Vermeiren SE04 Bedienungsanleitung

User manual

M A N U E L D ' U T I L I S A T I O N

G E B R U I K S A A N W I J Z I N G

G E B R A U C H S A N W E I S U N G

M A N U A L E D I I S T R U Z I O N I

M A N U A L D E I N S T R U C C I O N E S

I N S T R U K C J A O B S

U G I

N Á V O D K O B S L U Z E

SE04, SE104

2021-11

Content

Content.......................................................................................................................1

Preface........................................................................................................................2

1Description ....................................................................................................3

2Before use .....................................................................................................5

2.1 General safety instructions .............................................................................5

3Driving ...........................................................................................................6

4Operating console functions .......................................................................7

4.1 Switching ON / OFF ........................................................................................7

4.2 Failures and blocks .........................................................................................8

4.3 Battery status and charging ............................................................................8

4.4Navigation.......................................................................................................9

4.5 Settings button................................................................................................9

4.6 Joystick operation (driving and braking)........................................................12

4.7 Operating console lock .................................................................................12

4.8 Adjusting your body position .........................................................................12

4.9 Changing drive function ................................................................................13

4.10 Adjusting the chin controller..........................................................................14

5Troubleshooting..........................................................................................16

SE04, SE104

2021-11

Preface

Important note

This manual reflects the latest product developments. Vermeiren has the right to implement

changes to this type of product without being imposed to any obligation to adapt or replace similar

products previously delivered.

Pictures are used to clarify the instructions in this manual. Details of the depicted product may

deviate from your product.

Information available

On our website http://www.vermeiren.com/ you will always find the most recent version of the

information in this manual. Please consult this website regularly for possible updates.

Visually impaired people can download the electronic version of this manual and have it read out

by means of a text-to-speech software application.

This user manual of applied operating console

For user and specialist dealer

User manual of wheelchair

For user and specialist dealer

Installation manual of wheelchair

For specialist dealer

User manual of battery and charger

For user and specialist dealer

SE04, SE104

2021-11

Description

1 Description

The operating console built into your electric wheelchair enables you to control all the driving,

steering, braking and operating processes, as well as other adjusting motors (lifting column, seat

and back adjuster). The wheelchair's electrical unit and electronics are constantly being monitored

internally.

The following pictures show all parts that are relevant to the user.

Important parts (LiNX 400 screen)

1. ON / OFF button

with status indicator

2. Navigation button

main menu

3. Navigation button

submenu

4. Touch screen

5. Joystick

6. Connection point of

power cable

7. Connection point for

service purposes

8. Console base

9. Connection point of

power charger

SE04, SE104

2021-11

Description

Important parts (chin controller)

* Upon request, these buttons can be installed to switch sides.

10. ON / OFF button with status indicator

11. Functions indicator

12. Menu navigation button

13. Joystick

14. ON / OFF button (green, right) *

15. Navigation button (blue, left) *

SE04, SE104

2021-11

Before use

2 Before use

Risk of injuries and damage

•Do NOT install, maintain or use this product unless you have read and fully understood all

instructions in this manual and all relevant manuals regarding the wheelchair equipped with

this product.

•Do not try to open or disassemble the console in any case - there are no user-serviceable parts

inside.

•In case of doubts or questions, do not hesitate to contact your local specialist dealer, your care

provider, or your technical adviser to help you with this.

2.1 General safety instructions

Keep the following general warnings in mind during use:

•The operating consoles have been tested for electromagnetic compatibility on typical,

representative vehicles and comply with the appropriate EMC standards:

EN 12184: 2014, ISO7176-21: 2009.

•Nevertheless, sources of electromagnetic field may influence the driving performance of your

wheelchair, like the fields of mobile phones, power generators or high-power energy sources.

On the other hand, the electronics of your wheelchair can affect other electronic appliances

too, like alarm systems of shops and automatic doors. We therefore advise you to check your

operating console / wheelchair regularly for damage and wear, since these may enlarge the

interference.

•Be aware that the surface of the operating console may get very hot due to solar radiation or

heating devices. Be careful when touching.

•Make sure that the controller does not become colder or hotter than the allowed minimum

and maximum temperature, see the wheelchair user manual.

•Before switching the wheelchair on, be aware of your environment/situation. Adjust your

speed accordingly before driving off. We advise you to use the slowest speed setting to drive

indoors. For outdoor driving you can adjust the speed to a suitable speed at which you feel

comfortable and safe.

