Winmate W10IB3S-EHH2 Bedienungsanleitung

Please read this instructions before operating the device and retain them for future reference.

E-Series HMI

Intel® Celeron® Bay Trail-M N2930, 1.83 GHz

Elegant Design

Model No.: W07IB3S-EHT1

W10IB3S-EHH2

R15IB3S-EHC3

W15IB3S-EHA4

Quick Start Guide

Document Version 1.4

Document Part No. 9152101I1003

7~15.6" E-Series HMI Quick Start Guide

Contents

Chapter 1: Introduction 6

1.1 Features 6

1.2 Package Contents 6

1.3 Product Overview 7

Chapter 2: Getting Started 10

2.1 Turning On/ Off Your Device 10

2.2 Connecting to Other Devices 11

2.2.1 Power Connector 11

2.2.2 Serial Port Connector 11

2.2.3 Ethernet Connector 11

2.2.4 USB Connector 12

2.2.5 HDMI Connector 12

2.3 Changing Serial Port Settings 13

2.4 How to Enable Watchdog 14

Chapter 3: Installation 15

3.1 Wiring Requirements 15

3.2 Mounting Solution 16

3.2.1 Panel Mount 16

3.2.2 VESA Mount 17

APPENDIX 18

Appendix A: Hardware Specifications 18

Appendix B: Cleaning the Monitor 19

Appendix C: Winmate Software Development Kit 19

Chapter 1: Introduction

FCC Statement

This device complies with part 15 FCC rules.

Operation is subject to the following two conditions:

This device may not cause harmful interference.

This device must accept any interference received including

interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a class "B" digital

device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference in which case the user will be required to correct the interference

at him own expense.

European Union

Electromagnetic Compatibility Directive (2014/30/EU)

EN55024: 2010/ A1: 2015

oIEC61000-4-2: 2009

oIEC61000-4-3: 2006+A1: 2007+A2: 2010

oIEC61000-4-4: 2012

oIEC61000-4-5: 2014

oIEC61000-4-6: 2014

oIEC61000-4-8: 2010

oIEC61000-4-11: 2004

EN55032: 2012/AC:2013

EN61000-3-2:2014

EN61000-3-3:2013

Low Voltage Directive (2014/35/EU)

EN 60950-1:2006/A11:2009/A1:2010/A12:2011/ A2:2013

This equipment is in conformity with the requirement of the following EU legislations and

harmonized standards. Product also complies with the Council directions.

7~15.6" E-Series HMI Quick Start Guide

No part of this document may be reproduced, copied, translated, or transmitted in any form or by

any means, electronic or mechanical, for any purpose, without the prior written permission of the

original manufacturer.

Trademark Acknowledgement

Brand and product names are trademarks or registered trademarks of their respective owners.

Disclaimer

Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits

and/or software described or contained in this manual in order to improve design and/or

performance. We assume no responsibility or liability for the use of the described product(s)

conveys no license or title under any patent, copyright, or masks work rights to these products,

and make no representations or warranties that these products are free from patent, copyright, or

mask work right infringement, unless otherwise specified. Applications that are described in this

manual are for illustration purposes only. We make no representation or guarantee that such

application will be suitable for the specified use without further testing or modification.

Warranty

Winmate Inc. warranty guarantees that each of its products will be free from material and

workmanship defects for a period of one year from the invoice date. If the customer discovers a

defect, we will, at his/her option, repair or replace the defective product at no charge to the

customer, provide it is returned during the warranty period of one year, with transportation

charges prepaid. The returned product must be properly packaged in its original packaging to

obtain warranty service. If the serial number and the product shipping data differ by over 30 days,

the in-warranty service will be made according to the shipping date. In the serial numbers the

third and fourth two digits give the year of manufacture, and the fifth digit means the month (e. g.,

with A for October, B for November and C for December).

For example, the serial number 1W16Axxxxxxxx means October of year 2016.

Customer Service

We provide a service guide for any problem by the following steps: First, visit the website of our

distributor to find the update information about the product. Second, contact with your distributor,

sales representative, or our customer service center for technical support if you need additional

assistance.

You may need the following information ready before you call:

Product serial number

Software (OS, version, application software, etc.)

Description of complete problem

The exact wording of any error messages

In addition, free technical support is available from our engineers every business day. We are

always ready to give advice on application requirements or specific information on the installation

and operation of any of our products.

