X-Vision XC960T Bedienungsanleitung
Professional HD 960H Box Camera
User Manual
Version 1
Thank you purchasing the XC960T camera from Xvision.
Please ensure that you read and understand this User Guide before operating the camera.
Please store this User Guide in an easily accessible location.
HD 960H
XC960T
HD 960H
2
www.xvision.com
Contents
1. Product Overview .................................................................................. 4
1.2 Package Contents .......................................................................... 4
2. Installaon ............................................................................................ 5
3. How to Operate the Camera .................................................................. 6
4. Camera Menu ........................................................................................ 6
4.1 Lens ............................................................................................... 7
4.2 Exposure ....................................................................................... 7
4.3 White Balance ............................................................................... 7
4.4 Backlight ........................................................................................ 8
4.5 Day/Night ...................................................................................... 8
4.6 DPC ................................................................................................ 9
4.7 Special ........................................................................................... 9
5. Specicaons ........................................................................................ 11
XC960T
HD 960H
3
www.xvision.com
Safety Precauons
1. Do not install the equipment in an environment with too much moisture, dust or smoke dust as this
may result in re or electric shock.
2. In the unlikely event that the equipment should malfuncon and emit an abnormal smell or smoke,
please immediately stop it, shut o the power and contact your supplier.
3. Please do not place this equipment near a heat source to avoid risk of re.
4. Please do not store, install and use this product in danger areas with inammable or explosive
substances.
5. Please make sure the power is turned o when installing the product.
6. Please ensure that you install the camera in an area with good venlaon.
7. When installing the camera, please make sure that it does not face any objects giving out strong lights
as this will damage the CCD of the camera.
8. Please do not use the camera in an environment where temperatures exceed either -20°C to +55°C.
XC960T
HD 960H
4
www.xvision.com
Thank you for purchasing the HD 960H XC960T from Xvision. Please read through this manual carefully and
make sure you understand before operang the camera.
1.1 Features
• Sony 960H CCD Sensor
• Xvision X3K DSP
• 700TVL Resoluon
• 0.003 low lux sensivity
• Day/Night (IR Sensive)
• Compable with xed, manual and auto iris C/CS mount lenses
• Advanced Wide Dynamic Range
• High Speed Digital Slow Shuer
• 3D Digital Noise Reducon
• Programmable High Light Suppression
• Can be wall or ceiling mounted using oponal bracket
• Can be placed outside when used with an oponal weatherproof housing
1.2 Package Contents
The packaged box for the XC960T comes with the following items:
• XC960T Camera
• User Manual
Should any of these items be missing, please contact your local distributor.
1. Product Overview
1. Product Overview
XC960T
HD 960H
5
www.xvision.com
1. Product Overview
2. Installaon
The XC960T camera can be wall or ceiling mounted. To install the camera, you will need purchase an
oponal bracket or if installing the camera externally, a weatherproof housing. Contact the distributor for
details on more accessories. The instrucons below refer to the Xvision XV400B bracket.
1. To install the camera, rstly you will need to
remove the bracket into 3 pieces.
3. Use the base of the bracket as a stencil and
draw circles on the wall where you want to
drill the holes.
5. Once the plugs are in, place the bracket
over the wall plugs and screw the base in
place. Then screw the extension bar of the
bracket back onto the base.
7. Once the camera has been installed,
connect the lens (sold separately). An auto
iris will require you to plug into the auto
iris connector.
2. Screw the top of the bracket in either the
top or boom of the camera.
4. Take the wall plugs from the accessory
pack and get the correct size drill bit.
Depending on the wall or ceiling, please
make sure to choose the appropriate drill bit.
6. Secure the bracket head and camera in
the bar and use the screw to secure, twisng
clockwise.
XC960T
HD 960H
6
www.xvision.com
1. Product Overview
3. How to Operate the Camera
To operate the camera, rstly you will need to connect the BNC and terminal screws to the BNC and DC
sockets of a power supply and DVR or Monitor.
To provide power to the camera, you will need to use DC Cable. The posive will go into the ‘+” sign and
negave into the ‘-’ sign. To do this, push the orange clip down, place the cable into the hole and release
the orange clip again. Give the cable a small pull, and you should feel the cable ghten and secure. If not
please repeat this process unl cables are secure. Please note that this camera requires DC 12V.