•Do not touch the connector pins. If you touch the pins, they can become dirty, or they can be

damaged by electrostatic discharge.

•If the wheelchair has not been fitted with a hand guard for the operating console, be aware

that your hand will not be protected from crushing, for example while manoeuvring towards a

table.

•The XLR connector on the controller is to be used exclusively for the intended purpose of

charging the battery. The warranty will lapse if any unauthorized device is connected to this

port.

•Make sure that the battery charger that is used with the vehicle has a drive-inhibited function

that is correctly connected for use with the controller. This drive-inhibited feature is intended

to prevent the chair from driving while the battery is being charged. If you are not sure, ask

your dealer.

•Immediately turn the controller off and consult your service agent if the vehicle:

o is damaged;

o does not behave the same every time;

o does not respond normally, the way you expect it to;

o becomes hotter than normal;

o smokes;

WARNING

Vermeiren is responsible for software updates/repairs. For adaptations in the software,

contact Vermeiren, see our website http://www.vermeiren.com/

SE04, SE104

2021-11

Driving

o does not change its speed when you adjust the speed dial;

o displays a fault on its fault indicator and the controller does not perform normally.

•Turn the controller off:

o when you do not use it;

o before you get in or out of the wheelchair;

o if your vehicle drives by itself or against your will. When you turn the controller off, the

vehicle will halt.

3 Driving

1. Press the ON/OFF button on the chin controller or screen.

2. If the LED on the ON/OFF screen button and chin controller button is green, the wheelchair

is powered and ready to go.

3. Check the battery status indicator. Charge the battery if necessary (see § 4.3).

4. Select the driving program and set the speed range, see driving functions in § 4.9.

5. Start moving the wheelchair by operating the joystick on the chin controller slowly

forwards/backwards.

6. The speed will increase when you push the joystick further out of the centre.

7. To turn left or right, push the joystick to the left or right.

8. To brake, move the joystick to neutral position.

9. After arrival, check the battery status and press the ON/OFF button.

10. Charge the battery if necessary.

SE04, SE104

2021-11

Operating console functions

4 Operating console functions

The operating console with chin controller enables you to control all driving components as well

as the motors to adjust your body position. For your own safety, and to prevent that the wheelchair

gets damaged, movements are monitored by the electronics. This may result in block of

movement, speed decrease or complete stop.

4.1 Switching ON / OFF

Put the joystick in the neutral (central) position before pressing the ON/OFF button.

If the console is switched on with the joystick out of the neutral position, the wheelchair will

not drive. Release the joystick (return to neutral) within 5 seconds to unlock the drive. If the

joystick is not released within 5 seconds, the fault turns into a module fault which is

indicated by the red blinking LED in the ON/OFF buttons. The wheelchair will not drive. To

clear the module fault, release the joystick and switch the operating console OFF and then

ON again.

•To switch the operating console ON: either press the green ON/OFF button (1) on the chin

controller, or press the ON/OFF screen button (2) or chin controller button (3).

The start screen is displayed for a few seconds, after which the operating screen appears.

The LED (status indicator) in the ON/OFF buttons goes on. When it turns green, the operating

console is ready for operation. When the LED starts blinking in red, there is a failure, see §4.2

and §5.

•To switch the operating console OFF when it is ON: either press the ON/OFF button (1) on

the chin controller, or press the ON/OFF screen button (2) or chin controller button (3).

The operating console will power down and the status indicator

goes out.

Switching ON/OFF

4.1.1 Emergency stop

If you need to stop a driving or body-positioning movement quickly, press the ON/OFF button to

perform an EMERGENCY STOP. The wheelchair will come to a halt quickly.

SE04, SE104

2021-11

Operating console functions

4.1.2 Sleep mode

The operating console will go into sleep mode after a period of inactivity (default5 minutes). When

the system sleeps, it is partially turned off to reduce energy consumption.

To reactivate the operating console, press a button or move the joystick.

4.2 Failures and blocks

When the operating console is powered and a failure

appears, the indicator of the ON/OFF buttons starts

blinking in red, see picture. The number of blinks indicates

the fault code. For a few seconds, a triangle with fault code

(A) is displayed. The ON/OFF buttons will keep blinking.

