Installation and Operation Guide

XX232-00-02

V662-D High-Resolution

Analog WDR Camera

Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the

operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed

to be used in life-critical situations and must not be used for this purpose.

Vicon Industries Inc., 89 Arkay Drive, Hauppauge, New York 11788

Tel: 631-952-2288 Fax: 631-951-2288 Toll Free: 800-645-9116

24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300

Document Number: 8009-8232-00-02

Product specications subject to change without notice.

Issued: 513

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

PRODUCT TO RAIN OR MOISTURE.

DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING : TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER(OR BACK).

NO USER-SERVICABLE PARTS INSIDE.

REFFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

EXPLANATION OF GRAPHICAL SYMBOLS

The lightning flash with arrowhead symbol, within an equilateral triangle,

is intended to alert the user to the presence of uninsulated ''dangerous

voltage'' within the product's enclosure that may be of sufficient magnitude

to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert

the user to the presence of important operating and maintenance

(servicing) instructions in the literature accompanying the product.

PRECAUTIONS

Safety

Should any liquid or solid object fall into the cabinet,

unplug the unit and have it checked by

qualified personnel before operating it any further.

Unplug the unit from the wall outlet if it is not going to

be used for several days or more.

To disconnect the cord, pull it out by the plug. Neve

pull the cord itself.

llow adequate air circulation to prevent internal heat

build-up. Do not place the unit on soft surfaces (rugs,

carpets, sofas, etc.) or near materials (curtains,

draperies) that may block the ventilation holes.

Height and vertical linearity controls located on the

rear panel are for special adjustments by qualified

personnel only.

Installation

Do not install the unit in an extremely hot or humid place

or in a place subject to excessive dust, mechanical

vibration.

The unit is not designed to be waterproof.

Exposure to rain or water may damage the unit.

Cleaning

Clean the unit with a slightly damp soft cloth.

Use a mild household detergent. Never use strong

solvents such as thinner or benzine as they might

damage the finish of the unit.

Retain the original carton and packing materials for safe

transport of this unit in the future.

FCC COMPLIANCE STATEMENT

CE COMPLIANCE STATEMENT

INFORMATION TO THE USER:THIS EQUIPMENT HAS BEEN TESTED

AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE,

PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED

TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL

INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL

ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN RADIATE

RADIO FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL

INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO

CAUSE HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE

REQUIRED TO CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

CAUTION: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED

BY THE PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER'S

AUTHORITY TO OPERATE THE EQUIPMENT.

THIS CLASS A DIGITAL APPARATUS COMPLIES WITH CANADIAN ICES-003.

CET APPAREIL NUMÉRIQUE DE LA CLASSE A EST CONFORME À LA NORME

NMB-003 DU CANADA.

WARNING: This is a Class A product. In a domestic environment this product

may cause radio interference in which case the user may be required to take

adequate measures.

IMPORTANT SAFEGUARDS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s

instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or

other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug.

A polarized plug has two blades with one wider than the other. A grounding type

plug has two blades and a third grounding prong. The wide blade or the third prong

are provided for your safety. If the provided plug does not fit into your outlet, consult

an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by

the manufacturer, or sold with the apparatus. When a cart is used,

use caution when moving the cart/apparatus combination to avoid

injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for

long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is

damaged, liquid has been moisture, does not operate normally,

or has been dropped.

15. CAUTION – THESE SERVICING INSTRUCTIONS ARE FOR USE BY QUALIFIED

SERVICE PERSONNEL ONLY. TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT PERFORM ANY SERVICING OTHER THAN THAT CONTAINED IN THE

OPERATING INSTRUCTIONS UNLESS YOU QRE QUALIFIED TO DO SO.

16. Use Certified/Listed Class 2 power source only.

17. Apparatus shall not be exposed to dripping or splashing and no object filled with

liquids, such as vases, shall be placed on the apparatus.

CONTENTS OF PACKAGE

Installation of the camera must be performed by qualified service personnel in

accordance with all local and national electrical and mechanical codes.

Carefully remove the color camera and its accessories from the carton and verify that

they were not damaged in shipment.

The content of the package includes:

1. Color CCD camera

2. Mini-DIN connector (for video-or dc-type auto-iris lens)

3. CS adapter ring for C mounting "C" lenses

TABLE OF CONTENTS

INTRODUCTION --------------------------------------------------------------------------------------- 6

CAMERA OVERVIEW -------------------------------------------------------------------------------- 7

BACK FOCUS ADJUSTMENT---------------------------------------------------------------------- 8

THE DEFINITION OF TERMS ---------------------------------------------------------------------- 9

CAMERA ADJUSTMENT ---------------------------------------------------------------------------- 11

CONTROL AND CONNECTIONS / DAY&NIGHT I/O TERMINALS----------------------- 18

LENS ------------------------------------------------------------------------------------------------------ 19

SPECIFICATIONS ------------------------------------------------------------------------------------- 20

INTRODUCTION

The camera provides high-quality image using Sony®Wide Dynamic 1/3” Super-HAD™

II PS 960H CCD and DSP.

