Vax RapidPower PRO ECGLV1B1 Montageanleitung

ECGLV1B1

RapidPower

PRO

CARPETS DRY IN ABOUT 1 HOUR

LET’S GET STARTED.

Let’s talk safety

Do’s

Basic

safety

precautions

This carpet washer is intended for household use only and NOT

for commercial or industrial use.

• Only use the carpet washer indoors and keep the area you’re

cleaning well lit.

• Keep ngers, hair and loose clothing away from moving parts and

openings whilst using the carpet washer.

• This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental

Don’ts

• Don’t leave the carpet washer plugged in when unattended.

• Don’t use this carpet washer if it has been dropped, damaged or left

outdoors.

• Don’t run over the power cord or use carpet washer if the power

cord or plug is damaged. Please contact our Customer Care Line

on: 0330 026 8455.

• Don’t use the carpet washer to pick up any ammable or

combustible materials (lighter uid, petrol, kerosene etc.) or use the

carpet washer in an area with explosive vapours or liquid.

• Don’t handle the plug or use the carpet washer with wet hands.

• Don’t use the carpet washer to pick up hot coals, cigarette butts,

• Always vacuum your carpets thoroughly before using the carpet

washer.

• Check with the manufacturer of your ooring and always test in an

inconspicuous area prior to using the carpet washer.

• The clean water tank should be lled with warm water (max 40°C)

only. Filling the clean water tank with hot or boiling water will

damage the machine and invalidate the guarantee.

• Always unplug the carpet washer before carrying out any

maintenance and before connecting or disconnecting the hose/

accessories.

• Turn o all controls on the carpet washer before disconnecting or

connecting the power cord, after use always wrap the power cord

around the cord clips provided.

• Always replace the fuse in the plug with a British 13amp fuse.

Always protect the power cable from heated surfaces or near open

ames.

capabilities or lack of experience and knowledge if they have been given

supervision or instruction concerning use of the appliance in a safe way and

understand the hazards involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children without

supervision.

• Before using the carpet washer test your carpets/rugs/upholstery for

colourfastness and pile distortion.

• Only Vax recommended tools and solution should be used with this carpet

washer. Using other solutions may invalidate the guarantee.

matches or smoking hot burning items or use in an area where there may

be harmful uids (chlorine, bleach, and ammonia drain cleaner).

• Don’t pull or carry this carpet washer by the power cord. Don’t use the power

cord as a handle, pull the power cord around corners, sharp edges or close

a door over the power cord. Don’t unplug carpet washer by pulling on the

power cord.

• Don’t carry the carpet washer while it’s switched on.

• Don’t attempt to remove blockages with sharp objects as this may cause

damage to the carpet washer.

• Don’t use the carpet washer with incorrect voltage as this may result in damage

or injury to the user. The correct voltage is listed on the ratings label.

• Always keep the power cord away from the brushes whilst using the carpet

washer.

• Use only CE approved 13amp extension cords, non-approved extension cords

may overheat. Care should be taken to arrange the extension cord as it can be

a trip hazard.

• Take extra care when cleaning on the stairs.

• Always use the carpet washer with all water/solution tanks and lters in place.

• Always check accessories are free from damage, dirt and debris before use.

• Keep all openings clear and free from debris as this may aect the airow/

suction.

• Always use the carpet washer in an upright position. To prevent motor damage

from dirty water, never hold the carpet washer upside down or on its side.

• Store the carpet washer in a cool, dry area. Before storing the carpet washer

please ensure all water/solutions tanks and lters are thoroughly clean and dry.

• PLEASE KEEP INSTRUCTIONS FOR FURTHER USE AND USE ONLY

AS INSTRUCTED IN THIS GUIDE.

Thank you for buying the Rapid Power Pro.

Taking care of your carpets

The Rapid Power Pro is designed to make washing carpets regularly, as eective and ecient as

possible and this user guide will help you get the most out of your machine.

Maintaining your carpets will ensure they keep their appearance for longer and smell fresh and

clean. You’ve chosen carpets for your home for a reason and Vax will help you take good care

of them.

Taking care of your Rapid Power Pro

Also inside this guide are instructions on maintaining your new machine, so that it’s always ready

when you are to tackle your carpets.

