WANHAO Duplicator 5S Bedienungsanleitung
Desktop 3D Printer
Duplicator 5S
User Manual
www.wanhao3dprinter.com
This User manual is designed to help you
start your experience with Duplicator 5S. .Within
these pages, we want to show you how simple
and easy it is to produce great prints.You might
be familiar with earlier types of Wanhao printers
or other 3D-printers. It is essential that your read
this manual carefully as there are a lot of new
procedures with Duplicator 5S.
WANHAO is excited to welcome you to the world of
the WANHAO Duplicator 5S .Following this guide
will help ensure that you are getting the most out
of your machine, and that you continue to make
amazing things.
电话: +86-579-82346658
邮箱: Sales@WanHao3D Printer.com
网址: www.wanhao3dprinter.com
MAX 295*195*575MM
Resolution:0.02mm
Speed:300mm/s
Software:Wanhao Maker
Duplicator5S
User Manual
Print Technology： Fused filament
Fabrication(FFF)
Build Volume： 295*195*575mm
Layer Resolution:
Ultra high: 20 micron
High:60 micron
M e d i u m : 1 0 0 m i c r o n
Low:200 micron
Position precision :
X 12.5 micron
Y 12.5micron
Z 5 micron
Filament diameter: 3mm±0.15mm
Nozzle diameter: 0.4mm
Print speed: 30mm/s-300mm/s
Travel speed: 30mm/s-350mm/s
Software：
Software Package： WanhaoMaker
File Type： stl,Gcode
Support： windows(XP32bit/7+)
Mac OS X(10.6 64bit)
1 Specification of the D5S
Electrical
Intrpiucta l： 100-240V 4amps
50-60Hz 200Watt Max
Power Requirements:24V [email protected]
Physical dimensions
Frame Dimension Length 455mm
Width 415mm
Height 810mm
Shipping box Length 575mm
Width 530mm
Height 910mm
Net Weight： 28kg(62lbs)
Gross Weight： 39kg(86lbs)
Temperature：
Ambient Operating： 10℃-38℃
Storage Temperatuer： 0-40℃
Average Operational： 180—260℃
Noise： 48dba
Connectivity: Stand-alone printing
SD Card
USB（firmware)
CAUTION： The Duplicator 5S generates high temperatures and has
hot moving parts that can cause injury.Never reach inside of the Duplicator
5S while it is in operation. Always control the Duplicator 5S from the push
wheel on the front or with the power-switch on the back.
WARNING：Only use power supply provided with your Duplicator 5S.
1.Place The Duplicator 5S box on the
ground next to a clean, flat workspace 2.Cut of the rope and Discard
the top cardboard insert.
3.Now remove the inner cardboard
box, and take the Duplicator 5S
out of its box.
4.Now you can clear away the
packging films and get the
Duplicator 5S.
2 Unboxing
3 What's in the box
1 pc printer 1 pc bulid plate 1 pc spool holder 1 pc clamp
1 pc USB cable 1 pc Print raiser 1 pc Print wrench
1 pc SD card reader
1pc Power supply
unit
1 pc SD card 1 pc 3mm filament
1.LED display
2. Push and Rotate button
3. Extruder Cable
4. Filament tube
5. MK10 Extruder
6. Building Plate
7. Building Plate Screw
8. Spool Holder
9. USB Socket
10. Power Switch
11. Material Feeder
12. Power Socket
4 D5S glance
5 Install Power Supply
Now the next step is to give the Duplicator 5 power.This is done by attaching
the external power supply.
1. If the power supply has to be detached,the first step is to make sure the
Duplicator5S turned off.
2.The corresponding power cable (for your country) has to be inserted in
the power brick of the power supply.
3. The connector has to be inserted at the back of the Duplicator5S, in
the round hole next to the on/off switch and USB slot.The flat side of the
power plug has to face towards the top of the Duplicator5S.
4.Now plug the external power supply into the wall socket.
CAUTION：Please make sure not to pull the cable.
6.The main cable in the power brick can be detached by pulling it out
gently.
5.Next take the power plug out of the wall socket.
7.Navigate to Step2, 3 and 4
6How to level the buling plate
1. Navigate the Rotate button and push
the button 2. Navigate the Rotate button to utility
and Push the button
3. Navigate to Calibrate plate and push
the button
4.Prepare a name card, Wait untilauto-
homing f inshed
5.Push the button and adjust nut below
the plate
6.Insert one name card between the
nozzle and plate(0.1mm thick)
8.Adjust the rest 2 nuts and ensure name
card can go through
