Moneris® Core Countertop

V400c

Setting up Your Hardware

Moneris Core® V400c Terminal: Setting up Your Hardware 1

Contents

Before you get started................................................................................................................................2

Hardware setup..........................................................................................................................................3

Connect cables to the all-in-one cable ...............................................................................................................3

Remove the protective film (if applicable).........................................................................................................4

Install the paper roll ...........................................................................................................................................4

Merchant support ......................................................................................................................................6

Moneris Core® V400c Terminal: Setting up Your Hardware 2

Before you get started

1. Confirm you have received the required hardware.

V400c terminal

All-in-one cable (connected to terminal)

Power cable

Paper roll

Ethernet cable

2. Review the Moneris Ethernet Readiness Checklist to ensure that your Ethernet service is ready to support

your terminal. The checklist is available online at moneris.com/support-v400c.

3. Go to Hardware setup on page 3.

Moneris Core® V400c Terminal: Setting up Your Hardware 3

Hardware setup

Connect cables to the all-in-one cable

The all-in-one cable is already connected to the terminal when Moneris ships it to you. These steps explain how

to connect cables to the all-in-one cable.

1. Plug one end of the Ethernet cable

into the port on the multi-port box

labelled with the network symbol

( ).

2. Plug the other end of the Ethernet

cable into the router / switch / hub /

internal wiring —whatever is

applicable to the high-speed Internet

service at your location. (If necessary,

please refer to the Moneris Ethernet

Readiness Checklist).

Moneris Core® V400c Terminal: Setting up Your Hardware 4

3. Plug the barrel connector of the

power cable into the port on the

multi-port box labelled with the

power symbol ( ).

4. Plug the other end of the power cable into a power source. The terminal will power on.

Recommendations: Always plug the power cable into the power source last to avoid power surges. Use a

power bar equipped with surge protection if possible. Do not use the power cable from your existing

terminal, as it may damage your new terminal.

IMPORTANT! You must use the exact power adaptor and cables provided by Moneris to work with your

terminal. Failure to do so may affect the operability of, or cause damage to, the equipment.

Remove the protective film (if applicable)

If your V400c terminal has a protective film covering the display screen, peel the film off.

Hint: Peel from the top right to the bottom left corner.

Install the paper roll

1. Lift the printer latch up, and then pull back to open

the lid and expose the paper well.

Moneris Core® V400c Terminal: Setting up Your Hardware 5

2. Insert the paper roll into the paper well with the

loose end unrolling from the top of the roll toward

the back of the terminal.

Note: If the paper is installed backward, your

printouts will be blank.

3. Unroll enough paper to extend at least one inch

(2.5 cm) over the top of the lid.

4. Close the lid, and press down to snap it back into

place so that the extended paper is pressed

securely against the top of the closed lid.

Note: The paper should unroll back over the top

and back of the terminal, not unroll over the

faceplate.

5. Your hardware setup is complete. To set up your software, refer to the Moneris Core® V400c Setting up

Your Software guide available at moneris.com/support-v400c.

Moneris Core® V400c Terminal: Setting up Your Hardware 6

Merchant support

If you need assistance with your payment processing solution, we’re

here to help, 24/7.

We’re only one click away.

Visit moneris.com/support-v400c to:

download additional copies of this guide and other resources;

consult the Moneris V400c Online Operating Manual in WebHelp format to understand all the options

on your terminal and how to use them.

Visit shop.moneris.com to purchase point-of-sale supplies and receipt paper

Visit insights.moneris.com for business and payment news, trends, customer success stories, and quarterly

reports & insights

Need us on-site? We’ll be there.

One call and a knowledgeable technician can be on the way. Count on minimal disruptions to your business as

our Field Services provide assistance with your payment terminals.

Can’t find what you are looking for?

Call Moneris Customer Care (available 24/7) toll-free at 1-866-319-7450. We’ll be happy to help.

You can also send us a secure message 24/7 by logging in to Merchant Direct® at

moneris.com/mymerchantdirect.

MONERIS, MONERIS BE PAYMENT READY & Design and MERCHANT DIRECT are registered trade-marks of Moneris Solutions Corporation. Mastercard is a

registered trademark, and the circles design is a trademark of Mastercard International Incorporated. INTERAC is a registered trade-mark of Interac Inc.

AMERICAN EXPRESS is a registered trade-mark of American Express Company. VISA is a trademark owned by Visa International Service Association and

used under license. All other marks or registered trade-marks are the property of their respective owners.

in any form or by any means, electronic, mechanical, including photocopying, be reproduced or transmitted without the authorized consent of Moneris

Solutions Corporation. This document is for informational purposes only. Neither Moneris Solutions Corporation nor any of its affiliates shall be liable for

any direct, indirect, incidental, consequential or punitive damages arising out of use of any of the information contained in this document. Neither Moneris

Solutions Corporation or any of its affiliates nor any of our or their respective licensors, licensees, service providers or suppliers warrant or make any

representation regarding the use or the results of the use of the information, content and materials contained in this document in terms of their

correctness, accuracy, reliability or otherwise.

Your gift card processing is governed by your agreement for gift card services with Moneris Solutions Corporation. Your loyalty card processing is governed

by your agreement for loyalty card services with Moneris Solutions Corporation. Your DCC processing is governed by your agreement for Dynamic Currency

Conversion services with Moneris Solutions Corporation. Your credit and/or debit card processing is governed by the terms and conditions of your

agreement(s) for merchant credit/debit card processing services with Moneris Solutions Corporation. It is your responsibility to ensure that proper card

processing procedures are followed at all times. Please refer to the Moneris Merchant Operating Manual (available at: moneris.com/support) and the

terms and conditions of your applicable agreement(s) for credit/debit processing or other services with Moneris Solutions Corporation for details.

V400c: Setting up Your Hardware guide EN (December 2019)
