USE AND CARE MANUAL

Built-in

Refrigerator/Freezers

Warnings

WARNING

To reduce the risk of fire, electric shock, or injury when using

your unit, follow these basic precautions:

• Read all instructions before using the unit.

• Never allow children to operate, play with, or crawl inside

the unit.

• Never clean unit parts with flammable fluids. The fumes can

create a fire hazard or explosion.

• Always turn the power on/off switch (located behind the air

grille on top right side) to the OFF position before

attempting to change light bulbs, clean, or service the unit.

FOR YOUR SAFETY

DO NOT STORE OR USE GASOLINE OR OTHER

FLAMMABLE VAPORS AND LIQUIDS IN THE VICINITY OF

THIS OR ANY OTHER APPLIANCE. THE FUMES CAN

CREATE A FIRE HAZARD OR EXPLOSION.

WARNING

ELECTRICAL SHOCK HAZARD

Plug into a grounded 3-prong outlet.

If a 2-prong wall receptacle is encountered,

contact a qualified electrician.

Do not remove ground prong.

Unit must be grounded at all times.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these instructions can result in death, fire, or

electrical shock.

Your safety is important to us. This use and care manual

contains safety symbols and statements. Please pay special

attention to these symbols and follow any instructions given.

This symbol alerts you to hazards such as fire,

electrical shock or other injuries.

Congratulations

Congratulations and welcome to the elite world of Viking

ownership. We hope you will enjoy and appreciate the care

and attention we have put into every detail of your new,

state-of-the-art refrigerator.

Your Viking appliance is designed to offer years of reliable

service. This Use and Care Guide will provide you with the

information you need to become familiar with your refrigerator’s

care and operation.

Your complete satisfaction is our ultimate goal. If you have any

questions or comments about this product, please contact the

dealer from whom you purchased it, or contact our Consumer

Support Center at 1-888-VIKING1.

We appreciate your choice of a Viking refrigerator and hope

that you will again select our products for your other major

appliance needs.

For more information about the complete and growing

selection of Viking products, contact your dealer or visit us

online at vikingrange.com.

Warnings

WARNING

To avoid serious illness or death, do not use unit where water

is unsafe or of unknown quality without adequate disinfection

before or after use of filter.

WARNING

To avoid electrical shock which can cause severe personal

injury or death, turn power disconnect switch to OFF before

cleaning. After cleaning, return power disconnect switch to

ON position.

WARNING

ELECTRICAL SHOCK HAZARD

Disconnect power or turn power

disconnect switch to OFF position before

removing top grille. Failure to do so can

result in death or electrical shock.

WARNING

BURN HAZARD

Do not touch condenser coils near

defrost pan.

Doing so can result in burns.

DANGER

RISK OF CHILD ENTRAPMENT

Before You Throw Away Your Old Refrigerator or Freezer:

• Take off the doors.

• Leave the shelves in place so that children may not easily

climb inside.

IMPORTANT: Child entrapment and suffocation are not

problems of the past. Junked or abandoned refrigerators are

still dangerous... even if they will sit for “just a few days.”

Table of Contents

Getting Started

Important Safety Instructions ______________________6

Proper Disposal (of old refrigerator) ________________7

Features __________________________________________ 8

Product Controls

Settings and Functions ____________________________ 14

Operation

Refrigerator (all units) _____________________________19

Freezer (all units) __________________________________ 24

Automatic Ice Maker ______________________________ 25

Automatic Dispenser ______________________________ 27

Installing Water Filter ______________________________ 28

Replacing Water Filter _____________________________ 29

Food Storage Guide _______________________________ 30

Product Care

Cleaning and Maintenance ________________________ 32

Troubleshooting ___________________________________ 39

Service Information ________________________________ 42

Warranty __________________________________________ 43

Getting Started

Proper Disposal (of old refrigerator)

Important Safety Instructions

Getting Started

• Install and level your refrigerator on a floor that will hold its

weight, plus food weight (approximately 1200 pounds

[540kg]) and in an area suitable for its size and use.

• Do not install a refrigeration unit near a heat source, nor in a

location where the surrounding temperature will fall below

60Þ F (16Þ C).