Chapter 1: Introduction

Advisory Conventions

Four types of advisories are used throughout the user manual to provide helpful information or to alert you

to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and

Warnings. The following is an example of each type of advisory.

Note:

A note is used to emphasize helpful information

Important:

An important note indicates information that is important for you to know.

Caution/ Attention

A Caution alert indicates potential damage to hardware and explains how to avoid the

potential problem.

Une alerte d’attention indique un dommage possible à l’équipement et explique comment

éviter le problème potentiel.

Warning!/ Avertissement!

An Electrical Shock Warning indicates the potential harm from electrical hazards and how

to avoid the potential problem.

Un Avertissement de Choc Électrique indique le potentiel de chocs sur des emplacements

électriques et comment éviter ces problèmes.

Safety Information

Warning!/ Avertissement!

Always completely disconnect the power cord from your chassis whenever

you work with the hardware. Do not make connections while the power is on.

Sensitive electronic components can be damaged by sudden power surges.

Only experienced electronics personnel should open the PC chassis.

Toujours débrancher le cordon d’alimentation du chassis lorsque vous

travaillez sur celui-ci. Ne pas brancher de connections lorsque l’alimentation

est présente. Des composantes électroniques sensibles peuvent être

endommagées par des sauts d’alimentation. Seulement du personnel

expérimenté devrait ouvrir ces chassis.

Caution/ Attention

Always ground yourself to remove any static charge before touching the CPU

card. Modern electronic devices are very sensitive to static electric charges.

As a safety precaution, use a grounding wrist strap at all times. Place all

electronic components in a static-dissipative surface or static-shielded bag

when they are not in the chassis.

Toujours verifier votre mise à la terre afin d’éliminer toute charge statique

avant de toucher la carte CPU. Les équipements électroniques moderns sont

très sensibles aux décharges d’électricité statique. Toujours utiliser un

bracelet de mise à la terre comme précaution. Placer toutes les

composantes électroniques sur une surface conçue pour dissiper les charge,

ou dans un sac anti-statique lorsqu’elles ne sont pas dans le chassis.

Alternating Current Mise à le terre !

The Protective Conductor Terminal (Earth Ground) symbol indicates the potential risk of

serious electrical shock due to improper grounding.

Le symbole de Mise à Terre indique le risqué potential de choc électrique grave à la

terre incorrecte.

7~15.6" E-Series HMI Quick Start Guide

Chapter 1: Introduction

Congratulations on purchasing Winmate® E-Series HMI. Winmate® continues developing new

generation of Human Machine Interfaces for Industry 4.0 and Internet of Things (IoT). You can

choose the most suitable operating system for you application. Thereby wide customization

possibilities are available to satisfy the needs of industrial automation.

With mounting clips for panel mounting there is no need to drill holes in a fixture. This saves you

the time for mounting and guarantee aesthetic look of the wall after the unit gets removed.

1.1 Features

Winmate® E-Series HMI features:

Intel® Celeron® Bay Trail-M N2930 1.83 GHz

Resistant to scratches Projected Capacitive Multi-Touch (P-CAP)

Fanless cooling system and Ultra-low power consumption

Front IP65 water and dust proof, rear IP22

Power over Ethernet (Data and Power connections in a single cable)

Mounting clips for Quick installation

Elegant design for room booking, access control and room information applications

1.2 Package Contents

Carefully remove the box and unpack your device. Please check if all the items listed below are

inside your package. If any of these items are missing or damaged contact us immediately.

Standard factory shipment list:

HMI Device

Quick Start Guide

(Hardcopy)

Driver CD & SBC User

Manual

Varies by product

specifications

Part No. 9152101I1003

Part No 9171111I101Y

Power Cord

AC Adapter

(12V/ 50W)

Mounting Clips and

Screws

Varies by country

Part No 922D050W12VA

Part No 82111E240400

Chapter 1: Introduction

1.3 Product Overview

E-Series HMI 7”

Unit: mm

№

Description

№

Description

①

12V DC Power Jack

④

HDMI 1.4a

②

RS-232/422/485

⑤

RJ-45 Gbe LAN x 2

③

USB 3.0 x 1, USB 2.0 x 1

7~15.6" E-Series HMI Quick Start Guide

E-Series HMI 10.1”

Unit: mm

№

Description

№

Description

①

12V DC Power Jack

④

HDMI 1.4a

②

RS-232/422/485

⑤

RJ-45 Gbe LAN x 2

③

USB 3.0 x 1, USB 2.0 x 1

E-Series HMI 15”

