK) 0330 026 8455 (ROI) 1-800 928 308

Monday-Friday 8.30am to 6.30pm, Saturday 9.00am to 5.00pm

Calls are charged at the UK local rate. Please make a note of the serial number and model number

of the product before calling.

Alternatively, you can write to us at:

Vax Ltd, Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwitch, WR9 OLW, UK

This User Guide can be found online at: vax.co.uk/support

Contents

Let’s talk safety

Getting to know your machine

Getting started

Using your machine

Taking care of your machine

What to do if it goes wrong

Getting in touch

Accessories

Notes

Floormate Cordless

250ml Floor to Floor

Detergent

Included with

your machine

SpinScrubTM Wood

Floor Brush

1x LithiumLifeTM Battery

(dependant on model*)

Battery Charger

(dependant on model*)

*Not included with HF85-FM-CA

Getting to know your machine

Handle Release

Pedal

Folding Handle Release Button

Scroll Selector Control

Handle

Carry Handle

Battery Cover

Dirty Water Tank

Release Button

Clean Water/

Detergent Tank

Release Button

Dirty Water Tank

Clean Water/

Detergent Tank

Brush Release Buttons

Nozzle Release Latch

Nozzle

Subject to technical change without notice.

Technical Specication

Name Floormate Cordless

Battery voltage 20V

Weight 6.35kg

Part number 1-1-134995-00

Battery Specication

Type Lithium-Ion rechargeable

battery pack

Nominal voltage 20VDC

Capacity 4Ah/72Wh

Battery Model No. BH03120UK

Battery Charger Specication

Model No. BH03200UK

Technical Specication

Name Floormate Cordless

Weight 5.4kg

Part Number 1-1-135756-00

Accessories & Consumables

Battery Charger 1-1-134171-00

LithiumLifeTM Battery 1-1-134164-00

Floor to Floor Sanitise 1-9-133258-00

Floor to Floor Detergent 1.5L 1-9-132708-00

Getting started

HF85-FM-C HF85-FM-CA

Raise handle to upright

position until it clicks and

locks into place.

Pull the nozzle release

latch upwards and

forwards to remove.

Lie your Floormate

Cordless on its back. Line

up the spindle on the

SpinScrubTM brushes with

the plate on the base of

the Floormate Cordless.

Push SpinScrubTM brushes

rmly to lock into place.

Line up and push nozzle

until clicks into place.

PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE.

Getting started

Charging the battery

Fit the battery onto the

battery charger.

The battery charger light will

turn blue when charging. If

a red light appears an error

has occurred, remove the

battery and ret.

The battery will be fully

charged after 3 hours

and the charger light will

turn o.

PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE.

CAUTION: The battery used in this device may present a risk of re or chemical burn if mistreated. Do not

disassemble or heat above manufacturer’s maximum temperature limit (60° C/140°F) or incinerate. Replace battery

with Vax battery only. Use of another battery may present a risk of re or explosion. Dispose of used battery

promptly. Keep away from children. Do not disassemble and do not dispose of in re. Do not attempt to disassemble

the battery or remove any component projecting from the battery terminals. The battery and charger have no user

serviceable parts. Fire or injury may result. Prior to disposal, protect exposed terminals with heavy insulating tape to

prevent shorting. The battery is to be disposed of safely at your local battery recycling centre.

For best performance terminals on battery, battery charger and Floormate Cordless must be clean and free from dust

and dirt. Do not attempt to recharge non-rechargeable batteries. The battery must be removed from the appliance

before it is scrapped. The appliance must be disconnected from the supply mains when removing the battery. In case

of battery leakages avoid any contact with skin and contact our Customer Care Line on: 0330 026 8455 (Mon-Fri

8:30am to 6:30pm, Sat 9:00am to 5:00pm).

IMPORTANT: The battery will need fully charging before rst use.

NOTE: The life expectancy of the battery will vary depending on the usage of the Floormate Cordless.

Removing the battery

Press the release button,

hold base of battery

charger and lift the battery

to remove.

To check how much life is left

on the battery, press down on

the battery button and see the

battery life indicator.

25% Charged

50% Charged

75% Charged

Getting Started

Using your machine

Filling the clean water tank

IMPORTANT: Only use Vax hard oor cleaning detergent. Using other solution may cause excess foaming.

Excessive foaming will prevent the machine from working eectively. Using other detergents will

invalidate the guarantee.

Getting Started

Using your machine

Press the release button

on the clean water/

detergent tank. Pull to

remove tank.

Twist clean water/

detergent tank cap

clockwise to re-t.

Twist clean water/

detergent tank cap anti-

clockwise, lift to remove.

Tilt clean water/detergent

tank and line up onto

Floormate Cordless. Push

until it clicks into place.

Using the clean water/

detergent tank cap, pour

the required amount of

detergent to the ll line

(approx. 60ml

per 1 litre of water).

Pour detergent into tank.

Top up tank to ll line with

warm water (Max 40˚C).

IMPORTANT: Please refer to oor manufacturer’s care recommendations before use, and test your ooring by

running the Floormate Cordless over a small hidden area. If no damage or discolouration has occurred once

the area is dry, continue cleaning. Not suitable for use on water sensitive ooring. Vacuum your hard oor

thoroughly prior to using your Floormate Cordless.

NOTE: If you just want the brushes to spin, push scroll selector control forward one click to the central position.

Using your machine

TIP

To enhance drying on the oor

surface, release the trigger

and continue to move machine

over the area to pick up dirty

solution.

Pull to open battery cover.

Fit the battery into the

Floormate Cordless. The

battery will click into posi-

tion when correctly tted.

Press the handle

release pedal and pull

handle backwards.

Push scroll selector

control forward 2 clicks.

Squeeze trigger to release

clean water and detergent

(WASH mode), release

trigger to pick up dirty

water (DRY mode).

In WASH mode, with the

trigger held down

to release clean water

and solution, slowly move

the Floormate Cordless

forward to arms length.

Release the trigger and

pull the Floormate Cord-

less backwards

to pick up.

Taking care of your machine

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Vax Staubsauger Handbücher

Vax

Vax INFINITY V-031B Series Bedienungsanleitung

Vax

Vax VaxAIR VCAB1500 Bedienungsanleitung

Vax

Vax V-107B Series Bedienungsanleitung

Vax

Vax VCT-01 Bedienungsanleitung

Vax

Vax C85-AA-Be Bedienungsanleitung

Vax

Vax V-118 Bedienungsanleitung

Vax

Vax Blade TBT3V1B1 Montageanleitung

Vax

Vax Mach Air U91-MA series Bedienungsanleitung

Vax

Vax V027 Bedienungsanleitung

Vax

Vax Workman VCC-05 Bedienungsanleitung

Vax

Vax Air3 Agile U87-AA-B Bedienungsanleitung

Vax

Vax Rapide plus 5130 Produktinformationsblatt

Vax

Vax U90-CX-P-A Bedienungsanleitung

Vax

Vax Platinum PowerMax ECB1SPV1 Bedienungsanleitung

Vax

Vax W86-DP-A series Montageanleitung

Vax

Vax H85-ACH-B Technisches Datenblatt

Vax

Vax C87-VC-B Series Bedienungsanleitung

Vax

Vax Flair Total Home Montageanleitung

Vax

Vax C86-AS-H-E Bedienungsanleitung

Vax

Vax W85-PL-T Dual Power Pro Advance Bedienungsanleitung

Vax

Vax VX37 Bedienungsanleitung

Vax

Vax Libretto Produktinformationsblatt

Vax

Vax Mach1 VZL-6011 Bedienungsanleitung

Vax

Vax POWERMAX VRS18W Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
