Wilson Electronics WeBoost DRIVE SLEEK Bedienungsanleitung

ENGLISHFRANÇAIS

User Manual

Vehicle Signal Booster Kit

DRIVE SLEEK

A WILSON ELECTRONICS BRAND

NEED HELP? support.weboost.com 866.294.1660

______

Index

Package Contents 1

STEP 1: Mount Outside Antenna 2

STEP 2: Route & Connect Booster 3

STEP 3: Route Cable To Front Of Vehicle 5

STEP 4: Connect System To Power 6

STEP 5: Insert Phone Into Cradle 7

Troubleshooting 8

Safety Guidelines 9

Speciﬁcations 10

Warranty 11

ENGLISH

DRIVE SLEEK CELL PHONE SIGNAL BOOSTER 1

________

Package

Contents

Sleek

Cradle

Outside

Antenna

Signal

Booster

Power

Supply

Magnetic

Vent Mount

(for cradle)

ENGLISH

2CELL PHONE SIGNAL BOOSTER DRIVE SLEEK

______

Step 1: Mount Outside

Magnetic Antenna

WORKS WITH ALL VEHICLES

Identify a location on the top of your vehicle that is:

 Near the center of the roof

 At least 12 inches away from any other antennas

 At least 6 inches away from any windows

(including sunroofs)

Clean the surface where you will place the outside

antenna.

Mount the outside antenna by placing on top of vehicle.

6 in. away from windows

(including sunroofs)

route from

any side

NOTE: For aluminum roofs, an adhesive disk is included to mount the

outside antenna (do not use if outside antenna will magnetize to the top of

your vehicle).

ENGLISH

DRIVE SLEEK CELL PHONE SIGNAL BOOSTER 3

______

Step 2: Route Antenna Cable

& Connect Booster

Route the cable into the vehicle. See examples below.

NOTE: When going through car wash,

remember to remove your antenna.

NOTE: The cable is strong enough that it may be shut in most vehicle doors

without damaging the cable.

Car/Sedan: Cable routed

into rear side door.

SUV/Van/Hatchback: Cable

routed into top of hatchback door.

Truck: Cable routed into

side door.

Identify a location on the top of your vehicle that is:

 Near the center of the roof

 At least 12 inches away from any other antennas

 At least 6 inches away from any windows

(including sunroofs)

Clean the surface where you will place the outside

antenna.

Mount the outside antenna by placing on top of vehicle.

ENGLISH

4CELL PHONE SIGNAL BOOSTER DRIVE SLEEK

The included Velcro®can be used to mount the booster

out-of-the way on the ﬂoor under a seat or mounted to the

side of the trunk. It is best to mount in a place where the

cables cannot be tripped over or snagged (damaging the

booster).

______

(STEP 2 cont.)

Connect the cable from the outside antenna to the booster

port labeled

ANTENNA

by simply pressing the connector in until

you hear a “click”.

ANTENNA

cable from

outside antenna

booster

Velcro®

NOTE: Connecting cable from outside antenna to booster does not

take much force.

NOTE: The “hook” side of the Velcro®(already on the booster) can be

used to attach to the carpet of many vehicles.

bottom side of booster

ENGLISH

DRIVE SLEEK CELL PHONE SIGNAL BOOSTER 5

______

Step 3: Route Cable To Front

Of Vehicle & Connect To

Cradle

We recommend routing the 15ft. ﬁxed cable from the

booster, under mats and between seats up to the front of

the vehicle where the cradle will be located.

Connect booster cable to cradle cable.

to front of

vehicle

snap-in

connectors

cradle

ENGLISH

6CELL PHONE SIGNAL BOOSTER DRIVE SLEEK

______

Step 4: Connect System To

Power

Connect the power to the 12V*CLA port on your vehicle

and route power cable back to the booster.

Connect power cable to booster port labeled .

NOTE: We recommend routing with the same path as the cradle/booster

cable (under mats and between seats). Cable clips are provided to help

route & secure the cables.

NOTE: The booster will be on whenever there is power from the 12V CLA

port. If your vehicle always has power going to this port, you may want to

unplug this when you’re not driving so the booster does not drain your

battery. *Only 12V ports are supported.

ANTENNA

connect power supply

to 12V port

connect

to booster

cable from power supply

cable clip

ENGLISH

DRIVE SLEEK CELL PHONE SIGNAL BOOSTER 7

______

Step 5: Insert Your Phone

Into Cradle

Make sure you have plenty of slack in the cable going up

to the cradle (Velcro®straps included to manage excess

cable). Insert your phone into cradle and watch your signal

increase!

NOTE: A magnetic vent mount is provided which provides a versatile,

safe and functional smartphone solution.

IMPORTANT: The FCC requires to never use the cell phone in the cradle

next to your ear.

connect

to booster

cradle extends

insert phone into

cradle to boost signal

magnetic vent mount

ENGLISH

8CELL PHONE SIGNAL BOOSTER DRIVE SLEEK

______

Troubleshooting

Solid White (LED on cradle)

This indicates that your booster is functioning properly and at maximum gain.

Light O (LED on cradle)

Check/secure power connections to the CLA, booster, and cradle. If light shuts off,

remove from vehicle port and plug back in to reset the system. For any questions

or assistance contact our weBoost Customer Support Team (1-866-294-1660).

Dropped Calls

If you are regularly experiencing dropped calls in the same areas, turn off VoLTE/HD

Voice in your phone’s settings.

NEED HELP? support.weboost.com 866.294.1660
