Westinghouse WFVCR310 Bedienungsanleitung

ROBOTIC VACUUM CLEANER

WFVCR310

Instructions

Bedienungsanweisungen

Instructions

Instrucciones

Gebruiksaanwijzing

P.2

P.14

P.26

P.38

P.50

WFVCR310_Roboticvacuumcleaner_5L.indd 1 11/19/2019 3:14:20 PM

INTENDED USE

Use the appliance only for the intended purpose. Any other use may result in

damage to the appliance or injuries.

IMPORTANT SAFEGUARDS

General

1. Read this manual thoroughly before first use. It contains important information

for your safety as well as for the use and maintenance of the equipment. Keep

these instructions for future reference and pass them on to possible new owners

of the appliance.

2. Use the appliance only for its intended purpose. Improper use may lead to

hazards.

3. This appliance is intended for normal household use only. It is not intended for

outdoor use.

4. Do not use the appliance for any purpose other than described in this manual.

5. In the event of improper use or incorrect operation, we do not accept any

liability for resulting damages.

6. Do not use this appliance in small spaces (less than 6 cm), such as under a

bed or sofa. Remove anything on the ground to avoid tripping or winding the

product.

7. Make sure the power cord is placed in the right place in order to avoid tripping

the appliance over.

8. Do not place the appliance close to heaters, open fires, other sources of heat or

flammable substances.

9. Do not twist the power cord or place heavy objects on it, as this may cause

damage or result in a fire or electric shock.

10. Do not let clothes or body parts such as hair or fingers get close to the brushes

or wheels, as this may cause injuries or damage to the product.

11. This appliance is not intended to be used by persons (including children below

8 years of age) with reduced physical, sensory or mental abilities or lack of

experience and knowledge, unless they are supervised or instructed on the use

of the product by a person who is responsible for their safety.

12. Keep the appliance and its power cord out of the reach of children when it is in

operation.

13. Children should be supervised to ensure that they do not play with the product.

14. Never operate the appliance unattended.

15. Do not sit or stand on this appliance or place anything on top of it.

16. Do not store this appliance in a high place to avoid the risk of an accidental fall.

17. Do not under any circumstances attempt to repair the appliance yourself. For

serving and repairs, contact our after-sales service team to arrange a repair or

replacement.

WFVCR310_Roboticvacuumcleaner_5L.indd 2 11/19/2019 3:14:20 PM

Power supply

1. Make sure the power voltage matches the information on the rating label of the

power adapter.

2. Use the power adapter provided for charging. Do not use other power adapters,

as these may damage the device and cause a fire or electric shock.

3. Always attach the power cord to the charging socket first, and then plug the

power adapter into the wall outlet.

4. Disconnect from the power outlet when charging is complete, or in case of

malfunctions or prior to cleaning.

5. If the power cord of the power adapter is damaged, it must be replaced by the

manufacturer, an authorized service agent or a similarly qualified person in order

to avoid hazards.

6. Do not touch the charger with wet hands when charging, otherwise it may cause

damage or electric shock.

7. Charge the device indoor only.

8. Turn off the power switch while transporting or storing the vacuum cleaner, or

the battery might be damaged.

9. Check whether the charger is connected well, or it might cause charging failure

even fire.

RETAIN THESE INSTRUCTIONS

----------------

FOR HOUSEHOLD USE ONLY

WFVCR310_Roboticvacuumcleaner_5L.indd 3 11/19/2019 3:14:20 PM

ROBOTIC VACUUM CLEANER

Box Contents

a b c d

e f g

a. Main unit

b. Dust box (Water tank)

c. Charger

d. Power adapter

e. Remote control

f. Cleaning cloth

g. Instruction manual

Main Unit

1. Shell

2. Dust box/water tank

3. Power switch

4. Charging socket

5. Transparent signal window

6. Cover

7. Operation button

8. Front bumper

9. Universal wheel

10. Anti-drop sensor

11. Charging contacts

12. Edge-cleaning side brush (yellow)

13. Driving wheel

14. Dust inlet

15. Cleaning cloth

16. Battery cover

17. Driving wheel

18. Edge-cleaning side brush (gray)

6 7

Top and side view Bottom view

WFVCR310_Roboticvacuumcleaner_5L.indd 4 11/19/2019 3:14:20 PM

Dust Box/Water Tank

19. Handle

20. Rubber plug

21. Dust box/water tank

22. Dust box cover

23. Sponge

24. Hepa filter

25. Hepa filter supporter

26. Dustproof piece

27. Water outlet

23 24

25 27

Charger

28. Adapter socket 29. Charge pins

WFVCR310_Roboticvacuumcleaner_5L.indd 5 11/19/2019 3:14:21 PM

Remote Control

30. - Sleep, stop, and wake up button.

31. - Control the main unit (a) to return to the charger (c) and start charging.

32. - Confirm key.

33. - Control the direction of the main unit (a) (Use when the main unit

stops).

34. - Press to start or pause auto cleaning.

35. - Press to start or pause edge cleaning.

36. - Press to start or pause spot cleaning.

37. - Mute or unmute the voice prompt.

38. - Connect to Wi-Fi and app.

WFVCR310_Roboticvacuumcleaner_5L.indd 6 11/19/2019 3:14:21 PM

BEFORE FIRST USE

1. Unpack the appliance and all accessories carefully. Retain the packaging for

future reference or later use. For packaging disposal or recycling, contact your

local authority.

2. Make sure the appliance is not damaged and that there are no missing

accessories. Return the appliance to the retailer if there are any missing or

damaged parts.

Note:

• This appliance can be used on wooden, tile and cement floors and short fur

carpet (less than 1 cm long).