• Do not allow your refrigerator to be exposed to the weather

or outdoor elements.

• Connect your refrigerator only to the appropriate kind of

electrical outlet, with the correct power supply and

grounding. (Refer to the Electrical Requirements section

of the Installation Instructions.)

• Use the refrigerator only for the uses described in this

manual.

• Properly maintain the refrigerator.

• Be sure the refrigerator is not used by anyone unable to

operate it properly.

DANGER

RISK OF CHILD ENTRAPMENT

Before You Throw Away Your Old Refrigerator or Freezer:

• Take off the doors.

• Leave the shelves in place so that children may not easily

climb inside.

IMPORTANT:

Now that you have a new refrigerator, it is extremely important

that you dispose of your old appliance in a way that minimizes

the possibility that children will find it. There have been many

cases in years past of children crawling inside junked and

abandoned refigerators and becoming trapped or suffocated.

Contact your municipal waste disposal authority to find out

the best and safest way to dispose of your old refrigerator.

Getting Started

General Features

• ProChill™ Temperature Management System

The variable speed single compressor system

includes the quietest, most technologically

advanced compressor available. Electronic controls

maintain temperatures to within 1Þ F

and the multi-channel airflow system removes

odors and excess humidity.

• Convertible Meat Savor™/Produce Drawer

(all models except all freezer)

Equipped with a separate temperature control, the

Meat Savor/Produce Drawer can be set for either

produce or long-term fresh meat storage.

• Adaptive Defrost

Controls the timing of the defrost periods based

on refrigerator usage and can extend the defrost

up to 96 hours.

• Factory Installed Automatic Ice Maker

All models have an automatic ice maker with large

capacity ice buckets.

• Door Alarm

Sounds and glows to warn that fresh food and/or

freezer door have been ajar for three minutes.

• True 24” Depth

Keeps items in back within easy reach and allows

refrigerator to fit flush into 24” deep installation

cutout (Designer and Full Overlay models).

30” W. Model Shown

1. Electronic Controls

2. Lights

3. Wire Shelves (6)

4. Non-Adjusting Freezer

Shelf (1)

5. Patented Modular

Storage System

• Gliding Ice Drawer

with 2 Ice Bins

• Gliding Freezer

Baskets (2)

6. Adjustable Door Bins

(Patent Pending)

30” W. Models–

Full-Width Bins (3)

36” W. Models–

Full-Width Bin (1)

Half-Width Bins (4)

Features (built-in all freezer)

Getting Started

Features (built-in all refrigerator)

30” W. Model Shown

1. Electronic Controls

2. Lights

3. Dairy Compartments (2)

4. Adjustable Door Bins

(Patent Pending)

30” W. Models–

Full-Width (4)

36” W. Models–

Half-Width (2)

Full-Width (3)

5. MEAT SAVOR™/PRODUCE

Drawer

6. Moisture-Controlled

Produce Drawers (2)

7. Spillproof Shelves

30” W. Models–

Full-Width (4)

36” W. Models–

Half-Width (4)

Full-Width (2)

8. Deli Compartment

Drawers (2)

Features (built-in side-by-side, non-dispenser)

1. Electronic Controls

2. Spillproof Shelves (5)

3. Lights

4. Dairy Compartments (2)

5. Adjustable Door Bins (4)

(Patent Pending)

6. Deli Compartment(s)

42” W.– Full-Width (1)

48” W.– Half-Width (2)

7. MEAT SAVOR™/PRODUCE

Drawer (1)

8. Moisture-Controlled

Produce Drawer(s)

42” W.– Full-Width (1)

48” W.– Half-Width (2)

9. Glide-Out Freezer

Baskets (2)

10. Ice Bucket (1)

11. Non-Adjusting Freezer

Shelf (1)

12. Adjustable Freezer

Shelves (3)

13. Adjustable Freezer Door

Bins (3)

48” W. Model Shown

Getting Started

1. Electronic Controls

2. Spillproof Shelves (5)

3. Lights

4. Dairy Compartments (2)

5. Adjustable Door Bins (4)

(Patent Pending)

6. Deli Compartment(s)

42” W.– Full-Width (1)

48” W.– Half-Width (2)