Let us know what you think @VaxUK

Taking care of you

We’re here if you need us. Instead of taking me back

to the shop, simply visit our online support:

vax.co.uk/support

Still need to get in touch?

Our UK based Customer Care Team are here to support you - for help with assembly,

operational/performance problems or buying and tting new accessories. Whether you wish to chat,

use Facebook, Twitter or call, you can nd all our contact details at vax.co.uk/contactus

This user guide can be found online at: vax.co.uk/support

Contents

Let’s talk safety

Getting to know your machine

Getting started

Using your machine

Taking care of your machine

Let’s talk technical

What to do if it goes wrong

Getting in touch

Accessories

Rapid Power Pro

Hose

Included with

your machine

Accessory Bag

250ml

Ultra+ Solution

Wash Tool

Getting to know your machine

On/O

pedal

Recline

pedal

Clean water

/solution tank

Handle

Dirty water tank

release latch

Solution tube

connection port

Dirty water tank

release latch

SpinScrub brushes

Dirty water tank

Wash/Rinse dial

Nozzle

Cleaning

mode dial

Hose

connector

port

Solution tank cap

Clean water tank cap

Clean water/solution

tank release button

Technical Specication

Name Rapid Power Pro

Code ECGLV1B1

Part number 1-1-138933

Voltage 220-240~50/60Hz

Wattage 1200W

Cord length 8m

Weight 8.4kg

Subject to technical change without notice. *To purchase consumables and accessories, please visit vax.co.uk

Getting started

Quick cord

release hook

Trigger (hidden)

PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE

Getting started

IMPORTANT: Carpets should be dry vacuumed thoroughly before washing.

Test for colourfastness – Wet a white absorbent cloth with the solution. In a small hidden area of your carpet/rugs/

upholstery gently rub with the dampened cloth. Wait ten minutes and check for colour removal or bleed with a white paper

towel or cloth. If your carpet has more than one colour, check all colours.

Test your carpet/rugs/upholstery – Run the carpet washer over a small hidden area. If no pile distortion occurs continue

cleaning.

When cleaning an entire room, move furniture out of the area to be cleaned. If the furniture cannot be moved, place

aluminium foil or wax paper under the legs. This will prevent wood nishes from staining your carpet. Pin up furniture skirts

and curtains.

When using the carpet washer, basic safety precautions should always be observed and don’t over saturate your carpets.

Only use Vax carpet solution. Using other solutions may cause excess foaming and will invalidate your guarantee. The clean

water tank should only be lled with warm water (max 40°C). Filling the clean water tank with hot/boiling water will damage

your machine and invalidate the guarantee. This is a powerful carpet washer, before plugging in make sure all controls are

turned o. Hold carpet washer rmly when staring and during use.

Assembling your carpet washer

Line up the handle and

slide onto the main body.

Insert the 2 screws and

tighten using a cross head

screwdriver.

Tilt the clean water/

solution tank and line up

onto carpet washer. Push

tank back until it clicks

into place.

Wrap the power cord

around the cord hooks

for storage.

Using your machine

Using the carpet washer and cleaning modes

CAUTION: Always unplug the carpet washer before performing any maintenance/troubleshooting checks.

IMPORTANT: Your dirty water tank is tted with a oat. When the dirty water tank is full, or the oorhead is not in contact

with the carpet, the oat will shut o the suction on the carpet washer. You will be able to hear if this has happened as the

motor noise on the machine will increase. Once the oat is activated, empty the dirty water tank if full. If the dirty water tank

is not full then turn o your machine at the power switch and wait for the oat to settle.

NOTE: Carpets should be dry vacuumed thoroughly before washing. For best overall results use in deep clean mode.

For heavily soiled areas it may be necessary to repeat the cleaning process. Make crisscrossing strokes to the original

pattern and overlap each pass.

Quick Clean Mode: Best for a quick, surface clean because carpets dry in about 1 hour.

Deep Clean Mode: Best overall results for a thorough, deep clean.

Press the clean water/

solution tank release

button, pull and lift to

remove the tank.

Fill the clean water tank

with warm water (max

40°C). Replace the cap

before retting the tank.

Tilt the clean water/

solution tank and line up

onto the carpet washer.

Push the tank back until

it clicks into place.

Twist the water tank cap

anti-clockwise to remove.

Pour Vax carpet cleaning

solution into the tank.

