OWNER’S MANUAL

Operating and Servicing Instructions

Please read these instructions

carefully before using your new

vacuum.

Designed with you in mind.™

You are now the proud owner of a VAX®.We trust your new purchase will bring you many years of satisfaction.

Vax was invented to change the way you vacuum. Using a design philosophy we call NEXT CLEAN™,Vax has combined

proven cleaning effectiveness with user-focused engineering, so you can clean more with less strain and bending.

That’s deep cleaning at a higher level.

Thank you for your support of VAX®products.

Visit our website at www.vaxusa.com

LIMITED WARRANTY

To the consumer, Royal Appliance Mfg. Co. warrants this VAX®brand vacuum cleaner to be free of defects in material or workmanship commencing

upon the date of the original purchase. Refer to your vacuum cleaner carton for the length of warranty and save your original sales receipt to validate

startof warranty period.

If the vacuum cleaner should become defective within the warranty period, we will repair or replace any defective parts free of charge. The complete

machine must be delivered prepaid to any VAX®Authorized Sales & Warranty Service Station. Please include complete description of the problem, date

of purchase, copy of original sales receipt and your name, address and telephone number. If you are not near a Warranty Station, call the factory for

assistance at USA & Canada: 1-877-VAX-USA-9 (1-877-829-8729). Use only genuineVAX®replacement parts.

The warranty does not include unusual wear, damage resulting from accident or unreasonable use of the vacuum cleaner. This warranty does not cover

brushes, filters and bulbs.This warranty does not cover unauthorized repairs. This warranty gives you specific legal rights and you may also have other

rights other rights, which mayvary from state to state in the USA.

ENGLISH

Safety Instructions Page 3, 4

Features Page 5

Assembly Page 6

How To Operate Page 7-9

Starting Up Page 7

Brush Vacuuming Page 7

Brushroll Reset Page 7

Vacuuming With Accessories Page 8

Vacuuming Upholstery, Furniture, and Curtains Page 9

After Use Page 9

Dirt Container and Filter Page 10-12

Dirt Container Removal and Cleaning Page 10

HEPA Filter Removal and Cleaning Page 10, 11

Exhaust Filter Removal and Cleaning Page 12

General Maintenance Page 13

Lightbulb Removal and Replacement Page 13

Troubleshooting Guide Page 14

TABLE OF CONTENTS

When you use an appliance, basic precautions should always be followed, including the following:

• READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.

• ALWAYS FOLLOW THESE SAFETY INSTRUCTIONS.

• BRING VACUUM CLEANER TO UPRIGHT POSITION WHEN USING THE HOSE AND ATTACHMENTS.

• DO NOT LEAVE VACUUM CLEANER UNATTENDED WHEN PLUGGED IN.

• REGULARLY CHECK THE FILTER TO CLEAN OR REPLACE.

• WARNING: FULLY ASSEMBLE CLEANER BEFORE OPERATING.

• WARNING: DO NOT USE SHARP OBJECTS TO CLEAN OUT THE HOSE SINCE THEY COULD CAUSE DAMAGE.

• WARNING: THE CORDS, WIRES, AND/OR CABLES SUPPLIED WITH THIS PRODUCT CONTAINS CHEMICALS,

INCLUDING LEAD OR LEAD COMPOUNDS, KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER

AND BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM. WASH HANDS AFTER USING.

IMPORTANT SAFETY INSTRUCTIONS

THIS VACUUM CLEANER IS INTENDED FOR HOUSEHOLD USE ONLY.

• Do not leave appliance when plugged in. Unplug from

outlet when not in use and before servicing.

• Do not use outdoors or on wet surfaces. Electrical shock

could occur.

•Do not allow to be used as a toy.Close attention is

necessary when used by or near children.

• Use only as described in this manual. Use only

manufacturer’s recommended attachments.

• Do not use with damaged cord or plug. If appliance is not

working as it should, has been dropped, damaged, left

outdoors, or dropped into water,return it to a service

center for inspection. Call 1-877-VAX-USA-9 (1-877-829-

8729) for the nearest service center.

•Do not pull or carryby cord, use cord as handle, close a

door on cord, or pull cord around sharp edges or corners.

Do not run appliance over cord. Keep cord away from

heated surfaces.

