WE-EF FLC122 LED Bedienungsanleitung
Surge Protection
This product features built-in surge protection circuitry in compliance with
applicable standards.
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and secondary
(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.
Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this
document for details.
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Wall Luminaire Surface Mounted
FLC122 LED
FLC142 LED
1
IP55, IK07, Class I, ta= 40°C
Wall Luminaire Surface Mounted
FLC122
FLC142
2
Light Source
LED
Maintenance
Apart from cleaning the product’s exterior surfaces, no special maintenance work is required.
Do not use high-pressure cleaners.
In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out
by a suitably qualiƂed and trained professional.
Warning: Do not open luminaire while mains supply is switched on.
3
Installation
The product must be installed and maintained by a
suitably qualiƂed professional in compliance with latest
building/construction and/or electrical regulations and
relevant legislation.
Warning: Switch off mains electrical supply prior to
installing and connecting the luminaire.
Notice: If the luminaire is modiƂed by anybody other
than the original manufacturer, then the warranty will
no longer be valid and shall become the full respon-
sibility of the modifying person/organisation. Claims
based on defects attributable to improper installation
and/or application, and the consequences thereof, are
excluded.
4
1) Switch off mains electrical supply.
Installation Procedure
4) Determine position for Ƃxing screws D. Drill
relevant holes Eand insert nylon plugs F.
Warning: Ensure not to damage any electrical
cable, water pipe or other items drilling holes.
2) Remove mounting ƃange Aby loosening
screws B. Detach terminal connector C.
3) Check that rating shown on luminaire label
conforms with mains electrical supply.
(example)
FLC122-LED 220-240V50-60/Hz
145-XXXX SOE XXXXXXX
LED 3000K 12W item no. XXX
12/17 IP55
5
5) Feed mains supply cable G(and second cable
Hfor through wiring, if required) through
membrane spout(s) I, while setting mounting
ƃange Ain position.
6) To Ƃx mounting ƃange A, pierce through nylon
plugs Jby inserting and tightening screws D.
Attention: Nylon plugs Jmust remain in
position to provide sealing.
7) Connect mains supply cable Gleads to
respective terminals in terminal connector K:
a) ON/OFF (L = Phase, N = Neutral,
= Earthing)
b) 1-10 V/DALI (L = Phase, N = Neutral,
= Earthing, DA/DA = DALI control line,
D–/D+ = 1-10 V control line).
8) Ensure that all surfaces are clean and dry.
Position luminaire over mounting ƃange A
and attach terminal connector C. Tighten
screws B.
www.we-ef.com
WE-EF LEUCHTEN
Germany
Tel +49 5194 909 0
Fax +49 5194 909 299
info.germany@we-ef.com
WE-EF LUMIERE
France
Tel +33 4 74 99 14 44
Fax +33 4 74 99 14 40
info.france@we-ef.com
WE-EF HELVETICA
Switzerland
Tel +41 22 752 49 94
Fax +41 22 752 49 74
info.switzerland@we-ef.com
WE-EF LIGHTING
United Kingdom
Tel +44 844 880 5346
Fax +44 844 880 5347
info.uk@we-ef.com
WE-EF LIGHTING
Thailand
Tel +66 2 738 9610
Fax +66 2 175 2174
info.asiapaciƂc@we-ef.com
WE-EF LIGHTING
Australia
Tel +61 3 8587 0444
Fax +61 3 8587 0499
info.australia@we-ef.com
WE-EF LIGHTING
United States of America
Tel +1 724 742 0030
Fax +1 724 742 0035
info.usa@we-ef.com
TO9205W0318 © WE-EF 2018
Technical speciƂcations are
subject to change.