BNC Socket for
video
Terminal screw
for power
1. Product Overview
4. Camera Menu
To access the camera menu, rstly unscrew the panel at the boom of the camera using the allen key
(Above, le). This will expose the buons that are used to control the camera menu. Turn the camera on
and then press the set buon. When the menu has appeared, you will be presented with the following
opons:
• Lens
• Exposure
• White Balance
• Backlight
• D/N (Day/Night)
• DPC
• Special
Up
Le
Down
Right
Menu/
conrm
XC960T
HD 960H
7
www.xvision.com
4.1 Lens Opon: DC / Manual
Select the lens type from either DC or Manual. Use the joysck to navigate between the opons and
when on the desired opon, press the joysck in to select. Both opons have a sub-menu as follows:
DC: Brightness - adjust the brightness of the image between
0-255. Iris Speed - adjust the iris speed between 0-255.
Manual: Brightness - adjust the brightness of the image
between 0-255.
Return: Save / End and return to the previous menu.
4.2 Exposure Opon: Shuer / AGC / DWDR
The exposure menu allows you to adjust the shuer speed, Automac Gain Control (AGC) and the Digital
Wide Dynamic Range (DWDR) on the camera.
Shuer: Adjust the shuer speed to auto or choose from
the following shuer speeds (1/25, FLK, 1/50, 1/100, 1/2000,
1/5000, 1/10000).
AGC: Adjust the AGC to either Auto, Low, Middle or High.
DWDR: Turn the DWDR on or o. If you choose to turn it on,
you can adjust the sensivity level (0-63).
Return: Save / End and return to the previous menu.
4.3 White Balance Opon: AWB / ATW / An CRL / Manual
Adjust the White Balance and set the Automac White Balance (AWB), ATW, An Colour Rolling (An CRL)
and choose to set the white balance manually.
AWB: Set the white balance to Automac
ATW: Turns this funcon on so the camera will detect
the colour temperature automacally.
An CRL: Turn on the an colour rolling funcon
Manual: Set the white balance to manual. If this opon is
chosen, you will need to adjust the colour temperature.
To do this, adjust the colour temperature from Manual, Indoor
or Outdoor. In each of these opons you will need to
set the blue and red gain.
Return: Save / End and return to the previous menu.
XC960T
HD 960H
8
www.xvision.com
4.5 Day/Night Opon: D&N Auto / B&W / EXT / Colour
Day/Night: Set the camera to Day/Night mode. When selected, you can set the Day/Night mode to Auto,
Black and White, EXT or Colour.
D/N Auto: When choosing Auto you can adjust the lux
level from which the camera will switch from day to
night mode (0-255) and the delay from when the
camera reaches that lux level to turn to night mode
(0-30). You can also do this from night to day.
B/W: When choosing B/W you will put the cameras
image to black and white. You can also choose to turn
on the burst funcon, turn on the IR Smart and set
the IR level.
EXT: Choose the EXT funcon to set the day to night
funcon to be decided by external signals, for example
IR LEDs. Set the delay to (0-30 seconds) and night to
day funcon delay (0-30 secs).
Colour: Set the camera’s image to colour.
Return: Save / End and return to the previous menu.
4.4 Backlight Opon: O / BLC / HLC
This opon allows you adjust the advance backlight sengs, giving the following opons; Backlight
Compensaon (BLC), Highlight Compensaon (HLC), Day/Night, Black & White mode, EXT and Colour
Mode.
BLC: Select this opon to allow objects in front of
bright lights to be seen clearer, by making the background
darker. Once selected, you will be presented with a
further 2 opons; area select and state. Select the area gain
control (30-255), Height, Width (both 0-13), Le/Right
and Top/Boom (Both 0-5). You can also turn the state
on or o.
HLC: Select this opon to mask bright areas in an image,
for example, car headlights. Once selected, you can set the
sensivity level (0-240), set HLC to All Day or Mask Skip.
If you select Mask Skip, you can set the height, width,
le/right and top/boom of the masked areas between
0-15 values.
XC960T
HD 960H
9
www.xvision.com
4.6 DPC Opon: Start / DPC View / LS Value / Di / Area
Start: Once selected, you will be asked to cover the lens
and press the joysck in. Please note that this is for
factory use only, if iniated power the camera down
and then power the camera to back up.
