ELECTRIC FOOD STEAMER

Instruction Manual

www.focuselectrics.com

Important Safeguards...............................................................................................2

Operating Precautions..............................................................................................3

Assembling Your Steamer........................................................................................4

Using Your Steamer.................................................................................................4

Cleaning Your Steamer............................................................................................7

Cooking Tips ............................................................................................................7

Steaming Guide .......................................................................................................8

Recommended Cooking Temperatures..................................................................12

Warranty.................................................................................................................13

SAVE THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE

www.focuselectrics.com

IMPORTANT SAFEGUARDS

To prevent personal injury or property damage, read and follow all instructions

and warnings.

When using electrical appliances, basic safety precautions should always be

followed including the following:

•Read all instructions, including these important safeguards and the care and use

instructions in this manual.

•Do not touch hot surfaces. Use handles or knobs.

•To protect against electric shock, do not immerse cord, plugs, or other electric

parts in water or other liquids.

•Close supervision is necessary when this appliance is used by or near children.

•Unplug the appliance from outlet when not in use and before cleaning. Allow to

cool before putting on or taking off parts.

•Do not operate any appliance with a damaged cord or plug or after the

appliance malfunctions or if the appliance is dropped or damaged in any

manner. If you experience any problems with your appliance, unplug it

immediately from the electrical outlet. For service information see warranty

page.

•The use of accessory attachments not recommended by Focus Electrics, LLC

may cause injuries.

•Do not use this appliance outdoors.

•Do not let cord hang over the edge of a table or counter, or touch hot surfaces.

•Do not place on or near a hot gas or electrical burner, or in a heated oven.

•Extreme caution must be used when moving an appliance containing hot oil or

other hot liquids.

•To disconnect, turn unit to “OFF”, then remove plug from wall outlet.

•Do not use appliance for other than intended use.

•This appliance has a polarized plug (one blade is wider than the other). To

reduce the risk of electric shock, this plug is intended to fit into a polarized outlet

only one way. If the plug does not fit fully into the outlet, reverse the plug. If it

still does not fit, contact a qualified electrician. Do not attempt to modify the plug

in any way.

•Do not preheat the heating base.

•For household use only.

To prevent personal injury or property damage, read and follow all instructions

and warnings.

OPERATING PRECAUTIONS

•Use hot pads or oven mitts if you lift or carry the electrical base, baskets or

cover when it is hot.

•Be extremely cautious of steam when removing cover. Lift cover slowly,

directing steam away from you and let water drip into steamer.

•Do not operate appliance while empty or without water in the reservoir.

•A short power-supply cord is provided to reduce risks resulting from becoming

entangled in or tripping over a longer cord.

•Longer detachable power-supply cords or extension cords are available and

may be used if care is exercised in their use. While use of an extension cord is

not recommended, if you must use one, the marked electrical rating of the

detachable power-supply cord or extension cord should be at least as great as

the electrical rating of the appliance. If the appliance is of the grounded type,

the extension cord should be a grounding-type 3-wire cord. The cord should be

arranged so that it will not drape over the counter top or tabletop where it can be

pulled by children or tripped over.

•Do not attempt to repair this appliance yourself.

SAVE THESE INSTRUCTIONS

ASSEMBLING YOUR STEAMER

Cover

Rice Bowl

Separator Ring

Food Basket

Drip Tray

Heating Base

USING YOUR STEAMER

Before using for the first time, wash baskets, rice bowl, drip tray, separator rings and

cover using warm, soapy water. Rinse thoroughly and dry. Wipe the surfaces of the

heating base with a damp cloth and dry thoroughly. Do not use abrasive cleaning

products.

Cook Time – Maximum 90 minutes cooking time and 12 hour delay cycle.

STEAMER ICONS

“OFF” “START/STOP” “STEAM” “STEAM TIME” “WARM”

The

display

when first

plugged in.

Starts and

stops the

steamer.

Indicates

the

steaming

time.

Adjust the

steaming

time up.

Adjust the

steaming

time down.

Indicates

steamer is

in keep

warm

mode.