• Do not unplug by pulling on cord. To unplug, grasp the

WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY:

Your cleaner contains a thermal protective device to shut off the motor to avoid overheating. If this happens, turn switch off and unplug the cleaner. Inspect

the exhaust, inlet, hose, and filters for any blockage. Empty the dirt container and clean filters. After approximately 30 minutes the motor will have

cooled and the vacuum will be ready to use. NOTE: The cleaner must remain unplugged during the 30 minute cooling period.

WARNING:

To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other). This plug will fit in a polarized

outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install

the proper outlet. Do not change the plug in any way.

plug, not the cord.

• Do not handle plug or appliance with wet hands.

• Do not put any objects into openings. Do not use with

any opening blocked; keep free of dust, lint, hair, and

anything that may reduce air flow.

• Keep hair, loose clothing, fingers, and all parts of body

away from openings and moving parts.

• Do not pick up anything that is burning or smoking, such

as cigarettes, matches, or hot ashes.

• Do not use without dirt container and filters in place.

• Turn off all controls before unplugging.

• Look on your vacuum cleaner and follow all label and

marking instructions.

• Use extra care when cleaning on stairs.

• Do not use to pick up flammable or combustible liquids,

such as gasoline, or use in areas where they may be present.

• Keep the vacuum cleaner on the floor. Only the hand-

held vacuum cleaners may be set on furniture.

• Vacuum cleaner must be in the upright position to lift the

rotating brush off the carpet when doing above floor

cleaning.

• Do not use an extension cord with this vacuum cleaner.

• Store the vacuum cleaner indoors. Put the vacuum cleaner

away after use to prevent tripping accidents.

• Using improper voltage may result in damage to the

motor and possible injury to the user. Proper voltage is

listed on the cleaner plate.

• Hold plug when rewinding cord onto reel. Do not allow

plug to whip when rewinding.

• Unplug before connecting Turbo Tool.

• Do not carry vacuum cleaner by the cleaning wand tube.

This is not a carry handle.

SAVE THESE INSTRUCTIONS

FEATURES

1. Soft touch handle

2. ON/OFF button for brushroll

3. ON/OFF power button for vacuum

4. Soft touch cleaning wand handle

5. Cleaning wand release button

6. Hose fastening ring

7. Hose release button

8. Cleaning wand

9. Dirt container bottom release door

10. Hose clip

11. Reset button (located on back of nozzle)

12. Headlight

13. Brushroll

14. Soft touch furniture guard

15. Power cord hook

16. Crevice tool

17. Rotating upholstery tool

18. Accessory storage

19. Suction hose

20. Dirt container release and carry handle

21. Dirt container lid and lifetime HEPA filter

22. Bottom release lever

23. Dirt container

24. Exhaust filter (permanent filter)

25. Automatic cord rewind pedal

26. Exhaust grille

27.Power cord

28. Wheels

27 26

ASSEMBLY

TOOL REQUIRED: PHILLIPS OR FLATHEAD SCREWDRIVER

Using a Phillips or Flat Head screwdriver,

secure the handle by inserting the

provided four screws into the back of

the handle.

Align handle onto base of cleaner.

Pull cleaning wand to the front

of the cleaner and press hose

into handle assembly.

Insert excess cord into handle of

the cleaner by pushing down into

lower handle. CAUTION: AVOID

PINCHING CORD WHILE

INSERTING INTO HANDLE.

Connect the cleaning wand to

the opening on the base and push

the wand handle towards unit

until it snaps into place.

1. 2.

Use carry handle located on dirt

container lid.

TRANSPORTING

YOUR CLEANER

NOTE: Do not

carry vacuum

cleaner by the

cleaning wand

tube.This is not

acarry handle.

HOW TO OPERATE

STARTING UP

BRUSHROLL RESET

BRUSH VACUUMING

Holding the power cord by the plug, pull the

cordout completely. Red tag will indicate the

end of the cord. Plug into the outlet.

Tilt the upright vacuum cleaner

back before you start vacuuming.

At the same time, use your foot

to press the nozzle down onto

the carpet.

If something becomes lodged and

brushroll shuts off, turn cleaner off

and remove obstruction. Once the

problem has been fixed, the vacuum

cleaner can be switched back on

again after approximately 2 minutes

by pressing the reset button.