MEAT SAVOR™/PRODUCE

Drawer (1)

8. Moisture-Controlled Produce

Drawer(s)

42” W.– Full-Width (1)

48” W.– Half-Width (2)

9. Water Filter (1)

10. Glide-Out Freezer

Basket (1)

11. Non-Adjustable Freezer

Shelf (1)

12. Adjustable Freezer Shelves

(3)

13. Ice and Water Dispenser (1)

14. Ice and Storage Bucket (1)

15. Adjustable Freezer Door

Bins (3)

16. Built-In Ice and Water

w/Motorized Ice Dispenser

(Patent Pending)

48” W. Model Shown

10 7

Features (built-in side-by-side, dispenser) Features (built-in bottom-mount)

1. Electronic Controls

2. Spillproof Shelves (5)

Half-Width (4)

Full-Width (1)

3. Dairy Compartments (2)

4. Adjustable Door Bins (5)

(Patent Pending)

Half-Width (4)

Full-Width (1)

5. Wire Freezer Baskets (2)

6. Ice Bucket (1)

7. MEAT SAVOR™/PRODUCE

Drawer (1)

8. Moisture-Controlled

Produce Drawers (2)

9. Lights

36” W. Model Shown

Product Controls

Settings and Functions

In order for your new refrigerator to work properly, it is

important that you understand its various features, controls,

and how to use them.

Power On/Off Switch (Power Interruption Switch)

The power on/off switch is located behind your refrigerator's

top grille. It is used to turn the power off when cleaning the

refrigerator or changing the light bulbs. Your refrigerator

arrives from the factory with the power interruption switch on.

To turn power off, remove the center grille blade. Press the

power on/off switch to the off position.

To turn power on, press power on/off switch to the on

position. Replace the center grille blade.

IMPORTANT: Be sure the power on/off switch is in the on

position after cleaning or changing light bulbs.

Showroom Mode Initiation

Showroom mode allows electronic controls and interior lights

to function independently of refrigeraton system.

To enter the showroom mode: Press and hold “DISPLAY

ON”/”ACTIVATE CONTROLS” pads; while holding, press and

hold “HIGHER TEMP” and “ALARM OFF” pads together.

Three beeps will sound and unmarked blue light will be lit.

Showroom mode is entered.

To exit the showroom mode: press and hold “DISPLAY

ON”/”ACTIVATE CONTROLS” pads; while holding, press and

hold “HIGHER TEMP” and “ALARM OFF” pads together.

Three beeps will sound and control will revert to normal

operation and display.

Power Switch

DISPLAY

HIGHER

TEMP

ALARM

OFF

ACTIVATE

CONTROLS

Settings and Functions

Electronic Temperature Settings

Your refrigerator's electronic controls are located behind the

door above the cabinet interior. To activate the electronic

control panel, press “DISPLAY ON”/“ACTIVATE CONTROLS”

pads. All other pads, except the “ALARM OFF” pad, will

remain inactive until the “DISPLAY ON”/”ACTIVATE

CONTROLS” pads are pressed. Once activated, pads remain

programmable for at least ten minutes.

When you first plug your new refrigerator in, you will find that

five bars of nine are displayed. This means that all unit

controls are pre-set at the mid-range setting. Wait 24 hours

after plug-in for the cabinets to reach this setting. After 24

hours, you may adjust controls as desired. The warmest

setting displays one bar, while the coldest setting shows nine

bars.

To adjust the refrigerator or freezer temperature, simply

press the “DISPLAY ON”/”ACTIVATE CONTROLS” pads,

then “REF TEMP” pad or “FREEZER TEMP” pad. Press

“HIGHER TEMP” or “LOWER TEMP” pad to adjust

temperature setting one level at a time. Holding down

“HIGHER TEMP” or “LOWER TEMP” pad adjusts

temperature more than one level at a time.

Entry Tone

The entry tone is the “beep” you will hear when you press

one of the control pads.

You can deactivate the entry tone by pressing and holding the

“DISPLAY ON”/”ACTIVATE CONTROLS” pads for three to

five seconds. You will hear three short beeps to let you know

that the entry tone feature has been deactivated.