Failure indication and drive inhibited

In case of a failure, one or all functions of the operating

console are blocked. This is indicated by the “forbidden”-

symbol and the yellow warning bars (B).

The status is indicated by a small symbol (C) in the top corner of each screen.

For more information, see §5.

4.3 Battery status and charging

Risk of injuries and damage

•Follow the charging instructions in the wheelchair instruction manual and the supplier’s manual

of the battery charger.

The battery charge indicator (located at the top of the touchscreen) provides

an estimation of the remaining battery capacity.

In the following table all battery indications andtheir meanings are collected.

Battery status indication

Table 1: Battery status description

Display

Description

Meaning

Remarks

Most blocks are green

Battery capacity: more

than 50% of full

capacity.

Blocks turn yellow

Battery capacity level

is decreasing: less

than 50% of full

capacity

Consider recharging

the battery soon.

Blocks turn red

Battery almost empty

Stop and recharge

now.

Yellow or green blocks

with charging symbol

Battery is charging.

Battery capacity level is

indicated by colour.

Wait until battery is

completely charged.

WARNING

Andere Handbücher für SE04

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Vermeiren Mobilitätshilfe Handbücher

Vermeiren

Vermeiren Quava Bedienungsanleitung

Vermeiren

Vermeiren Eco-Plus Bedienungsanleitung

Vermeiren

Vermeiren 201 Delta Bedienungsanleitung

Vermeiren

Vermeiren Twist Bedienungsanleitung

Vermeiren

Vermeiren Four Light Bedienungsanleitung

Vermeiren

Vermeiren CARPO 4 LIMITED Bedienungsanleitung

Vermeiren

Vermeiren SLINGS Eagle Bedienungsanleitung

Vermeiren

Vermeiren Streeter Bedienungsanleitung

Vermeiren

Vermeiren 286i Bedienungsanleitung

Vermeiren

Vermeiren Normandie Bedienungsanleitung

Vermeiren

Vermeiren Eagle 620 Bedienungsanleitung

Vermeiren

Vermeiren Eco-Light Bedienungsanleitung

Vermeiren

Vermeiren Elios Bedienungsanleitung

Vermeiren

Vermeiren Eagle 620 Bedienungsanleitung

Vermeiren

Vermeiren Paris Bedienungsanleitung

Vermeiren

Vermeiren Goliat Bedienungsanleitung

Vermeiren

Vermeiren Magda Bedienungsanleitung

Vermeiren

Vermeiren Eco-Plus Bedienungsanleitung

Vermeiren

Vermeiren Kate Bedienungsanleitung

Vermeiren

Vermeiren Twin-Light Bedienungsanleitung

Vermeiren

Vermeiren 276 Bedienungsanleitung

Vermeiren

Vermeiren Quava Bedienungsanleitung

Vermeiren

Vermeiren Lyna II Bedienungsanleitung

Vermeiren

Vermeiren Goliat Bedienungsanleitung

Beliebte Mobilitätshilfe Handbücher anderer Marken

Alber

Alber Scalamobil iQ Bedienungsanleitung

Ferno

Ferno CCT-PX Bedienungsanleitung

HEPRO

HEPRO Gripo Bedienungsanleitung

Otto Bock

Otto Bock Pheon 3R62 Bedienungsanleitung

NRS Healthcare

NRS Healthcare M11090 Bedienungsanleitung

Medline

Medline MDS86835DSHEC Installationsanleitung

Guldmann

Guldmann Twin Turner II Bedienungsanleitung

Drive

Drive ROOMBA Bedienungsanleitung

Gate

Gate Balder Bedienungsanleitung

Decon wheel

Decon wheel TNS Notos Bedienungsanleitung

ExoAtlet

ExoAtlet ExoAtlet-II Bedienungsanleitung

Invacare

Invacare Storm Series Bedienungsanleitung

Rhythm Healthcare

Rhythm Healthcare B3800F Bedienungsanleitung

AMF-BRUNS

AMF-BRUNS PROTEKTOR Bedienungsanleitung

Drive DeVilbiss Healthcare

Drive DeVilbiss Healthcare OTTER Bedienungsanleitung

Rhythm Healthcare

Rhythm Healthcare C500U Bedienungsanleitung

Lumex

Lumex RJ4200A Bedienungsanleitung

Rebotec

Rebotec Jumbo Bedienungsanleitung