Features:

z1/3" Super-HAD™II PS 960H CCD

zSuper high-resolution of 650TV lines

zWide Dynamic Range (~x512)

zExcessive High-Light Compensation

zBack Light Masking (MAX. 15 area)

z2D-NR, 3D-NR (DNR Demo)

zDay & Night(Auto, Manual, External, Filter delay)

z0.4 lux(Color), 0.04 lux(B/W), 0.001 lux(Slow-Shutter) @ F1.4 Sensitivity

zSens-Up (~x32)

zVarious Detection Method (zone detection, motion trace, face trace, mine area,

absent detection, cross object counting, entrance counting)

zScene Change Detection

zVarious Alarm Method (Period, Snooze, Polarity Select)

zFrame Control (Auto, 1~7 sec)

zPrivacy Mask or Mosaic (MAX. 15 area/4-point polygonal/transparency)

zDigital PTZ

zWhite Pixel Remove

zBack Light Compensation

zDigital Effect (H/V reverse, 180 degree rotate, inverse, freeze)

zSystem Lock (4-Digit password)

zAuto Electronic Shutter [1/50 ~ 1/100,000] and manual electronic shutter

modes [1/50 ~ 1/10,000]

zC/CS, back-focus cam for easy adjustment

zAuto and Manual white balance modes

zSupport Line-Lock external synchronization

zRS-485 Remote camera control

zOn Screen Display (OSD)

zCompatible with Video, DC type lenses with OSD select

zQuick connect for Video or DC lens with 4-pin connector

zUser Certified / Listed Class 2 power source only

zOperates in 12VDC or 24VAC

CAMERA OVERVIEW

SIDE VIEW

TOP VIEW

FRONT VIEW

nLeft Button

oUp Button

pEnter Button

qRight Button

rDown Button

sDay/Night External I/O

Motion ALARM OUT

RS - 485

UTP(optional)

tPower Indicator

uVideo Output Connector (BNC)

vUTP or BNC Transformation Switch

(optional)

wAC/DC Compatible Input Terminal

AC Power Cord

REAR VIEW

REAR VIEW (Free Voltage)

BACK FOCUS ADJUSTMENT

When installing a zoom lens on a camera, sometimes the lens cannot be focused at

either end of the zoom range. If this problem occurs, it may be necessary to adjust the

camera back focus. By adjusting the back focus, the position of the pick-up device in

relation to the rear of the lens is changing.G

1. Secure the lens to the camera body, and plug in the auto iris connector.

2. Place a neutral density filter in front of the lens. This will force the lens iris to open to

the max. (In the case of a manual lens, open the lens iris to its maximum.)

3. Set the focus of the lens to full infinity.

4. Set the zoom to Wide.

5. Aim the camera at a high contrast object a distance away and move the back-focus

lever to bring object into focus.

6. Set the zoom to Tele.

7. Repeat the above steps until the focus remains clear throughout the zoom range.

Zoom

Focus

Back-focus lever

THE DEFINITION OF TERMS

White Balance

Compensates for deviations in the white color caused by changes in the color

temperature of the light source so that the colors are reproduced correctly.

Auto Exposure

Automatically adjusts the images to the optimum brightness.

SHT(Electronic Shutter)

Controls the integration time (exposure) of the photodiode array and reduces, blooming

overexposure, and smear when capturing moving objects.

Flicker(FLC)

Avoids image flicker when there is a discrepancy between current and frequency

AGC(Automatic Gain Control)

Automatically adjusts (boosts) the video signal to the required level to produce a quality

image in low light situations

Sens-Up(Slow Shutter)

Allows the video sensor of a camera to control sensitivity as it automatically detects the

light level in dark environments to maintain a clear picture.

Back Light Compensation (BLC)

Compensates for the brightness of the subjects with a large amount of background light

that would make it practically impossible to see any details of the subjects. Adjusts the

iris so that a distinctive subject and the background are delivered at the same time.

Wide Dynamic Range (WDR)

Extends the action of BLC. When both high-brightness subjects and low-brightness

subjects are in the same scene, overexposure in the high-brightness subjects or loss of

dark detail in the low-brightness subjects may occur. WDR combines the two images to

eliminate over exposure and loss of detail.

EHLC(Excessive High Light Compensation)

Brings excessively high-brightness subjects into focus.

Mask

Hides one or more areas that the user does not want to be displayed on screen. Masks

can be set with their own display area, color, darkness and mosaic processing.

Detection

Detects motion within the scene using one of the available methods. Some methods

trigger the Alarm output.

Sharpness

Reducing this parameter adjusts the noise level to smooth out the "noise" caused by the

compression.

