Vax Power U84-M1-Be Montageanleitung

U84-M1-Be

U84-M1-Pe

U84-M1-Re

U84-M1-Te

LET’S GET STARTED.

Power

POWERFUL PERFORMANCE

U84-M1-Be

U84-M1-Pe

U84-M1-Re

U84-M1-Te

LET’S GET STARTED.

Power

POWERFUL PERFORMANCE

Let’s talk safety

Basic

safety

precautions

Don’ts

Do’s

• This vacuum cleaner is intended for household use only and

NOT for commercial or industrial use.

• Only use the vacuum cleaner indoors on dry surfaces and

keep the area you’re cleaning well lit.

• Keep ngers, hair and loose clothing away from moving parts

and openings whilst using the vacuum cleaner.

• This vacuum cleaner can be used by children aged from 8

years and above and persons with reduced physical, sensory

• Don’t use the vacuum cleaner if it has been dropped, damaged

or left outdoors.

• Don’t run over the power cord or use vacuum cleaner if the

power cord or plug is damaged. Please contact our Customer

Service Line on: 0330 026 8455 (Mon-Fri 08:30-18:30 Sat

09:00-17:00).

• Don’t handle the plug or use the vacuum cleaner with wet hands.

• Don’t pull or carry the vacuum cleaner by the power cord.

Don’t use the power cord as a handle, pull the power cord around

corners, sharp edges or close a door over the power cord.

Don’t unplug the vacuum cleaner by pulling on the power cord.

• Turn o all controls on the vacuum cleaner before

disconnecting or connecting the plug from the mains socket.

• Always keep the power cord away from the brushes during

use. After use always wrap the power cord around the cord

clips provided.

• Always make sure both the pre-motor/post-motor lters are

in place before use.

• This vacuum cleaner is tted with a constantly rotating

brushbar. To avoid damage to your ooring, make sure the

brush bar is raised to the highest setting when using the

accessories and when using on stairs.

• Always take extra care when positioning the vacuum cleaner

on the stairs.

or mental capabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the vacuum cleaner in a

safe way and understand the hazards involved. Children shall not play with

the vacuum cleaner. Cleaning and user maintenance shall not be made by

children without supervision.

• Only Vax recommended tools should be used with the vacuum cleaner,

use of non-branded Vax accessories/tools will invalidate your warranty.

• Don’t vacuum up any ammable or combustible materials (lighter uid, petrol,

kerosene etc) or use the vacuum cleaner in an area with explosive vapours

or liquid.

• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning

items or use in an area where there may be harmful uids (chlorine, bleach,

and ammonia drain cleaner).

• Don’t attempt to remove blockages with sharp objects. This may cause damage

to the vacuum cleaner, remove blockages only as instructed in this guide.

• Don’t vacuum up hard or sharp objects such as glass, nails, screws or coins etc.

• Don’t use the vacuum cleaner with incorrect voltage as this may result in

damage or injury to the user. The correct voltage is listed on the ratings label.

• Always switch o the vacuum cleaner before disconnecting or connecting

the hose and accessories.

• Keep all openings clear and free from debris as this may aect the

airow/suction.

• Always replace the fuse in the plug with a British 13amp fuse. Always protect

the power cable from heated surfaces and open ames.

• Use only CE approved 13amp extension cords, non-approved extension cords

may overheat. Care should be taken to arrange the extension cord as it can

be a trip hazard.

• Store the vacuum cleaner in a cool, dry area. If the lters have been cleaned

as per user the guide instructions ensure they are thoroughly dry before

storing away.

PLEASE KEEP INSTRUCTIONS FOR FURTHER USE AND USE ONLY

AS INSTRUCTED IN THIS GUIDE.

Thank you for buying this Power vacuum

Taking care of your carpets and hard ﬂoors

The Power is designed to make vacuuming carpets and hard oors regularly, as eective

and eﬃcient as possible and this user guide will help you get the most out of your machine.

