Vax VX49 Montageanleitung

20L WET & DRY

MULTIFUNCTION

CLEANER

LET’S GET STARTED.

vax.com.au

vax.co.nz

VX49

20L Wet & Dry

MULTIFUNCTION CLEANER

Don’ts

Let’s talk safety

This machine is intended for household use only, and

NOT for commercial or industrial use.

WHEN USING THE VACUUM CLEANER:

Basic safety precautions should always be observed,

including the following:

• Do not leave the vacuum cleaner unattended when

plugged in. Unplug it from the socket when not in

use.

• Not to be used as a toy.

• Children should be supervised to ensure that they

do not play with the appliance.

• This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision

or instruction concerning the use of the appliance by

a person responsible for their safety.

• Use only as described in this manual. Use only Vax

recommended attachments.

• Do not use the vacuum cleaner if it has been

dropped, damaged, left outdoors or dropped

into water. Do not use the vacuum cleaner with

a damaged cord or plug. If the supply cord is

damaged, it must be replaced by the manufacturer

or a recommended service agent to avoid a hazard.

Basic safety precautions

• Do not handle the plug or machine with wet hands.

• Do not leave outdoors.

• Do not pull or carry by cord. Do not use cord as a

handle, close a door on the cord or pull cord around

sharp edges or corners. Do not run the machine

over the cord. Keep the cord away from heated

surfaces.

• Do not put any objects into openings or operate with

openings blocked. Keep them free of anything that

might reduce airow.

• Keep hair, loose clothing, ngers and all parts of

body away from openings and moving parts.

• Do not pick up hot coals, cigarette butts, ash,

matches or any hot, smoking or burning objects.

• Do not use the vacuum without the lters in place.

• Turn o all controls before unplugging.

• Do not vacuum up harmful or toxic material

(chlorine, bleach, ammonia, drain cleaner etc.).

• Do not vacuum up hard or sharp objects such as

glass, nails, screws, coins, etc.

• Do not vacuum baking soda or any other powder-

based carpet refresher or deodoriser.

• Do not vacuum plaster dust, concrete dust or any

other building or vitreous material.

Do’s

• Use only approved 10 amp extension cords. Care

should be taken to arrange the cord so that the cord

cannot be tripped over. Only use a weatherproof 10

amp extension cord when using in wet mode.

• Store the vacuum cleaner in a cool, dry area.

• To prevent dirty water from running into motor, do

not hold the appliance upside-down or lay on its

side. Use appliance in normal vacuuming position.

• Take extra care when cleaning on stairs.

• Turn o the on/o switch before unplugging the

vacuum cleaner.

• Do not carry appliance while motor is running.

• We recommend the use of a residual current device

with a residual current rating of 30mA or less.

WHEN USING BLOWER FUNCTION:

• Direct air discharge at work area only – never at

people or animals.

• Do not use blower as a sprayer in wet mode.

• Wear a dust mask and protective eye wear.

DAMAGE TO THE VACUUM CLEANER CAUSED

AS A DIRECT RESULT OF NOT ADHERING TO

THE GENERAL SAFETY INFORMATION AND THE

INSTRUCTIONS IN THIS USER GUIDE INVALIDATES

THE WARRANTY.

PLEASE KEEP THESE INSTRUCTIONS FOR

FURTHER USE.

If servicing of this product is required, it should only

be performed by a qualied service agent. Please

visit the Vax website for a most up to date list of vax

service agents or contact our Customer Care Line

on: AU: 1300 361 505 / NZ: 0800 800 900 (Mon-Fri

8:30am to 5:00pm)

vax.com.au / vax.co.nz

Always switch o and unplug the machine

from the electrical outlet before assembling,

opening, emptying the dirt container,

before connecting/disconnecting the

attachments, or carrying out maintenance or

troubleshooting checks.

WARNING

If the hose or tools are blocked, switch o

the cleaner and remove the blockage(s)

before re-starting your machine.

WARNING

Cleaning lters and replacing them regularly

maintains vacuum performance. Vax

recommends that your lters should be

checked, cleaned and replaced periodically.

WARNING

Thank you for buying this Multifunction Cleaner.

The VX49 is a powerful 20L Wet & Dry Multifunction cleaner ideal for both wet and dry

pick-ups. Featuring easy to manoeuvre castor wheels, this cleaner can be used both in the

home and garage, making it ideal for any home.

Taking care of your 20L Wet & Dry Multifunction Cleaner

Inside this guide are instructions on maintaining your new machine, so it’s always ready when

you are to tackle cleaning jobs throughout your home and garage.

We’re here if you need us

For troubleshooting simply visit or call:

Australia: 1300 361 505* New Zealand: 0800 800 900*

vax.com.au vax.co.nz

*Monday – Friday: 8:30am -5:00pm

Calls are charged at the standard local rate. Please make note of the serial

number and model number of the product before calling.

Contents Multifunction Cleaner

Included with

your machine

Let’s talk safety

Getting to know your machine

Getting started

Using your machine

Taking care of your machine

What to do if it goes wrong

Getting in touch

Accessories / Notes

3 Extension Tubes

1 Crevice Tool

1 Foam Filter

1 Dry Filter

1 Paper Dust Bag

1 Dual Function Floor Tool

Getting to know your machine

Name Wet & Dry Canister

Voltage 220-240V ~50/60Hz

Wattage 1250W

Tank capacity 20 Litres

Vacuum Pressure 14kpa

Sound Pressure 80dB(A)

Cord length 8m

Weight 5.1kg

Technical Speciﬁcation

Subject to technical change without notice. *To purchase consumables and accessories, please visit vax.com.au

Double

Insulated

Indoor

Use

Read

Instructions

Double

Insulated

Indoor

Use

Read

Instructions

Motor housing

Carry handle

Paper dust bag

Crevice attachment

Tank

Flexible hose

Accessory holders

Extension tubes x3

Filter Retainer

Foam lter

Dry lter

On/o switch

Dual function oor

tool (dry / liquids

accessory)

Assembling your wet & dry vacuum cleaner

PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE

Getting started

WARNING: To reduce the risk of personal injury, unplug the vacuum cleaner when assembling.