“SET DELAY” “SET” “HOURGLASS” “ADD WATER”

Press to set

the delayed

steaming time.

Indicates the

delayed

steaming

time.

Indicates how

long the timer

has to count

down to 0:00

Indicates the steamer does not

have enough water to complete

the steaming cycle.

STEAMING

1. Place the heating base on a dry, level, heat resistant surface, away from any

edge. Note: As food cooks, steam will come out of appliance. To prevent

possible damage, do not place steamer directly under cabinets.

2. Add cold water to the desired level or as shown in the cooking chart. Note:

Never start the steamer without water or with water below the “MIN” line or

above the “MAX” line.

3. Place the drip tray in theheating base. Note: The drip tray must always be used

when steaming foods or cooking rice.

4. Place food items in the food baskets or rice bowl. Place the food basket on top

of the drip tray making sure the drip tray and food basket are aligned properly. If

you are using multiple food baskets, lay a separator ring on top of the bottom

food basket and snap the second food basket in place. Make sure the separator

ring is completely snapped on to the upper basket and all baskets line up

properly. If using the second and third baskets repeat this procedure. If you are

using the rice bowl, place the rice bowl inside any of the food baskets being

used. Always place the cover on the top basket being used.

5. Plug the cord into a 120 volt, AC electric outlet only. The appliance

will beep and display a cooking time of 10 minutes and the display

will read “OFF.” Note: If the steamer is left idle for 5 minutes or

more, the digital display will turn off. Press any button on the

steamer to reactivate the display.

Pressing the “STEAM TIME” buttons will adjust the steaming time up or down

between 00 and 90 minutes. Note: Hold either button down to scroll quickly.

See the steaming chart for approximate cooking times.

6. When the timer is at the desired steaming time, press the

“START/STOP” button to begin steaming. The “STEAM” icon will

appear in the display to indicate steaming has begun. To cancel

steaming, press the “START/STOP” button again.

KEEP WARM - After the steaming time has elapsed, an audible

beep will sound 5 times and the “STEAM” icon will disappear. The

steamer will enter a 1 hour keep warm mode indicated by a

“WARM” icon and “00” in the display. During the keep warm mode,

the steamer will periodically turn off and on to maintain food at serving

temperature. When the keep warm mode is finished, the steamer will beep and

“OFF” and “10” will appear in the display.

If you want to cancel the “WARM” cycle, press the “START/STOP” button.

DELAY COOKING

1. Follow steps 1 - 4 from the “STEAMING” directions. Note: Do not

press the “START/STOP” button.

2. Press the “SET DELAY” button. The “SET” icon and 6:00 will be

displayed.

3. Pressing the “STEAM TIME” buttons will adjust the delay time up or down

between 00 and 12 hours. Note: Hold either button down to scroll quickly.

4. Press the “SET DELAY” button to accept the delay time. Once the

button is pressed, the hourglass icon will be displayed which

means the timer is counting down to 0:00. When the timer reaches

0:00, the unit will beep once and start the steaming cycle.

•If you decide to change the delay time after it has been set, press the “SET

DELAY” button and you will be back in “SET” mode. After changing the delay

time, be sure to press “SET DELAY” again to start the timer.

•If you decide to change the steam time when in the delay mode, press the

“START/STOP” button and you will be back in the steam timer mode. Note:

The delay timer will have to be reset after you change the steam time.

ADD WATER ALARM – when the steamer is out of water or the water

level is too low to complete the steaming cycle, the steamer has a self-

protection feature that will stop the steaming operation. An audible

beep will sound for 50 seconds and the “ADD WATER” icon will appear in the

display.

If this happens, push any button to stop the alarm. The steam time and “OFF” will

appear in the display. Add cold water through the drip tray handles or remove the

drip tray and add cold water directly into the heating base. Allow a few seconds for

the heater to cool down. Start the steamer up again by pushing “START/STOP”

button; the steamer will resume the cycle. If the steamer goes back into the alarm

mode, let the steamer cool down for a longer period of time and push the

“START/STOP” button again.

