Vivo MOUNT-SPSB1 Bedienungsanleitung

Universal Soundbar Wall Mount

Scan the QR code with your mobile device or follow the link

for helpful videos and specifications related to this product.

Instruction Manual

https://vivo-us.com/products/mount-spsb1

SKU: MOUNT-SPSB1

[email protected]om www.vivo-us.com 309-278-5303

Chat live with an agent!

GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

PACKAGE CONTENTS

TOOLS NEEDED

Phillips

Screwdriver

A (x2)

Bracket

B(x1)

Sonos Drill

Template

C(x4)

Support

Bushing

NOTE: SOME HARDWARE INCLUDED MAY NOT BE USED

Drill

D(x2)

M5x10mm

E (x2)

M5 Washer

F (x4)

ST5x40mm

Screw

G (x4)

Anchor

Level

H (x2)

ST5x50mm Screw

Studfinder Pencil Low Tack

Tape

WARNING!

If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a

qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may

cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. Do

not exceed weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect assembly

or inappropriate use.

WARNING: CHOKING HAZARD

SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.

33lbs

(15kg)

DO NOT EXCEED WEIGHT CAPACITY.

Failure to do so may result in serious injury.

Determine desired location of soundbar on wall. Use of a stud finder is recommended to determine if either bracket

can be mounted into a wood stud or not. Then proceed to Options A or B below.

Note: If you own a Sonos Beam soundbar, please use hole pattern marked “SONOS BEAM” on drill template (B). For

all other soundbars you may choose which hole pattern to use from drill template.

OPTION A: Wood Stud Installation

Tape drill template (B) to wall lining up chosen hole pattern, “A”, “B”, or “SONOS BEAM”, with desired studs. Make

sure template is level. Mark all four drilling locations for chosen hole pattern using a pencil or screw and remove

from wall. For all drilling locations that line up with a stud, drill 2-⅛” (54mm) deep holes using a 3/32” (2.5mm) bit

and mount support bushings (C) to wall using ST5x50mm screws (H). For all drilling locations that do not line up

with a stud, refer to Option B below for drywall instructions.

OPTION B: Drywall/Concrete Installation

Tape drill template (B) to wall making sure template is level. Mark all four drilling locations for hole pattern “A”,

“B”, or “SONOS BEAM” shown on template using a pencil or screw and remove from wall. Drill 1-5/8” (41mm) deep

holes using a 5/16” (8mm) bit, insert anchors (G) into holes, then mount support bushings (C) to the wall using

ST5x40mm screws (F).

STEP 2

ASSEMBLY STEPS

STEP 1

Note: It is recommended to connect all peripheral cables before mounting soundbar to brackets (A).

OPTION A: Sonos Beam Soundbar

If you own a Sonos Beam soundbar, removal of adhesive protection film from brackets (A) is not recommended

for installation. Place brackets (A) over the support bushings (C) and gently lower to secure. Install brackets (A) to

Sonos Beam using M5x10mm screws (D) with M5 washers (E).

OPTION B: All Other Soundbars

Peel o adhesive protection film from brackets (A) and install brackets onto support bushings (C). Carefully

center soundbar over the brackets and gently lower soundbar onto the brackets ensuring good contact with the

adhesive pads.

Pencil

OPTION A OPTION B

LAST UPDATED: 09/08/2020

Open Monday - Friday 7:00am - 7:00pm CST,

our dedicated support team can oer immediate assistance with rapid response times. If any

parts are received damaged or defective, please contact us. We are happy to replace parts to

ensure you have a fully functioning product.

FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com

[email protected] AVG. RESPONSE TIME (within oice hrs): 1HR 8M

- 23% within < 15m

- 38% within < 30m

- 61% within < 1hr

- 83% within < 2hr

- 92% within < 3hr

Love your new VIVO setup and want to share?

Tag us in your photo! @vivo_us

AVG. RESOLUTION TIME (within oice hrs): < 15 M

www.vivo-us.com

Chat live with an agent!

AVG. RESOLUTION TIME (within oice hrs): 5M 4S

309-278-5303
