VDO CONTISYS VCI Gebrauchsanweisung
An overview of the most
important features.
With its variety of functions, the ContiSys VCI is
suitable as a separate solution as well as a supp-
lement to the ContiSys OBD.
Function EOBD
Mobile
Engine
Control
ABS EPB Climate
Product
ContiSys
OBD X X X X
ContiSys
VCI XXXXX
Function SRS-
Systems
TPMS Comfort Body Instrumen-
tation
Product
ContiSys
OBD X X
ContiSys
VCI XXXXX
Function Component
Activation
Catalogue
Module
Technical
Data: Inter-
face
Update
Service
Product
ContiSys
OBD optional
ContiSys
VCI XXX
2 years
included /
optional from
3rd year
The listed functions of the ContiSys VCI are only an extract.
The information provided in this brochure contains only general
descriptions or performance characteristics which may not
always apply in actual applications in the manner described and/
or which can change as a result of the further development of the
product. The information contained here is merely a technical
description of the product and is especially not intended to gua-
rantee any specific quality or service life. An obligation to provide
desired characteristics only exists if this has been expressly
agreed in the terms of contract. The right is reserved to alter the
delivery options and make technical changes.
A2C59513760 IContinental Trading GmbH IEnglish © 2010
Printed in Germany
Continental Trading GmbH
Sodener Str. 9
65824 Schwalbach
Deutschland
Telefon: +49 6196 87-0
Telefax: +49 6196 86571
www.contisys-diag.com, www.vdo.com
VDO – A Trademark of the Continental Corporation
ContiSys VCI.
www.vdo.com
Computerized and
high performance.
Reads and deletes fault memories, tests
and activates components, displays actu-
al values or looks up parts catalogues – the
ContiSys VCI offers you all of this and much
more.
This multifunctional diagnostics solution
was developed to satisfy the extensive de-
mands placed in the service area. In an in-
terplay with the simple and intuitively ope-
rable computer software ContiSys DSI, the
vehicle interface communicates with every
workshop PC via a modern, secure WLAN
interface. And it always remains up-to-date
if required thanks to the ContiSys Update
Plus software updating service.
ContiSys VCI.
Computerized and
high performance.
ContiSys VCI
Overview of Functions:
• Identifiescontroldevicesautomatically
• Readsanddeletesfaultmemories
• Reads,recordsandreplayslatestdata/
measured values
• Activatescomponents
Systems:
• Brakes:ABS,EPB,SBC
• SRS:airbags,belttensioners
• Servicedisplayreset–incl.CBS
• Codingofcontroldevices
• Injectorcoding
• Tyrepressuremonitoringsystems
• Bodycontrolcomputers
• Immobilizers
• Enginecontrols(petrol/diesel)
• Comfortsystems
• Steeringanglesensors
Technical Data:
• RS232,USBandWi-Fi(802.11g)
• Multiplexer
• Supportsthefollowingprotocolsandothers:
ISO9141-2(KLineandLLine),ISO15765-4(CAN),
SAEJ1850PWM,SAEJ1850VPW,ISO14320-
4KWP,ISO11519CAN(error-tolerant),SAEJ2411
singlewireCAN(GMLAN),SAEJ1708,SAEJ2610
(ChryslerSCI)
• Optionallyavailableconnectioncablefor:BMW,Fiat/
Alfa/Lancia,PSA,Mercedes,VAG
ContiSys VCI
ContiSys DSI.
Control centre with a standardized
system.
The ContiSys DSI diagnostics software is the
heart-piece of the multi-brand ContiSys VCI
diagnostics system. This is where such func-
tions as the reading and deletion of fault me-
mory entries, vehicle selection, vehicle system
identification, activation of components etc.
are performed. With the high-performance
software,datacanbeanalyzedandbranched
offtoothersoftwaremodules(e.g.partscata-
logues)whennecessary.Thesoftwarealways
remains self-explanatory and can be operated
without any previous experience.
Highlights:
• WindowsTMXP/Vista/Windows7
compatible
• Multilingual:GB,D,NL,F,E,P,I
• Intuitiveuserinterface
• Including2yearsofsoftwareupdates
• Freeappliancehotline
ContiSys Update Plus.
Updated at the click of a mouse.
The optional software updating service is also
available for the ContiSys VCI. Take advan-
tage of the diagnostics software updates,
even after the first two years.
