VWR V-1200 Bedienungsanleitung

VWR Collection Manual ver 1, rel 15.05.2007

V-1200 Spectrophotometer

INSTRUCTION MANUAL

European Catalogue Number(s):

634-6000

Version: 1.0.0

Issued: 07, April 2010

Legal Address of Manufacturer

Europe

VWR International Europe bvba

Researchpark Haasrode 2020

Geldenaaksebaan 464

B 3001 Leuven

Tel.:+ 32 16 385 011

http://www.be.vwr.com

Made in China

Table of Contents

Safety Information 1

Package Contents 1

Unpacking 2

Installation 2

Intended Use 2

Symbols and Conventions 2

Specifications 3

Overview 4

Description of Buttons and Switches 4

Operational Keys 5

Getting Started 6

Important Guidelines 6

General Operating Instructions 7

Operation 8

Photometry 9

Quantitative Mode 10

System Utility 15

Troubleshooting 18

Repair and Maintenance 19

Daily Maintain 19

Spare Parts Replacement 19

Accessories and Spares Parts 24

Technical Service 24

Warranty 25

Equipment Disposal 25

Safety Information

Please follow the guidelines below, and read this manual in its entirety to ensure safe

operation of the unit.

VWR recommends against the use of V-1200 Spectrophotometer.

Do not open the device.

Disconnect the device from the mains supply before carrying out

maintenance work or changing the fuses.

The inside of the device is a high-voltage area Danger!

Do not use the device if it is damaged, especially if the main power

cable is in any way damaged or defective.

Repairs may only be carried out by the service technicians from your

local VWR office and authorized contractual partners.

The device must be connected to a power outlet that has a protective

ground connection.

If the equipment is used in a manner not specified by the

manufacturer, the protection provided by the equipment may be

impaired.

Do not allow any liquid to enter into the device.



Do not operate the device in a hazardous location or potentially

explosive environment.

Package Contents

Description Quantity

Spectrophotometer 1PC

Glass Cuvette 4PCS

Power Cord ( Euro Plug ) 1PC

Power Cord ( UK Plug ) 1PC

Power Cord ( SW Plug ) 1PC

Manual 1PC

Unpacking

Open the package, according to carefully check the packaging packing list items, if found

inside the packaging are missing or damaged items please your local VWR office and

authorized contractual partners.

Installation

Placement

Place the instrument on the stable table carefully.

Install printer (Printer is Optional Accessories)

Check to confirm instrument power switch is turned off, connect the printer’s data cable to

the Instrument’s parallel port.

Link the power cord

Check to confirm instrument power switch is turned off, the power cord plug into two

separate power interface and power supply socket apparatus.

Intended Use

V-1200 Spectrophotometer used in Chemistry, Pharmaceuticals, Biochemical, metallurgy,

Light Industry, Textile, Material, Environments, Medical, Education and some other fields. It

is one of the most important instruments in Quality Control and an essential in normal

laboratories.

Symbols and Conventions

The following chart is an illustrated glossary of the symbols that are used in this manual.

CAUTION This symbol indicates a potential risk and alerts you to

proceed with caution

CAUTION This symbol indicates the presence of high voltage and

warns the user to proceed with caution

CAUTION This symbol indicates risks associated with hot surfaces

Specifications

Optical System Single Beam

Wavelength Range 325-1000nm

Band Width 4nm

Stray Light ≤0.3%T

Photometric Range 0-200%T,-0.3-3.0A, 0-9999C

Wavelength Accuracy ±2nm

Photometric Accuracy ≤±0.5%T or 0.005A@1A

Stability 0.002A/h @ 500nm

Memory 200 Results & 200 Standard Curves

Language English, French, German, Spanish

Display 128×64 Dots Matrix LCD

Interface USB, Parallel

Measuring Procedure: Photometry

Quantitation

Power Supply AC 110/220V, 50/60Hz

Dimension 490×360×210mm

Weight 12kg

This instrument is compliant to the European Directives on

Low Voltage Directive 2006/95/EC

Electromagnetic compatibility 2004/108/EC

Restriction on use of Hazardous Substances RoHS 2002/95/EC

and theirs amandements.

Overview

V-1200 Spectrophotometer has the characters of wide range of wavelength, high sensitivity,

powerful function, easy to use, simple structure and pretty figure. Besides these, the large

LCD, High Precise A/D and easy to store RAM makes the instrument much more superior

than other originals. It is widely used in Chemistry, Pharmaceuticals, Biochemical,

metallurgy, Light Industry, Textile, Material, Environments, Medical, Education and some

other fields. It is one of the most important instruments in Quality Control and an essential

in normal laboratories.

Description of Buttons and Switches

Front View

Rear View