Maintaining your carpets and hard oor will ensure they keep their appearance for longer.

You’ve chosen the carpets and hard oors for your home for a reason and Vax will help you

take good care of them.

Taking care of your Power

Also inside this guide are instructions on maintaining your new machine, so that it’s always

ready when you are to tackle your carpets and hard oors.

Let us know what you think @VaxUK

Let us know what you think

@VaxUK

Taking care of you

We’re here if you need us. Instead of taking me back

to the shop, simply visit:

vax.co.uk/support or call:

(UK) 0330 026 8455 (ROI) 1-800 928 308

Monday-Friday 8:30am to 6:30pm, Saturday 9:00am to 5:00pm

Calls are charged at the UK local rate. Please make a note of the serial number and model number

of the product before calling.

Alternatively, you can write to us at:

Vax Ltd., Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwich,

Worcestershire, WR9 0LW, UK

This user guide can be found online at: vax.co.uk/support

Contents

Let’s talk safety

Getting to know your machine

Getting started

Using your machine

Taking care of your machine

Let’s talk technical

Accessories

What to do if it goes wrong

Getting in touch

Notes

Power

2-in-1 tool

Included with

your machine

TurboTool

Up-Top-Tool

Hard Floor Adaptor

Power Pet/Reach

Includes all the above, plus

Power Total Home

Includes all the above, plus

Getting to know your machine

Name Power

Voltage 220-240V~50Hz

Wattage 850W

Cord length 6-8m

Weight 6.1kg

Technical Speciﬁcation

Subject to technical change without notice.

Pre-motor Filter

1-7-137046

Post-motor Filter

1-7-137047

Pro Cleaning Kit (Type 2)

1-1-133326-00

TurboTool (Type 5)

1-1-134418-00

Flat Upholstery Tool

1-1-131394-00

Flexi Crevice Tool (Type 2)

1-1-131393-00

2 in 1 Tool (Type 3)

1-1-132332-00

Accessories & Consumables

To purchase consumables and accessories, please visit vax.co.uk

Handle

Separator

Dirt container release button

Dirt container

Height adjuster

dial

Brushbar

Flat Upholstery Tool

Accessories & Consumables

Post motor lter

and cover

Cord hook

Hose guide

Accessory hose

On/O pedal

Stretch hose

Handle release clip

Cord hook

Assembling your vacuum cleaner

Press the release clip on

the stretch hose, line up

and push the hose into

the handle.

Slide the handle down

into the main body of

the vacuum cleaner.

Line up the stretch hose with hose

guides, push and clip stretch hose

into place. The end of the stretch

hose will hang loose at the bottom

of the machine

PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE

Getting started

Before you begin

WARNING: Always switch o the vacuum cleaner before connecting or disconnecting the hose/attachments

or removing and emptying the dirt container.

IMPORTANT: The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does

overheat the thermostat will automatically turn the vacuum cleaner o. If this happens switch the vacuum cleaner o

and unplug from electrical socket. Remove and empty the dirt container also check the vacuum cleaner for blockages.

Allow the vacuum cleaner to cool for approximately 1 hour (if you have cleaned the lters please wait 24 hours for the

lters to fully dry before putting back into the machine).

For best cleaning results, lters should be tapped over a bin every 4-6 uses to remove dirt and debris and washed every

3 to 6 months (depending on the level of use).

If the vacuum cleaner is blocked, switch o and unplug before removing the blockage.

When the vacuum cleaner is stood in the upright position, or when using the hose and tools the brushbar height adjuster

must be set to the highest setting.

Using your machine

Plug vacuum cleaner into

the mains and switch on.

Turn height adjuster dial

to desired setting.

Place foot on oorhead

and pull handle to recline.

Press the on/o pedal

to switch on.

Using your machine

IMPORTANT: Always switch o the vacuum cleaner before disconnecting or connecting the hose and accessories.

The accessories can be attached to the handle or directly to the hose.

