X-Vision XUSB4DVR Bedienungsanleitung
CCTV
Model:
XUSB4DVR
4Camera 25fps USB DVR Card
and Software
Beforeyou begin
•Please unpack all boxes carefully and identify that all the parts are present.
•Do not cut the cables,this will void the warranty.
Model: XUSB4DVR
4Camera 25fps USB DVR Card
and Software
User Guide
CONTENTS
1INTRODUCTION ............................................................................................5
1.1 OVERVIEW ................................................................................................... 5
1.2 FEATURES...................................................................................................... 5
1.3 SYSTEM REQUIREMENTS ............................................................................. 6
1.4 SYSTEM SPECIFICATIONS ............................................................................ 6
2HARDWARE INSTALLATION........................................................................ 8
2.1 VIDEO CAPTURE CARD HARDWARE............................................................. 8
2.1.1 XUSB4DVR Card Hardware.............................................................. 8
2.2 INSTALL VIDEO CAPTURE CARD DRIVER...................................................... 8
3MAIN DISPLAY INTERFACE ....................................................................... 11
3.1 LOGIN........................................................................................................... 11
3.2 DISPLAY CONTROL PANEL ........................................................................... 11
3.2.1 Flip Pages ........................................................................................ 12
3.2.2 Auto Dwell display Mode................................................................. 12
3.2.3 Quick Switch ................................................................................... 12
3.3 RECORD ....................................................................................................... 12
3.3.1 Record Modes ................................................................................. 12
3.3.2 Recording Multiple Cameras............................................................ 12
3.3.3 Record Setup .................................................................................. 13
3.3.4 Record Status Panel ........................................................................ 14
3.3.5 Manual Record Mode ..................................................................... 14
3.3.6 Schedule Record Mode ................................................................... 14
3.3.7 Motion Detection Record Mode ...................................................... 14
3.3.8 Sensor Alarm Record Mode ............................................................ 15
3.3.9 Recycling Record ............................................................................. 15
4SYSTEM SETUP .............................................................................................16
4.1 BASIC CONFIGURATION .............................................................................. 16
4.2 SCHEDULE CONFIGURATION........................................................................ 17
4.3 VIDEO CONFIGURATION .............................................................................. 17
4.4 MOTION DETECTION CONFIGURATION ....................................................... 18
4.4.1 Set Motion Detection Area............................................................... 18
4.4.2 Set Motion Detection Sensitivity ..................................................... 18
4.5 ALARM CONFIGURATION ............................................................................ 18
4.5.1 Alarm Triggering Conditions Configuration...................................... 18
4.5.2 Alarm Record .................................................................................. 19
4.5.3 Alarm Output Tab ............................................................................ 19
4.5.4 Auto Mail Function Tab.................................................................... 20
4.5.5 Emap Tab.......................................................................................... 20
4.6 PTZ CONTROL CONFIGURATION ................................................................. 20
2XUSB4DVR User Guide
4.6.1 Protocol Setup ................................................................................ 20
4.6.2 Serial ports setup ............................................................................ 21
4.7 USERS CONFIGURATION .............................................................................. 21
4.7.1 Add User ........................................................................................ 21
4.7.2 Change User rights ......................................................................... 21
4.7.3 Delete User ..................................................................................... 22
4.8 E-MAP CONFIGURATION.............................................................................. 22
4.8.1 Edit a map ...................................................................................... 22
4.8.2 View the map....................................................................................23
5P.T.Z CONTROL ............................................................................................ 24
6RECORD SEARCH AND PLAYBACK ........................................................... 26
6.1 RECORD SEARCH ......................................................................................... 26
6.2 RECORD PLAYBACK AND CONTROL ............................................................ 26
6.3 OTHER FUNCTIONS ...................................................................................... 28
6.3.1 Record File Backup .......................................................................... 28
6.3.2 Delete Recorded Files ...................................................................... 28
6.3.3 Capture Pictures .............................................................................. 28
6.3.4 Image Zoom In / Out ....................................................................... 30
7REMOTE SURVEILLANCE AND PLAYBACK .............................................. 31
7.1 REMOTE LIVE SURVEILLANCE ...................................................................... 31
7.1.1 Remote Surveillance Server Configuration ...................................... 31
7.1.2 Remote Surveillance Client-side Setup ........................................... 31
7.2 REMOTE PLAYBACK ..................................................................................... 34
7.2.1 Remote Playback Server Configuration ........................................... 34