Switch the upright vacuum

cleaner on or off bypressing the

on/off switch.

For easier handling while

vacuuming, hook the power

cordonto the power cord

hook.

Brush Vacuuming on carpeted floors:

•The brushroll is switched on or off

using the brushroll on/off switch

(Diagram 2). Switch brushroll on for

carpeted floors.

• The rotating brushroll loosens deeply

embedded dirt and brings it to the

surface.

Vacuuming on smooth surfaces:

• Switch brushroll off to obtain the

best results when vacuuming smooth

barefloor surfaces.

NOTE:The brushroll is automatically switched off when it is in the vertical upright position.

RESET BUTTON

HOW TO OPERATE

VACUUMING WITH ACCESSORIES

1. 3.

6. 6a.

NOTE: The two accessory parts may be used on the suction hose and cleaning wand.

NOTE: For safety reasons when vacuuming stairs, leave the upright vacuum cleaner on the bottom stair.

HOSE

CLIP

CREVICE

TOOL

UPHOLSTERY

TOOL

FASTENING

RING

• Bring the upright vacuum cleaner into its vertical locking position. The brushroll switches off automatically in this position, thus preventing any damage to the

carpet while cleaning with hose or tools.

• To switch the upright vacuum cleaner on again when you resume vacuuming, tilt it back. The brushroll switches on again automatically.

Straighten the hose and hook the hose clip

into the fastening ring to prevent the upright

vacuum cleaner from toppling over during use.

While pressing the hose release

button, pull out the suction hose

to release from cleaning wand.

Press the release button to release the

cleaning wand.The cleaning wand with built-

in brush can be used for cleaning surfaces.

To access tools, rock upholstery tool

away from cleaner. To remove tools,

grasp tool and pull up and out of

accessory clip.

Then attach the accessory to the

suction hose.

The rotating upholstery tool may be turned through 360˚ to allow

vacuuming in poorly accessible areas such as corners, edges, stairs

and vertical surfaces.

HOW TO OPERATE

VACUUMING UPHOLSTERY, FURNITURE, AND CURTAINS

AFTER USE

Switch off the upright vacuum

cleaner and unplug the power

cordfrom the wall socket.

Pressing the button for automatic cordrewind

draws in the power cordautomatically. NOTE:

Hold onto the power cordto prevent the cord from

whipping during the automatic cord rewind.

After vacuuming, slide the suction

hose back into the cleaning wand

while holding the hose release button.

Use the cleaning wand as an

extension for long reaches.

Slide the hose into the cleaning wand

until locking mechanism engages.

Inhaltsverzeichnis

Sprachen:

Andere Vax Staubsauger Handbücher

Vax

Vax MACH-5 VZL-7015 Bedienungsanleitung

Vax

Vax W87-RP-C Bedienungsanleitung

Vax

Vax C90-M1 Series Bedienungsanleitung

Vax

Vax V-020 Bedienungsanleitung

Vax

Vax VPPST1600 Bedienungsanleitung

Vax

Vax Air Lift Steerable UCPESHV1 Montageanleitung

Vax

Vax quicklife widetrack2 V-045 Bedienungsanleitung

Vax

Vax Air Cordless Montageanleitung

Vax

Vax Bagged Cylinder Bedienungsanleitung

Vax

Vax WashVax V-020 PU Bedienungsanleitung

Vax

Vax C85-AA-Be Bedienungsanleitung

Vax

Vax Cordless Blade Pet Slimvac VX66 Bedienungsanleitung

Vax

Vax VX82 Bedienungsanleitung

Vax

Vax Quicklite Widetrack V-045 Bedienungsanleitung

Vax

Vax Impact 702 U86-IBe Series Montageanleitung

Vax

Vax VCC-08 Bedienungsanleitung

Vax

Vax U9O-MA-B Bedienungsanleitung

Vax

Vax Power 5 Pet VX28 Bedienungsanleitung

Vax

Vax U85-ACLG-BA Bedienungsanleitung

Vax

Vax VCT-01 Bedienungsanleitung

Vax

Vax V-044B Series Bedienungsanleitung

Vax

Vax Rapide Delux Produktinformationsblatt

Vax

Vax Air3 Agile U87-AA-B Bedienungsanleitung

Vax

Vax VC-H4510E-1/2/3 Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
