WE-EF ETC330-GB LED Bedienungsanleitung
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Inground Luminaire
ETC330-GB LED
ETC340-GB LED
Surge Protection
This product features built-in surge protection circuitry in compliance with
applicable standards.
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and secondary
(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.
1
Inground Luminaire
IP67, IK10+, Class I, ta = 40°C
ETC340-GBETC330-GB
2
Light Source
LED
Maintenance
Apart from cleaning the product’s exterior surfaces, no special maintenance work is required.
Do not use high-pressure cleaners.
In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out
E\DVXLWDEO\TXDOLƂHGDQGWUDLQHGSURIHVVLRQDO
Warning: Do not open luminaire while mains supply is switched on.
3
Installation
The product must be installed and maintained by a
VXLWDEO\TXDOLƂHGSURIHVVLRQDOLQFRPSOLDQFHZLWKODWHVW
building/construction and/or electrical regulations and
relevant legislation.
Warning: Switch off mains electrical supply prior to
installing and connecting the luminaire.
Notice:,IWKHOXPLQDLUHLVPRGLƂHGE\DQ\ERG\RWKHU
than the original manufacturer, then the warranty will
no longer be valid and shall become the full respon-
sibility of the modifying person/organisation. Claims
based on defects attributable to improper installation
and/or application, and the consequences thereof, are
excluded.
Minimum Distance
ETC330-GB: No minimum distance.
ETC340-GB: Ensure the minimum distance for objects
to be illuminated is correct (see illustration ------m
inside luminaire).
Installation Methods
For proper installation, use the supplied installation
blockout.
Ensure that proper drainage is provided for the shown
installation methods:
In landscape areas, soil with gravel base (Fig. I).
In paved areas, concrete with gravel base (Fig. II).
Fig. II
Fig. I
4
1) Ensure a suitable recess.
Phase One
Blockout Installation Procedure
3) Set mounting ring B/Min position. 4) Do not remove screws Xfrom mounting ring M.
2) Select appropriate installation blockout
holes Sfor mains supply cable(s) O.
orientation
FLUSH
R
5
5) Switch off mains electrical supply.
8) Terminate cable Eand mains supply cable Oin
sealable junction box J.
7) Remove screws Xfrom mounting ring M.
Phase Two
Luminaire Installation, Electrical Connection, and Aiming Procedure
6) Check that rating shown on luminaire label
conforms with mains electrical supply.
(example)
ETC330-GB 220-240V/60/Hz, 1-10V
185-XXXX SOE XXXXXXX
LED 4000K 12W item no. XXX
03/17 IP67
6
9) Remove cover Pand lens/gasket Qby loosening
screws C.
12.1) Insert screw driver into a slot on locking
wheel W. Rotate locking wheel Win
the 23(1GLUHFWLRQ+ROGƂQVIto aim
horizontally…
12.2) Insert screw driver into hole Tto aim vertically.
10)Set cables and sealable junction box J
inside installation blockout B.
11)Place housing Ainto blockout/mounting
ring assembly B/M. Tighten screws X.
B/M
7
15)Switch on and wait 30 minutes.
13) Reinsert screw driver into slot on locking
wheel Wand rotate it in the 'LOCK' direction.
Use only moderate torque.
14)Reposition lens/gasket assembly Qand
cover P.
-
O
P
E
N
L
O
C
.
-
!
30
MIN
16)Tighten screws in criss-cross sequence.
Using torque 5 Nm for ETC330-GB and 6 Nm
for ETC340-GB.
www.we-ef.com
WE-EF LEUCHTEN
Germany
Tel +49 5194 909 0
Fax +49 5194 909 299
info.germany@we-ef.com
WE-EF LUMIERE
France
Tel +33 4 74 99 14 44
Fax +33 4 74 99 14 40
info.france@we-ef.com
WE-EF HELVETICA
Switzerland
Tel +41 22 752 49 94
Fax +41 22 752 49 74
info.switzerland@we-ef.com
WE-EF LIGHTING
United Kingdom
Tel +44 844 880 5346
Fax +44 844 880 5347
info.uk@we-ef.com
WE-EF LIGHTING
Thailand
Tel +66 2 738 9610
Fax +66 2 175 2174
LQIRDVLDSDFLƂF#ZHHIFRP
WE-EF LIGHTING
Australia
Tel +61 3 8587 0444
Fax +61 3 8587 0499
info.australia@we-ef.com
WE-EF LIGHTING
United States of America
Tel +1 724 742 0030
Fax +1 724 742 0035
info.usa@we-ef.com
TO9128W0318 © WE-EF 2018
7HFKQLFDOVSHFLƂFDWLRQVDUH
subject to change.