7.2.2 Remote Playback Client-side Setup.................................................. 34
7.2.3 Remote Playback Configuration and Control Setup......................... 35
7.3 MOBILE SURVEILLANCE................................................................................ 37
7.3.1 Introduction to Mobile Surveillance ................................................ 37
7.3.2 Client Configuration of Windows Mobiles ...................................... 37
7.3.3 Client Configuration of Symbian 60 ............................................... 38
APPENDIX 1: FREQUENTLY ASKED QUESTIONS ....................................... 40
APPENDIX 1.1 ABOUT INSTALLATION ............................................................... 40
App 1.1.1 Cannot Install the SmartDVR Driver ....................................... 40
App 1.1.2 Why can’t I run SmartDVR in the Windows 2003 OS? .......... 40
App 1.1.3 ‘Unspecified error’ in the End of Installation .......................... 40
App 1.1.4 Cannot find XUSB4DVR in Device Manager ........................... 40
APPENDIX 1.2 HOW TO USE SMARTDVR............................................................ 41
App 1.2.1 What are the meanings of the indicator lights ....................... 41
App 1.2.2 How do the different record modes work? ............................ 41
App 1.2.3 How do I set Recycling Record mode on the system? ........... 41
3XUSB4DVR User Guide
App 1.2.4 How to set the Auto Reboot function? .................................. 41
App 1.2.5 How to quickly use the Schedule Record function? ............... 41
App 1.2.6 What are the byte rates for different image qualities? .......... 41
App 1.2.7 The frame rate seems to be lower than what I set? .............. 42
App 1.2.8 Why I can’t select more channels to backup? ........................ 42
App 1.2.9 When should I select manual Gain Control? .......................... 42
APPENDIX 1.3 HOW TO USE THE NETWORK FUNCTION.................................... 42
App 1.3.1 How do I monitor on the client-side? .................................... 42
App 1.3.2 Why I can’t download the client-side software?.................... 42
App 1.3.3 Why can’t the server be configured at the clientside? .......... 42
App 1.3.4 Why I can’t see the images?.................................................. 42
App 1.3.5 What should I do if the Internet speed is quite slow? .......... 43
App 1.3.6 Why I can’t start WebCam server or RPB server? .................... 43
APPENDIX 1.4 OTHER QUESTIONS .................................................................... 43
App 1.4.1 Why doesn’t the computer display work, and why can’t I
access the window system? .................................................................... 43
App 1.4.2 Why I can’t find the recorded files? ........................................ 43
App 1.4.3 Why is the screen’s display is unstable with dithering and
water-wave images? ............................................................................... 43
App 1.4.4 Why is there a delay to playback, and why is it slow to
close and open the driver? ...................................................................... 44
App 1.4.5 Why can’t I playback?............................................................. 44
App 1.4.6 Why do I see some grey blocks on time progress bar area
when I playback? .................................................................................... 44
App 1.4.7 Why do I see some old record sections that can’t be covered
when I playback? ..................................................................................... 44
App 1.4.8 Precautions on changing system time .................................... 44
App 1.4.9 If the system time must be changed, make the following
preparations first: .................................................................................... 45
APPENDIX 1.5 SYSTEM QUESTIONS .................................................................. 45
App 1.5.1 How to use REPAIRDB to repair SmartDVR database? .......... 45
App 1.5.2 How to setup power options in the Microsoft VISTA system... 45
APPENDIX 2: QUICK START .......................................................................... 46
APPENDIX 2.1 TROUBLESHOOTING .................................................................. 46
App 2.1.1 When I open the SmartDVR application, it says ‘Can’t find
Card ......................................................................................................... 46
App 2.1.2 How do I setup the Web Client to monitor from the
Internet? .................................................................................................. 47
APPENDIX 3 FUNCTION TREES...................................................................... 48
APPENDIX 4 NOTES ...................................................................................... 51
4XUSB4DVR User Guide
1.1 OVERVIEW
Thank you for choosing this Xvision USB Card and Software. The USB Card adopts MPEG4 compression
format, and allows up to 4 cameras to be recorded in real-time for live surveillance and playback, all
from a PC/laptop. The cameras can also be viewed and played back a remote PC on the same LAN or on
the Internet. In addition to this it can also synchronise the recording and transmission of audio from up
to 2 cameras.
This user guide will show you how to install the hardware and the SmartDVR 5.0 Software, and how to
setup the systems of this range of products. To maintain the stability of your PC DVR system, please
make sure you operate the product in accordance with this user guide.
1.2 FEATURES
The following are standard functions of the XUSB4DVR:
1. Schedule record mode
You can choose any period in a day to record and set up the record modes, i.e. sensor alarm
record, motion detection record, manual record, schedule record.
2. Motion detection mode
Motion detection areas are adjustable and you can assign up to 16 areas for detection for each
channel. You can also set the motion detection sensitivity for each channel. The system will only
begin to record only when motion in the detection area occurs, and it will stop recording after a
period of time which also is adjustable.
3. Recycling record mode
You can set the recording Storage Sequence for HDD partitions. The recording storage will
automatically jump to the next partition when it is full. If all the partitions are full and recycling
record mode is enabled, the old recorded data will be recycled and recorded over with new data.
You can also set a HDD Minimum Storage Alarm. Once the present storage space is less then the
minimum storage and recycling record mode is not enabled, the recording will automatically stop.