To activate the entry tone, simply press and hold the

“DISPLAY ON”/”ACTIVATE CONTROLS” pads for three to

five seconds.

Max Refrigerator Mode

Max refrigerator mode adjusts the refrigerator temperature to

the coldest setting for four hours, at the end of which the

refrigerator's temperature automatically returns to its previous

setting.

ACTIVATE

CONTROLS

DISPLAY

ACTIVATE

CONTROLS

DISPLAY

ACTIVATE

CONTROLS

DISPLAY

HIGHER

TEMP

LOWER

TEMP

ACTIVATE

CONTROLS

MAX REF

DISPLAY

Product Controls

Settings and Functions

To activate the max refrigerator mode, simply press the

“DISPLAY ON”/”ACTIVATE CONTROLS” pads, followed by

the “MAX REF” pad. The indicator light will glow to let you

know you've turned on the max refrigerator mode.

To deactivate the max refrigerator mode before the end of

the four hour cycle, press the “DISPLAY ON”/”ACTIVATE

CONTROLS” pads, followed by the “MAX REF” pad.

Max Freezer Mode

Max freezer mode adjusts the freezer temperature to the

coldest setting for 24 hours, at the end of which, the freezer

temperature automatically returns to its previous setting.

To activate the max freezer mode, press the “DISPLAY

ON”/”ACTIVATE CONTROLS” pads, followed by the “MAX

FRZ” pad. The indicator light will glow to let you know you

have turned on the max freezer mode.

To deactivate the max freezer mode before the end of the 24

hours cycle, simply press the “DISPLAY ON”/”ACTIVATE

CONTROLS” pads, followed by the “MAX FRZ” pad.

Door Open Alarm

Door open alarm sounds and an indicator light blinks if either

door is left open for more than three minutes.

To deactivate the door open alarm, press the “ALARM OFF”

pad or close the door that is open.

High Temperature Alarm

High temperature alarm sounds and an indicator light glows if

the refrigerator or the freezer temperature is too high for two

hours. A blinking light signals which part of the appliance is

affected. The alarm will end when the temperature is brought

back to a proper setting.

To deactivate the high temperature alarm, press the “ALARM

OFF” pad.

ACTIVATE

CONTROLS

MAX REF

DISPLAY

ACTIVATE

CONTROLS

DISPLAY

MAX FRZ

ALARM

OFF

ALARM

OFF

Thermistor Alarm

Thermistor alarm is a special feature that electronically senses

temperatures. The thermistor alarm will sound and indicator

lights will scroll if the thermistor is not operating properly. The

alarm can be deactivated by pressing the “ALARM OFF” pad

on your refrigerator's control panel.

If the alarm continues to

sound, contact an authorized Viking Range Corporation

technician immediately.

Display Lights

To activate temperature display lights, press the “DISPLAY

ON”/”ACTIVATE CONTROLS” pads.

To deactivate temperature display lights, press the “DISPLAY

ON”/”ACTIVATE CONTROLS” pads, followed by the “DISPLAY

OFF” pad.

Sabbath Mode

Sabbath mode is used to disable interior lights and alarms for

observance of the Sabbath.

Before the Sabbath mode is engaged, the bale arm of the ice

maker needs to be raised until it clicks into the detent. This

turns off the power to the ice maker.

To enter Sabbath mode, press the “DISPLAY ON”/”ACTIVATE

CONTROLS” pads to activate the control panel. Then, press

and hold “DISPLAY ON”/“ACTIVATE CONTROLS” and

“DISPLAY OFF” pads simultaneously for three seconds. It will

beep three times and light the three right blue

squares so you

will know that you have activated Sabbath mode.

When your refrigerator is in Sabbath mode, interior lights,

display (excluding the three right

hand side lit blue squares), and

alarms are disabled.

If your refrigerator loses power

while in Sabbath mode, it will return to the Sabbath mode

when power is reestablished.

To exit the Sabbath mode, press the “DISPLAY ON”/

”ACTIVATE CONTROLS” pads. Then, press and hold “DISPLAY

ON”/“ACTIVATE CONTROLS” and “DISPLAY OFF” pads

simultaneously for three seconds. You will then hear three

beeps letting you know that you have turned the Sabbath mode

off.