• This appliance must not be used in spaces with a height of less than 6 cm such

as under a bed and sofa, as it may get stuck during use.

• Remove power cords, threads or debris on the ground before use to avoid

tripping or winding the robotic vacuum cleaner.

• To clean carpet tassels, you will need to remove two edge-cleaning side brushes

(12) (18) to enable the main unit to start moving.

CHARGING THE ROBOTIC VACUUM CLEANER

Manual charging

Connect one end of the power adapter (d) to the charging socket (3) on the main

unit (a) and the other end to a wall outlet.

• The green light will flash and you will hear a voice message.

• The robotic vacuum cleaner will start to charge.

• The green light will stay constant when charging is complete.

Auto-recharging

1. Place the charger (c) on a flat surface. Make sure there are no obstacles within a

range of 0.5 m to the left and right and 1.5 m in front of the charger (c).

2. Connect one end of the power adapter (d) to the charging socket (28) on the

charger (c) and the other end to a wall outlet.

• When the battery level is low, the robotic vacuum cleaner will automatically

return to the charger (c) and charge itself.

Note: The charging contacts (11) on the main unit will align with the charging pins

(29) on the charger during charging.

WFVCR310_Roboticvacuumcleaner_5L.indd 7 11/19/2019 3:14:21 PM

You can use the automatic charging function in the mobile app or press on

the remote control (e) to return the main unit (a) to the charger (c). For more

information, see ‘Using the mobile app to control the robotic vacuum cleaner’.

Note:

• Charge the main unit (a) for at least 8 hours before first use.

• Make sure the water tank is empty before charging starts.

USING THE ROBOTIC VACUUM CLEANER

Turning the robotic vacuum cleaner on or off

Press the power switch (3) to turn the main unit (a) on or off.

• When the main unit (a) is switched on, the green light will turn on and you will

hear a sound.

Note:

• ‘I’ means powering on, ‘O’ means powering off.

• If you will not use the robotic vacuum cleaning for a long time, make sure the

water tank is empty.

WFVCR310_Roboticvacuumcleaner_5L.indd 8 11/19/2019 3:14:22 PM

Press the operation button (7) to start auto cleaning. Press the operation button (7)

again to stop cleaning.

Using the mobile app to control the robotic vacuum cleaner

Scan the following QR code with your smartphone to download and install the

mobile app. After installing the app, launch the app interface to access in the in-app

functions.

Wi-Fi settings

1. Press the power switch (3) to turn on the main unit (a).

2. Press the operation button (7) for about 5 seconds (or press on the remote

control).

• You will hear a sound signal.

3. When the main unit is ready to pair with your Wi-Fi network, open the app

interface on your smartphone and follow the steps to set up Wi-Fi.

Note:

• Once you have successfully paired the main unit for the first time, it will

automatically reconnect to the same Wi-Fi network.

• You can use the smartphone app to control the main unit remotely.

• The smartphone app is available for Android and iOS devices.

WFVCR310_Roboticvacuumcleaner_5L.indd 9 11/19/2019 3:14:22 PM

Selecting different cleaning modes

You can use the smartphone app or remote control to select your preferred cleaning

mode. For more information, launch the app interface or see ‘REMOTE CONTROL’ in

this manual.

• Auto cleaning: Select this mode for full coverage cleaning.

• Edge cleaning: Select this mode if you want to focus cleaning on the wall edges

or corners of your house.

• Spot cleaning: Select this mode if you want to focus cleaning on specific areas

with fewer obstacles.

• Powerful cleaning (only available within the smartphone app): Clean more

thoroughly with increased suction power.

• Return to charging: Select this option when the battery level is low.

Setting the cleaning time in the smartphone app

For convenience, you can use the preset timer function in the smartphone app to

choose the desired cleaning time and cleaning mode.

Using as a mop

1. Remove the dust box/water tank (21).

2. Open the rubber plug (20) and add water.

3. Close the rubber plug (20) and replace the

dust box (2).

Note: When you use the cleaning cloth (15), place it at the bottom of the main unit

(a).

WFVCR310_Roboticvacuumcleaner_5L.indd 10 11/19/2019 3:14:22 PM

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Westinghouse Staubsauger Handbücher

Westinghouse

Westinghouse WST1600 Series Bedienungsanleitung

Westinghouse

Westinghouse VC14110 Bedienungsanleitung

Westinghouse

Westinghouse WHVC03SB Bedienungsanleitung

Westinghouse

Westinghouse WHVCSV04SB Bedienungsanleitung

Westinghouse

Westinghouse WFVCZJX8217 Bedienungsanleitung

Westinghouse

Westinghouse VC14150 Bedienungsanleitung

Westinghouse

Westinghouse VC2511210 Bedienungsanleitung

Westinghouse

Westinghouse WHVC01SB Bedienungsanleitung

Westinghouse

Westinghouse WFVC001 Bedienungsanleitung

Westinghouse

Westinghouse VC14130 Bedienungsanleitung

Westinghouse

Westinghouse WFVCZJX8217 Bedienungsanleitung

Westinghouse

Westinghouse WST1500-1509 Bedienungsanleitung

Westinghouse

Westinghouse WFVCHS106 Bedienungsanleitung

Westinghouse

Westinghouse VC251809 Bedienungsanleitung

Westinghouse

Westinghouse WFVCR290BK Bedienungsanleitung

Westinghouse

Westinghouse WST1600A - Unplugged Bagless Cord-Free... Gebrauchs- und Wartungshandbuch

Westinghouse

Westinghouse WHVC02SB Bedienungsanleitung

Westinghouse

Westinghouse VC25132 Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