This means old data will never be recorded over.
4. P.T.Z control function
Supported by a number of decoders, you can control multiple speed domes and integrated
cameras. Controls include Pan, Tilt, Zoom, Focus and Iris Adjustment for P.T.Z devices. The system
also supports Preset Points and Auto Seek.
5. Management of Users
Different users can have different rights, user names and passwords, so as to ensure system is
secured against unauthorised users.
6. Multi-channel display
Supports Multi-channel Display mode, Full Screen display and Auto Dwell display.
5XUSB4DVR User Guide
1INTRODUCTION
7. Real Time Recording
The USB Card can support up to 4 channels with a maximum frame rate of 25 fps.
8. Image Quality
Features MPEG4 compression, which greatly reduces HDD usage and supports 352x288 and
704x576 (PAL) standard resolutions. Also allows you to adjust the image colour for each channel,
including contrast, lightness, hue and saturation.
10. Powerful video playback functions
Including playback, pause, stop, fast-forward, single-frame play and image capture.
11. Support advanced search mode
Users can search by date/time, camera, record mode, or a combination of the three methods.
12. File Management
Supports recorded files backup, delete by date/time, camera.
13. Multiple Language support
Including Chinese (Traditional), English, German, Spanish, Portuguese and other customised
languages.
14. Remote Surveillance
You can view, playback and have PTZ Control from a remote PC on the same LAN or Internet
15. Alerts
Set buzzer and Email alerts with image snapshots when motion is detected
16. User-friendly graphical user interface
Simple user interface allows you to control the system with ease
17. Decrease file fragmentation
Features NTFS partition to decrease fragmented files
1.3 SYSTEM REQUIREMENTS
The following are the minimum system requirements for your PC:
Operating System: Windows XP or Vista
CPU: Pentium 4, 1.7GHz or above
Graphics: Nvidia Geforce 2/ATI Rage 128 compatible or similar
RAM: 256MB
Direct X: Version 9 or above
USB 2.0 Sockets required: 1
6XUSB4DVR User Guide
Please Note:
When the recording disk partition’s format is FAT32 and the system has run for a long time, the system will create
alot of data fragments, that may result in the system running slowly. We recommend that you defragment your
hard disk every 10 to 30 days. We strongly suggest that recording disk partition uses NTFS format.
1.4 SYSTEM SPECIFICATIONS
Format: PAL/NTSC
Resolution: 352x288 / 704x576 (PAL)
Maximum Frame rate: 25 fps (PAL)
Screen set: Resolution 1024x768, 16 bits or 32 bits
Compression code rate: 50kbps – 1.2Mbps
Data format: MPEG4
7XUSB4DVR User Guide
2.1 VIDEO CAPTURE CARD HARDWARE
2.1.1 XUSB4DVR Card Hardware
Fig 2.1 XUSB4DVR USB Video Capture Card
2.2 INSTALL VIDEO CAPTURE CARD DRIVER
Connect the USB plug on the XUSB4DVR to a
spare USB port on your laptop/PC and insert the
Software CD into the CD drive. Run ‘Setup.exe’
(located in ‘Install’ Folder), and the installation
interface will appear.
Select ‘Next to continue.
Fig 2.2 Welcome Page
8XUSB4DVR User Guide
2HARDWARE INSTALLATION
Please Note:
•Makesure that your PC USB interface is 2.0; the XUSB4DVR card can only support USB 2.0.
•Please follow the steps to safely remove the USB card:
Right click on the Taskbar > Stop device > pull out the USB card.
•Using this card with other USB device simultaneously may cause mean that PC is unable to identify the USB card.
•Do not insert two or more USB video capture cards simultaneously.
•Do not use with any other PCI video capture card simultaneously.
Audio Input (White)
Video Input (Yellow)
USB Connection
Select Video format and then click ‘Next’ to
continue.
Fig 2.3 Select video format
After this process, the application package
SmartDVR will begin installation.
Select a suitable destination option, and click
‘Next’.
Fig 2.4 Select installation destination
Click ‘Next’ to continue.
Fig 2.5 Select Program Folder
9XUSB4DVR User Guide
For UK video format, select PAL
The Software will finish installing. Click ‘Finish’.
Now, restart the computer and start the
surveillance program.
Fig 2.6 Driver and application installation finished
You will see a shortcut will have been created on the desktop:
Fig 2.6.1 Shortcut of SmartDVR
10 XUSB4DVR User Guide
Please Note:
When you install the driver software on a Microsoft VISTA system, you need select the option shown below when
you start the installation process. After this, follow the same steps as outlined previously for installing the software
on a Microsoft XP system.
If you cannot run the SmartDVR program, users
should restart the computer.
Fig 2.7 Install the Software on a VISTA system
Andere Handbücher für XUSB4DVR
1
Inhaltsverzeichnis
