WE-EF FLC122 LED Bedienungsanleitung

Surge Protection

This product features built-in surge protection circuitry in compliance with

applicable standards.

For comprehensive protection of a luminaire installation against lightning

and electrical surges,it is essential to cover mains supply and data input

lines at the distribution board level,by using respective primary (Type 1)

and secondary (Type 2) surge arrestors in compliance with EN61643-11/

IEC61643-1.

Warning

Ensure that all required surge protection measures are in place and

activated prior to luminaire installation.Also,disconnect luminaires

before operating high-power devices such as, for example,electrical

arc welders.

Do not open during installation

This product is factory-sealed.

Refer to the instructions contained in this

document for details.

WE-EF LIGHTING

Installation and Maintenance

Instructions

Wall Luminaire Surface Mounted

FLC122 LED

FLC142 LED

IP55, IK07, Class I, ta= 40°C

Wall Luminaire Surface Mounted

FLC122

FLC142

Light Source

LED

Maintenance

Apart from cleaning the product’s exterior surfaces,no special maintenance work is required.

Do not use high-pressure cleaners.

In case of component failure due to abnormal circumstances or at end of life, replacement must be carried

RXWE\DVXLWDEO\TXDOLĥHGDQGWUDLQHGSURIHVVLRQDO

Warning: Do not open luminaire while mains supply is switched on.

Installation

The product must be installed and maintained by a VXLWDEO\TXDOLĥHGSURIHVVLRQDOLQFRPSOLDQFHZLWKODWHVW

building/construction and/or electrical regulations and relevant legislation.

Warning:6ZLWFKRĪPDLQVHOHFWULFDOVXSSO\SULRUWRLQVWDOOLQJDQGFRQQHFWLQJWKHOXPLQDLUH

Notice:,IWKHOXPLQDLUHLVPRGLĥHGE\DQ\ERG\RWKHUWKDQWKHRULJLQDOPDQXIDFWXUHUWKHQWKHZDUUDQW\ZLOO

no longer be valid and shall become the full responsibility of the modifying person/organisation.

Claims based on defects attributable to improper installation and/or application, and the consequences

thereof, are excluded.

The installation on site must comply with local and/or national health and safety regulations.

 6ZLWFKRĪPDLQVHOHFWULFDOVXSSO\

Installation Procedure

 'HWHUPLQHSRVLWLRQIRUĥ[LQJVFUHZVD. Drill

relevant holes Eand insert nylon plugs F.

Warning: Ensure not to damage any electrical

cable, water pipe or other items drilling holes.

 5HPRYHPRXQWLQJĦDQJHAby loosening

screws B.

3) Check that rating shown on luminaire label

conforms with mains electrical supply.

(example)

FLC122-LED 120-277V/60Hz

145-XXXX SOE XXXXXXX

LED 3000K 12W item no.XXX

12/17 IP55

5) Feed mains supply cable G(and second cable

Hfor through wiring,if required) through

ĥ[WXUHRSHQLQJIZKLOHVHWWLQJPRXQWLQJĦDQJH

Ain position.

 7Rĥ[PRXQWLQJĦDQJHA, pierce through nylon

plugs Jby inserting and tightening screws D.

Attention: Nylon plugs Jmust remain in

position to provide sealing.

7) Connect mains supply cable Gleads to

respective terminals in of LED Driver K:

a) ON/OFF (L = Phase,N = Neutral,

= Earthing)

b) 0-10 V (L = Phase,N = Neutral,

= Earthing,D–/D+ = 0-10 V control line).

8) Ensure that all surfaces are clean and dry.

3RVLWLRQOXPLQDLUHRYHUPRXQWLQJĦDQJHA.

Tighten screws B.

www.we-ef.com

WE-EF LIGHTING

United States of America

Tel +1 724 742 0030

Fax +1 724 742 0035

[email protected]

TO9205W0422 © WE-EF 2022

Technical specifications are

subject to change.