Caution should be taken not to reduce it too much, which may result in a blurred

image.

Resolution

Controls the display fine details. The higher the resolution, the higher level of details can

be seen.

2D_ / 3D_NR (Digital Noise Reduction)

Adjusts the illuminance noise level in low light situations by reducing image noise in

order to improve the image. - 2D-NR is space-based and 3D-NR is time-based.

Frame Control

Specifies how many frames are generated/transmitted in a unit of time.

The more frames there are, the smoother the image will be, The television

system(NTSC/PAL) has adopted 30/25 frames per second(fps) to be regarded as

completely smooth image. However, when recording video data, video surveillance

systems often use lower fram rates to reduce the size of the recording data.

Nega

Reverses the color signals for the Chroma signal so the image looks like a “negative.”

d-PTZ(Digital Pan/Tilt/Zoom)

Adjusts the camera position and zooms in on a section of the overall full image. The

pixels in this area are then enlarged so the image is the same size as the original, giving

the appearance of being zoomed in. Widen the intervals between the pixels in the

original signal according to the magnification, and then filing these intervals with

interpolation signals.

Communication

Allows for the connection to external devices, such as keyboards, through the menu

interface.

Iris Control

Automatically adjusts the level of the iris according to changing light levels without

having to manually turn a ring on the lens to open or close the iris.

LLC

In the line lock mode, the AC power supply and vertical sync signal of the cameras are

synchronized.

White Pixel

Automatically detects and compensates for peak white levels to maintain the image

quality.

White pixels whose frequency of occurrence varies in proportion to the temperature are

sometimes observed when the devices are used under the influence of external factors

or especially high temperatures.

Day/Night

Allows the camera to be effective even in the lowest of light conditions while still

showing clear color pictures during daylight hours. Day/Night cameras automatically

change from color images to black and white when the light levels drop below a certain

level.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Vicon Sicherheitskamera Handbücher

Vicon

Vicon V920B Series Bedienungsanleitung

Vicon

Vicon ROUGHNECK V910 Bedienungsanleitung

Vicon

Vicon V920B Series Bedienungsanleitung

Vicon

Vicon Roughneck V894CSH Series Bedienungsanleitung

Vicon

Vicon V672D Betriebsanleitung

Vicon

Vicon Roughneck Pro V2002D-PTZ Bedienungsanleitung

Vicon

Vicon Roughnec V922D Series Bedienungsanleitung

Vicon

Vicon Surveyor 2000 Bedienungsanleitung

Vicon

Vicon Surveyor 282-20-02 Series Bedienungsanleitung

Vicon

Vicon XX247-32-00 Bedienungsanleitung

Vicon

Vicon Vantage V16 Bedienungsanleitung

Vicon

Vicon Cruiser SN663V Betriebsanleitung

Vicon

Vicon V-CELL-HD Bedienungsanleitung

Vicon

Vicon SVFT-W35 Bedienungsanleitung

Vicon

Vicon V840D Series Bedienungsanleitung

Vicon

Vicon V960D Series Bedienungsanleitung

Vicon

Vicon Surveyor MKII Series XX282-20-00 Bedienungsanleitung

Vicon

Vicon i-onyx MP-980DN Handbuch

Vicon

Vicon V1020-WIR-180-1 Bedienungsanleitung

Vicon

Vicon Roughneck Pro V2000B Series Bedienungsanleitung

Vicon

Vicon Roughneck Pro V2000D Series Bedienungsanleitung

Vicon

Vicon Surveyor MKII Series XX282-40-01 Kurzanleitung

Vicon

Vicon V992B-IR4 Bedienungsanleitung

Vicon

Vicon V894MSH Bedienungsanleitung

Beliebte Sicherheitskamera Handbücher anderer Marken

Okina USA

Okina USA SIR36-870VF650LP Bedienungsanleitung

Divio

Divio NDR155PA Bedienungsanleitung

Canon

Canon VB-C500D Bedienungsanleitung

Easy Access

Easy Access EasyGuard Bedienungsanleitung

Vivotek

Vivotek FD9389-EHV-v2 Bedienungsanleitung

TUYA

TUYA COSMO W2 Bedienungsanleitung

Eusso

Eusso UNC7500-IR Einrichtungshandbuch

urmet domus

urmet domus 1096/204 Bedienungsanleitung

VC VC20 series Bedienungsanleitung

Axis

Axis Q1614 Bedienungsanleitung

ieGeek

ieGeek DD201 Bedienungsanleitung

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Bedienungsanleitung

Grundig

Grundig GCH-K0274P Bedienungsanleitung

Lorex

Lorex VANTAGE LBC7032 Bedienungsanleitung

4xem

4xem WPT Bedienungsanleitung

Samsung

Samsung SCV-3082 Bedienungsanleitung

Vitek

Vitek VTC-C544 Bedienungsanleitung

Lumens

Lumens VC-A50PNW Bedienungsanleitung