Unit: mm

№

Description

№

Description

①

12V DC Power Jack

④

HDMI 1.4a

②

RS-232/422/485

⑤

RJ-45 Gbe LAN x 2

③

USB 3.0 x 1, USB 2.0 x 1

Chapter 1: Introduction

E-Series HMI 15.6”

Unit: mm

№

Description

№

Description

①

12V DC Power Jack

④

HDMI 1.4a

②

RS-232/422/485

⑤

RJ-45 Gbe LAN x 2

③

USB 3.0 x 1, USB 2.0 x 1

7~15.6" E-Series HMI Quick Start Guide

Chapter 2: Getting Started

2.1 Turning On/ Off Your Device

Follow the following steps to turn on your HMI device:

1. Connect the AC adapter to the DC-in jack connector on the back side of the HMI

device.

2. Connect the power cord to AC adapter.

3. Plug the power cord to the AC outlet and the device will turn on automatically.

Disconnect the power cord from the HMI device to completely turn off the device.

Alternating Current Mise à le terre !

This product must be grounded. Use only a grounded AC outlet. Install the

additional PE ground wire if the local installation regulations require it.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Winmate Touchscreen Handbücher

Winmate

Winmate W10IB3S-PCH2-PoE S-Series Bedienungsanleitung

Winmate

Winmate W07RK3S-PCO1-POE Bedienungsanleitung

Winmate

Winmate E-Series Bedienungsanleitung

Winmate

Winmate IP69K Stainless P-Cap Bedienungsanleitung

Winmate

Winmate G-WIN Bedienungsanleitung

Winmate

Winmate W10IH3S-GCH1(HB) Bedienungsanleitung

Winmate

Winmate R19IHAT-66EX Bedienungsanleitung

Winmate

Winmate GC Series Bedienungsanleitung

Winmate

Winmate W15IB3S-EHA4 Bedienungsanleitung

Winmate

Winmate W07FA3S-EHT1 Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Winmate

Winmate W07IB3S-PCO1-POE Bedienungsanleitung

Winmate

Winmate R15IE3S-PTC3 Bedienungsanleitung

Winmate

Winmate R05FA3S-IPD1HMHB Bedienungsanleitung

Winmate

Winmate W10IB3S-MRH2 Bedienungsanleitung

Winmate

Winmate ARM-11 HMI Series Bedienungsanleitung

Winmate

Winmate W05TA3S-PCT3AC Bedienungsanleitung

Winmate

Winmate W10FA3S-PCH2AC-PoE Bedienungsanleitung

Winmate

Winmate R15IK3S-67C3(HB) Bedienungsanleitung

Winmate

Winmate W10IB3S-PCH2AC-PoE S-Series Bedienungsanleitung

Winmate

Winmate R15ID3S-65A1FTE Bedienungsanleitung

Winmate

Winmate 7'' S-Series Bedienungsanleitung

Winmate

Winmate W07L100-GCO1 Bedienungsanleitung

Winmate

Winmate W15IB3S-PTA3 Bedienungsanleitung

Beliebte Touchscreen Handbücher anderer Marken

FlowLine

FlowLine Data loop Bedienungsanleitung

ALPEX

ALPEX AEx-8 P Series Bedienungsanleitung

Ltech

Ltech E5S Bedienungsanleitung

Harman

Harman AMX MODERO S MSD-701-L2 Bedienungsanleitung

Acnodes

Acnodes PC 1150 Bedienungsanleitung

AIS

AIS IP10IA99 series Bedienungsanleitung

IBASE Technology

IBASE Technology ASTUT-152-RE1S Bedienungsanleitung

YASKAWA

YASKAWA TP 610C Bedienungsanleitung

B&R

B&R Power Panel C Series Bedienungsanleitung

Beijer Electronics

Beijer Electronics X2 control Bedienungsanleitung

AXIOMTEK

AXIOMTEK GOT321W-521 Bedienungsanleitung

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Bedienungsanleitung

Qomo

Qomo QIT1386 Bedienungsanleitung

DFI

DFI KS104-CD Bedienungsanleitung

AMX

AMX AXP-PPC Leitfaden

Sartorius

Sartorius X3 PR 5410 Bedienungsanleitung

AMX

AMX Modero X Series Bedienungsanleitung

Advantech

Advantech TPC-30 Series Bedienungsanleitung