Place the tank upside down

and rmly press the four

caster wheels into the base

of the tank.

Place the top motor housing

cover onto the main tank

and secure into position

with the retaining clips on

each side. Use the screws

provided to attach the

motor housing handle.

Attach the 3 piece wand

to the end of the hose and

then the dual function oor

tool to the end of the wand.

Push the exible hose

into the connector and twist

slightly clockwise.

To remove the exible hose,

twist house anticlockwise

and pull.

Use bristles on the oor

tool for hard surfaces.

For soft surfaces such as

carpet, remove bristles by

pressing the 2 clips down.

SETUP the Cleaner from WET to DRY Vacuuming

NOTE: Empty the tank and dispose of any liquid which may have been picked up in wet mode.

NOTE: as the suction power decreases, this may indicate that the paper dust bag is full and needs replacing.

Remove the foam lter.

Dry o any excess moisture

from the oat cage.

Place the top motor housing

cover onto the main tank

and secure

into position with the

two retaining clips.

Attach the dry lter

beneath the motor housing

by pushing it on.

(This dry lter must

ALWAYS be used in dry

vacuuming mode to help

provide protection and

avoid motor damage).

Connect the vacuum

cleaner to the power supply

and switch ON

by pushing the on/o

switch “I”.

Once the dry lter has been

pushed onto the oat cage

- align the lter retainer cap

onto the base of lter and

turn clockwise to lock into

place.

Attach the paper dust

bag to the inner side

of the hose connector

on the inside of the tank

as shown.

Push the bag on to

the hose connector.

Using your machine

SETUP the Cleaner from DRY to WET Vacuuming

NOTE: Empty the tank and dispose of any dirt/dust which may have been picked up previously in dry mode.

NOTE: Clean and dry the inside and outside of the machine before storage.

IMPORTANT: Never vacuum dry dust and dirt with just this foam lter tted as it will provide little or no protection,

resulting in motor damage. To be used in wet mode only.

When vacuuming up uids

– the crevice nozzle can be

used when the water level

is too high to use the oor

tool. To ensure the

air ow is adequate, we

recommend that the end

of the nozzle is not totally

immersed.

Once the water tank is

emptied, place the top

motor housing cover back

onto the main tank and

secure into position with

the two retaining clips.

Connect the vacuum

cleaner to the power supply

and switch ON

by pushing the on/o

switch “I” to continue

to vacuum in wet mode.

When the uids have

reached the maximum tank

capacity, the oat regulator

will cover the motor lter

causing the motor to work

harder and it will become

noticeably nosier. At this

point turn o the machine

and unplug it from the mains

power and empty the tank.

Remove the dry lter and

replace it with the foam

lter – this slides over the

oat cage as shown.

Place the top motor housing

cover onto the main tank

and secure into position

with the two retaining clips.

Remove dust bag from

tank.

Using your machine

Remove the hose from

the standard hose outlet

used for cleaning modes

and place it on the blower

outlet located at the back of

the machine. Remove oor

tool and connect the crevice

nozzle to hose.

Connect the vacuum

cleaner to the power supply

and switch ON

by pushing the on/o

switch “I”.

WARNING: Keep bystanders clear from blowing debris (including persons and animals)

WARNING: Wear a dust mask and protective eye wear when using blower function .

IMPORTANT: Make sure the tank container is empty before using the blower.

SETUP the Blower Function

WARNING:

Keep bystanders clear from blowing debris (including persons and animals)

WARNING:

Wear a dust mask and protective eye wear when using blower function .

IMPORTANT:

Make sure the tank container is empty before using the blower.

Using your machine

Inhaltsverzeichnis

Andere Vax Staubsauger Handbücher

Vax

Vax Ultrixxcobalt Bedienungsanleitung

Vax

Vax Mach Zen Pet C85-MZ-Pe Montageanleitung

Vax

Vax Rapide Spring V-021AA Bedienungsanleitung

Vax

Vax Rapide Ultra Bedienungsanleitung

Vax

Vax impact Bedienungsanleitung

Vax

Vax Vivality V-0071 Produktinformationsblatt

Vax

Vax Zoom U87-ZM-B Bedienungsanleitung

Vax

Vax Mach 1 SERIES Bedienungsanleitung

Vax

Vax Air Steerable Ultra Lite U86-AC-Be Bedienungsanleitung

Vax

Vax VX32SK Bedienungsanleitung

Vax

Vax ultrixx V-040 Bedienungsanleitung

Vax

Vax Powermax VRS2 Series Bedienungsanleitung

Vax

Vax U88-T4 series Bedienungsanleitung

Vax

Vax RapidPower PRO ECGLV1B1 Montageanleitung

Vax

Vax Mach 9 Bedienungsanleitung

Vax

Vax EVERYDAY TURBO V-041 Bedienungsanleitung

Vax

Vax W86-DP-A series Montageanleitung

Vax

Vax Lightweight V-044AP Bedienungsanleitung

Vax

Vax VX78 Montageanleitung

Vax

Vax MACH PET Montageanleitung

Vax

Vax Mach Rapide XL V-027CC Bedienungsanleitung

Vax

Vax Essentials VEU-101 Bedienungsanleitung

Vax

Vax C85-WW-Be Montageanleitung

Vax

Vax VCAPH1500 Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