CLEANING YOUR STEAMER

1. Unplug the cord from the electrical outlet. Allow the steamer and all accessories

to cool completely before cleaning. Note: Never immerse the heating base,

cord or plug in water or in a dishwasher.

2. Wash the food baskets, rice bowl, drip tray, separator rings and cover using

warm, soapy water. Rinse thoroughly and dry. These parts may also be cleaned

in a dishwasher, top rack only. Note: Do not use the heat setting to dry.

3. Clean the inside and outside of the heating base with a damp cloth and dry

thoroughly. Note: Do not use abrasive cleaning products.

4. Mineral deposits may build up on the steamer heater over time. When you see a

white coating on the heater, perform the following steps to descale and extend

the life of your steamer.

1. Fill the heating base with two cups of vinegar and one cup of cold water.

2. Put the drip tray in place, set the timer for twenty minutes and press

“START/STOP” to begin steaming.

3. When the steamer turns off, let it cool completely and rinse the water

reservoir with cold water being careful not to get water on the outside or

bottom of the heating base.

4. Dry thoroughly.

STORAGE – Your steamer’s food baskets nest for easy storage. Remove the

separation rings between the baskets and place baskets inside one another.

COOKING TIPS

•Altitude and water type affect the temperature at which water boils which affects

cooking time. As you cook with this appliance, adapt times and measurements

to your own personal tastes.

•Cut food into uniform pieces and arrange evenly in food baskets for even

cooking.

•Do not thaw frozen vegetables before steaming. Stir halfway through the

steaming time for best results.

•Items will continue to cook slightly during the “Warm” mode, so adjust

accordingly.

•Do not pack food into the baskets as this limits the flow of steam.

•If steaming items for more than 60 minutes, you may have to add water during

the steaming cycle.

STEAMING GUIDE

These steaming times are for the bottom basket filled to the capacity listed in the

chart. Items will cook faster in the bottom basket. If you are cooking with multiple

baskets, or putting more food into the baskets than suggested, you may have to add

extra steaming time. The water level does not have to be precise. The following

levels are suggested to provide enough water for the recommended steaming times.

Note: The drip tray must always be used.

Fresh

Vegetables Amount Approximate

Time (minutes) Water

Level Preparation

Artichokes,

whole 4 whole. 30-34 MAX Trim stem, remove

loose outer leaves, cut

1 inch off top.

Asparagus,

spears 1 lb. 13-17 Middle Place evenly in basket.

Beans,

green/wax 1 lb. 16-20 Middle Place evenly in basket.

Beets 1 lb. 24-28 Middle

Cut and place evenly

in basket.

Broccoli,

spears 1 lb. 16-20 Middle Place evenly in basket.

Brussels

Sprouts 1 lb. 20-24 Between

Middle

and MAX

Remove outer leaves

and place evenly in

basket.

Cabbage 1 head 23-27 Between

Middle

and MAX

Cut whole head into 8

equal pieces.

Carrots,

sliced or

whole 1 lb. 25-29 Between

Middle

and MAX Place evenly in basket.

Cauliflower 1 lb. 16-20 Middle Place evenly in basket.

Celery 1 lb. 17-21 Middle Cut into ¼ inch pieces.

Corn on the

Cob

Up to 6

ears per

basket 28-32 MAX

Remove husk. Place

evenly in basket.

Mushrooms,

whole 1 lb. 11-15 Middle Place evenly in basket.

Fresh

Vegetables Amount Approximate

Time (minutes) Water

Level Preparation

Okra 1 lb. 18-22 Middle Place evenly in basket.

Onions,

quartered 1 lb. 12-16 Middle Place evenly in basket.

Parsnips 1 lb. 10-14 Middle Place evenly in basket.

Peas in pod 1 lb. 12-16 Middle Place evenly in basket.

Peppers,

green or red 1 lb. 12-16 Middle Place evenly in basket.

Potatoes, red,

baking or

sweet 1 lb. 38-42 MAX Cut in half and place

cut side down or cut in

¼ inch slices.