FRZ

TEMP

FRZ

TEMP

HIGH

TEMP

MAX

REF

MAX

FRZ

COLDEST

...........

DOOR OPEN

Settings and Functions

ACTIVATE

CONTROLS

DISPLAY

ACTIVATE

CONTROLS

DISPLAY

OFF

DISPLAY

ACTIVATE

CONTROLS

DISPLAY

ACTIVATE

CONTROLS

DISPLAY

OFF

DISPLAY

Operation

Settings and Functions

Product Controls

Once your refrigerator has left the Sabbath mode, the bale

arm of the ice maker needs to be pushed downward until it is

no longer in the detent. This will restore power to the ice

maker.

Setting the Controls

Set controls precisely with a household thermometer that

includes temperatures between -5Þ to 50Þ F (-21Þ to 10Þ C).

Checking the Temperature (freezer)

Place the thermometer snugly between frozen packages in

freezer section. Wait five to eight hours, then check the

temperature. If the freezer temperature is not 0Þ to 2Þ F

(-17Þ to -16Þ C), adjust the temperature control one number

at a time. Then, check the temperature again in five to

8 hours.

Checking the Temperature (refrigerator)

Place the thermometer in a glass of water in the middle of

the refrigerator. Wait five to eight hours, and then check the

temperature. If the refrigerator temperature is not 38Þ to 40Þ

F (3Þ to 4Þ C), adjust the control one number at a time.

Check again after five to eight hours.

Refrigerator (all units)

CAUTION

To avoid personal injury and property damage, confirm shelf is

secure before placing items on shelf.

CAUTION

To avoid personal injury or property damage, handle tempered glass

shelves carefully. Shelves may break suddenly if nicked, scratched, or

exposed to sudden temperature change.

Spillproof Shelves

Your refrigerator's spillproof shelves are

constructed of polypropylene molded

around the glass and metal rail. This

design means that the shelves are

completely enclosed and liquids can't

seep under the glass. This localizes spills

and makes clean-up easier. Spillproof

shelves also adjust to meet individual

storage needs.

NOTE:

Foods and beverages placed on

the uppermost shelf under the air vent may freeze.

Shelf Adjustment

You can adjust the shelves to match the way you use your

refrigerator. To remove the shelves, tilt the shelf up at the

front releasing the hooks from the shelf support, then pull the

shelf straight out.

To replace shelves, guide the rear hooks of the shelf into the

slots in the shelf supports. Then, tilt the shelf up at the front

until the hooks drop into the slots, and lower the front of shelf

to level position.

Andere Handbücher für Professional DFFB530

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Viking Kühlschrank Handbücher

Viking

Viking High-Performance Kitchen Bedienungsanleitung

Viking

Viking Quiet Cool FDSB5421 Bedienungsanleitung

Viking

Viking VUBD140TRSS Bedienungsanleitung

Viking

Viking Professional VCFB304 Service-Handbuch

Viking

Viking Designer DFRD144D Bedienungsanleitung

Viking

Viking FDSB5481D Series Montageanleitung

Viking

Viking 5 Series Bedienungsanleitung

Viking

Viking VCBF136RSS Montageanleitung

Viking

Viking Professional VIRB364 Bedienungsanleitung

Viking

Viking Professional VCFB530 Bedienungsanleitung

Viking

Viking Custom Front series Bedienungsanleitung

Viking

Viking CFDCFB5363 Bedienungsanleitung

Viking

Viking Designer DUAR140R Bedienungsanleitung

Viking

Viking RDDFF236SS Montageanleitung

Viking

Viking Designer DFRD144D Benutzerhandbuch

Viking

Viking FDSB5481 Series Leitfaden

Viking

Viking FBI7360 Bedienungsanleitung

Viking

Viking DDSB542DSS Montageanleitung

Viking

Viking Professional VIBB536R Bedienungsanleitung

Viking

Viking Professional VCBB536 Bedienungsanleitung

Viking

Viking Designer DDSB423 Bedienungsanleitung

Viking

Viking Designer DDSB483 Bedienungsanleitung

Viking

Viking VUAR140T Technisches Handbuch

Viking

Viking F20481 Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