When using accessories on the hose/handle raise the height adjuster to the highest setting.

Lie vacuum cleaner on its

back exposing the brush bar.

Line up oor tool with the base of the vacuum cleaner, push until it clicks into place.

Using the hard ﬂoor tool

TIP

To make sure the oor

tool is correctly tted,

the wheels should

be towards the back

of the oor tool

when attached to

vacuum cleaner.

Using your machine

Pull and release the stretch

hose from hose guides.

Unclip the hose end on

the accessory hose. Pull

and remove accessory

hose from the base of

vacuum cleaner.

Line up and push the end

of the stretch hose onto

the accessory hose until

it clicks into place.

Using the hose and accessories

Using your machine

IMPORTANT: Always switch o the vacuum cleaner before disconnecting or connecting the hose and accessories.

The accessories can be attached directly to the hose.

This vacuum cleaner is tted with a constantly rotating brush bar. To avoid damage to your ooring, make sure the brush

bar is raised to the highest setting when using the accessories.

Press the release clip

on the stretch hose,

pull and remove stretch

hose from handle.

Push and attach the 2-in-1

crevice/dusting brush,

TurboTool or Above Floor

Tool (some models only)

onto the end of the

stretch hose.

Turn the brushbar height

adjuster dial to highest

setting before pressing the

on/o pedal to switch the

vacuum on.

Using your machine

Press the handle release

clip, pull and remove the

handle out of the main body.

Attach the 2-in-1 crevice/

dusting brush to the end

of the handle.

Turn brush bar height adjuster

dial to highest setting before

pressing the on/o pedal to

switch the vacuum on.

Taking care of your machine

Pull and release the stretch

hose from hose guides.

Unclip the hose end on the

accessory hose. Pull and remove

accessory hose from the base of

vacuum cleaner.

Using the handle and accessories

IMPORTANT: Always switch o the vacuum cleaner before disconnecting or connecting the hose and accessories.

This vacuum cleaner has a constantly rotating brush bar. When cleaning on stairs raise the height adjuster dial to the

highest setting. The brush bar must over hang the stair tread.

Always take extra care when cleaning stairs.

Line up and push the end of the

stretch hose onto the accessory

hose until it clicks into place.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Vax Staubsauger Handbücher

Vax

Vax V-091Series Bedienungsanleitung

Vax

Vax Flair C86-FD-Be Montageanleitung

Vax

Vax Air Stretch U85-AS-Be Technisches Datenblatt

Vax

Vax CANISTER Produktinformationsblatt

Vax

Vax Dynamo Power H85-DP-B21 Montageanleitung

Vax

Vax C91-P2 SERIES Bedienungsanleitung

Vax

Vax HF86-FM-T Technisches Datenblatt

Vax

Vax Performance Cyclonic V-008SC Bedienungsanleitung

Vax

Vax U90-M5 Series Bedienungsanleitung

Vax

Vax HF86-FM-T Bedienungsanleitung

Vax

Vax U88-T4 series Bedienungsanleitung

Vax

Vax U91-P3 Series Bedienungsanleitung

Vax

Vax turbo force zero VZL-501 Bedienungsanleitung

Vax

Vax FORCE3 VZL-118 Series Bedienungsanleitung

Vax

Vax C86-TOe Series Montageanleitung

Vax

Vax SLIMVAC VX63 Bedienungsanleitung

Vax

Vax C86-AS-H-E Bedienungsanleitung

Vax

Vax Rapide V-028PX Bedienungsanleitung

Vax

Vax MACH 5 Bedienungsanleitung

Vax

Vax Rapide Spring Fresh V-021T Bedienungsanleitung

Vax

Vax XL Pro V-027U Bedienungsanleitung

Vax

Vax VC-1002 Bedienungsanleitung

Vax

Vax RAPID POWER Series Bedienungsanleitung

Vax

Vax Edge Pet & Car CLUP-EGKS Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