Replace the cap.

Choose the cleaning mode

by turning the dial on the

base.

Quick Clean Mode: Best

for a quick, surface clean

with carpets drying in

about 1 hour.

Deep Clean Mode: Best

overall results for a

thorough, deep clean.

Turn the wash/rinse dial

to ‘wash’. The SpinScrub

brushes deep clean your

carpets with water and

detergent removing dirt

and stains.

Twist the solution tank

cap anti-clockwise to

remove.

TIP

Always empty and rinse out the clean and

dirty water tanks and leave to air dry before

replacing. Do not leave solution stored in

the tanks between uses.

Using your machine

Using Rinse mode

Using your machine

Turn the wash/rinse

dial to rinse. Only water

is released to remove

solution residue.

Plug into the mains,

press the on/o pedal

to switch on.

Press the recline pedal

and pull the handle

backwards.

Squeeze the trigger to

release solution and

water mix.

For best results apply

water/solution on the

forward stroke and

release the trigger to pick

up water/solution on the

backward stroke. Follow

with a slow additional dry

stoke without the trigger

pressed for a dryer nish.

For best results apply

water on the forward

stroke and release the

trigger to pick up water

on the backward stroke.

Follow with a slow

additional dry stoke

without the trigger

pressed for a dryer nish.

TIP

For best cleaning results use slow straight

parallel strokes. Intermittent dry forward

strokes will increase water pick up.

Using your machine

Using the hose and wash tool

CAUTION: Test for colourfastness – Wet a white absorbent cloth with the solution. In a small hidden area of your carpet/

rugs/upholstery gently rub with the dampened cloth. Wait ten minutes and check for colour removal or bleed with a white

paper towel or cloth. If your carpet has more than one colour, check all colours.

IMPORTANT: The carpet washer should be in the upright position when using the hose and tools; de-activating the

SpinScrub brushes and brushbar. Do not place the washer at top of stairs to avoid it falling down stairs. Place washer at

bottom of stairs and work up.

Pour Vax carpet cleaning

solution into the solution

side of the tank.

Slide the wash tool over

the tab at the end of the

hose until it clicks into

place.

Line up the arrow on the

hose with the arrow on

the washer and push the

hose into position. Rotate

the hose clockwise to lock

into place.

Fill the clean water

tank with warm water

(max 40°C).

Plug into the mains and

press the on/o pedal to

switch on.

Pull to open the solution tube connector cover and push

the solution tube rmly onto the port.

Open the hose connector

cover.

Turn wash/rinse dial

to wash.

Attach the wash tool.

Use the carpet washer

or hose to pick up

spills before washing

and cleaning

the area.

TIP

Inhaltsverzeichnis

Andere Vax Staubsauger Handbücher

Vax

Vax VX75 Bedienungsanleitung

Vax

Vax V-008T Bedienungsanleitung

Vax

Vax 6121 Multivax Bedienungsanleitung

Vax

Vax EVOLVE CLSV-LXKS Bedienungsanleitung

Vax

Vax H87-T1-B Bedienungsanleitung

Vax

Vax S10 Series Bedienungsanleitung

Vax

Vax H89-12V Series Bedienungsanleitung

Vax

Vax Mach Air Force U89-MAF Series Bedienungsanleitung

Vax

Vax MACH 7 VZL-6017 Series Bedienungsanleitung

Vax

Vax C87-VC-B Series Bedienungsanleitung

Vax

Vax C85-TO-Be Bedienungsanleitung

Vax

Vax V-2000S Bedienungsanleitung

Vax

Vax V-135 SERIES Bedienungsanleitung

Vax

Vax V-048 Bedienungsanleitung

Vax

Vax turbo force zero VZL-501 Bedienungsanleitung

Vax

Vax Performance Cyclonic V-008SC Bedienungsanleitung

Vax

Vax Washvax V-020 Series Montageanleitung

Vax

Vax U85-ACLG-BA Bedienungsanleitung

Vax

Vax H89-12V Series Bedienungsanleitung

Vax

Vax White C88-W2-B Bedienungsanleitung

Vax

Vax VX5 Bedienungsanleitung

Vax

Vax C91-M3 SERIES Bedienungsanleitung

Vax

Vax RAPID POWER Series Bedienungsanleitung

Vax

Vax C90-M1 Series Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