Potatoes,

whole 6 potatoes 50-54 MAX Pierce skin with fork

several times and place

evenly in basket.

Rutabaga 1 lb. 28-32 Between

Middle

and MAX

Dice and place evenly

in basket.

Spinach 1 lb. 10-14 Middle Place evenly in basket.

Squash,

Summer,

Yellow,

Zucchini

1 lb. 14-18 Middle Cut into ¼ inch pieces.

Turnips 1 lb. 20-24 Middle

Slice and place evenly

in basket.

Frozen

Vegetables

All – Corn,

Carrots,

Green Beans,

Broccoli,

Peas, Brussel

Sprouts

1 lb. 16-20 Middle Place evenly in basket.

Stir halfway through

steaming cycle.

Vegetables in

sauce 1 lb. 16-20 Middle

Put in rice bowl with

recommended water

stated on package.

Mix halfway through

steaming cycle.

Rice/Grains/

Pasta Amount Approximate

Time (minutes) Water

Level Preparation

White, 1 cup dry 33-37 MAX Mix 1 cup rice with 1½

cups water and desired

seasoning in rice bowl.

Brown, 1 cup dry 40-44 MAX Mix 1 cup rice with 1½

cups water and desired

seasoning in rice bowl.

Barley 1 cup dry 40-44 MAX Mix 1 cup barley with

1½ cups water in rice

bowl.

Pasta 1 cup dry 38-42 MAX Mix 1 cup pasta with

1½ cups water in rice

bowl.

Eggs

Hard Boiled Up to 12 16-20 Middle Place evenly in basket.

Soft Boiled Up to 12 8-10 Middle Place evenly in basket.

Seafood and

Fish

Clams, Fresh

in shell 1 lb. 12-16 Middle Clean, soak shells.

Cook until shells are

open.

Crab legs,

claws

(cooked) 1 lb. 15-19 Middle Steam until hot.

Lobster tails

(uncooked) 1 lb. 18-22 Middle

Remove underside of

shell. Place in steam

basket shell side down.

Steam until flesh is

opaque and shell is

reddish in color.

Mussels, in

shell 1 lb. 16-20 Middle

Clean shells. Cook

until shells are open

and flesh turns tannish

in color.

Oysters, in

shell 1 lb. 13-17 Middle Clean shell. Cook until

shells are opened and

juices bubble.

Scallops,

thawed 1 lb. 13-17 Middle Rinse scallops. Steam

until opaque in color.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere West Bend Elektrischer Dampfgarer Handbücher

West Bend

West Bend Chris Freytag 86604CF Bedienungsanleitung

Beliebte Elektrischer Dampfgarer Handbücher anderer Marken

Eloma

Eloma Joker B Gebrauchsanweisung

Clatronic

Clatronic DG 3547 Bedienungsanleitung

Heaven Fresh

Heaven Fresh NaturoPure HF 8333 Bedienungsanleitung

Memco

Memco 6625B Handbuch

Braun

Braun 3216 Bedienungsanleitung

Kooper

Kooper 2165306 Bedienungsanleitung

Morphy Richards

Morphy Richards FS48751MEE Bedienungsanleitung

Cuisinart

Cuisinart STM1000AR Bedienungsanleitung

Hastings

Hastings DIRECT GAS FIRED ELECTRIC STEAM Kurzanleitung

Galantine

Galantine SILVER Style SC-5003B Bedienungsanleitung

Cleveland

Cleveland SteamChef 22CET3.1 Bedienungsanleitung

Cleveland

Cleveland Enodis 24-CDM Bedienungsanleitung

Oster

Oster 5711 Bedienungsanleitung

Back to Basics

Back to Basics NUTRI STEAMER L5725A 01/09 Bedienungsanleitung

Gallet

Gallet CUV 968 Colmar Bedienungsanleitung

Rasonic

Rasonic RSB-B1CR Bedienungsanleitung

Basilico

Basilico K047 Bedienungsanleitung

Cuisinart

Cuisinart Cook & Steam Bedienungsanleitung