DPC View: Turn the DPC View on or o.
LS Value: Set the shuer value for searching dead pixels
Di: Set the di. value for searching dead pixels
Area: Set the area of the DPC. There are areas to
adjust; HS, HE, VS and VE (0-255).
Return: Save / End and return to the previous menu.
4.7 Special Opon: Camera Title / Moon / Privacy / Park Line / Image Adjust
Cam Adjust / Display ID / Language / Version
The special opon allows you to adjust various sengs on the camera from camera tle, privacy masking,
moon detecon and language etc.
Camera Title: Turn the camera tle on or o. When choosing on,
you will be presented with an on screen keyboard to set the
camera tle. Move the joysck to navigate between the
leers/numbers and then press the joysck in to conrm
selecon.
Moon: Turn the moon detecon funcon on or o.
If set to on, you will be presented with the following opons:
Area Select: Select 1-4 areas
Area State: Turns the selected moon zone on or o
Height: 0-50
Width: 0-50
Top: 0-50
Boom: 0-50
Degree: 0-255
View: On or o
Privacy: Turn the privacy funcon on or o. If set to on, you
will be presented with the following opons:
Area Select: Select 1-8 areas
Area State: Turns the selected privacy zone on or o
Height: 0-255
Width: 0-255
Le/Right: 0-255
Top/Boom: 0-255
Colour: 0-15 - choose between 15 colour opons to show the masked areas.
XC960T
HD 960H
10
www.xvision.com
4.7 Special Connued...
Park Line: Turn the park line funcon on or o. This feature all the user to set on-screen parking lines
for vehicle use. If turned on, you will be presented with the following opons to adjust the parking lines’
posion and width:
LT: 0-255
LB: 0-255
RT: 0-255
RB: 0-255
F: 0-255
N: 0-255
T: 0-15
V1: 0-255
V2: 0-255
V3: 0-255
Image Adjust: The image adjust opons allows you to change various sengs to create the perfect image
for your needs. When entering the image adjust opon, you will be presented with the following
sub-menu.
Lense Shadow: Sets the amount of light available to the lense to provide clearer images. Turn this
funcon and you can alter the light level (0-255), H-centre (0-255) and V-centre (0-255).
2DNR: Turn on to acvate the Dynamic Noise Reducon funcon. When turned on, you can set
the level from 0-255.
Mirror: Provides a mirror reecon (horizontal) of the image. This funcon can be turned on or
o.
Font Colour: Change the font colour for the on-screen display. When turned on you can choose
between 15 colours and the ID/Title of the camera.
Contrast: Adjust the contrast colour (0-255)
Sharpness: Adjust the sharpness of the image (0-255)
Display: Choose the display from LCD, User, CRT or Neg Image. The LCD opon allows you to
adjust Gamma (0.3 - 1.0), Ped Level (0-63) and Colour Gain (0-255). The user opon allows you to
adjust the same opons as LCD and the CRT opon allows you to adjust Ped Level (0-63) and
Colour Gain (0-255).
Com Adjust: This feature is for RS485 sengs. Here you can adjust the baudrate (2400, 4800,
9600), Protocol (Pelco D, Pelco P) and the Cam ID (1-255).
Display ID: Turn the ID of the camera on or o. If set to on, you can choose the on screen posion
of the ID.
Language: Set the language on the camera.
Version: View the current rmware version on the camera.
Return: Save / End and return to the previous menu.
Exit: Exit the menu and go back to camera view. You will be asked to either exit without saving,save the
sengs or reset the camera back to the factory sengs.
Inhaltsverzeichnis
Andere X-Vision Sicherheitskamera Handbücher
X-Vision
X-Vision XC960S30 Bedienungsanleitung
X-Vision
X-Vision XSD35ZDN Bedienungsanleitung
X-Vision
X-Vision PCC427 Bedienungsanleitung
X-Vision
X-Vision XPD700WIR-2 Bedienungsanleitung
X-Vision
X-Vision XHC1080S10IRN Bedienungsanleitung
X-Vision
X-Vision XC960VV Bedienungsanleitung
X-Vision
X-Vision XPD621 Bedienungsanleitung
X-Vision
X-Vision Professional NPR Camera Einrichtungshandbuch
X-Vision
X-Vision VIS338DX-3 Bedienungsanleitung
X-Vision
X-Vision XIR621 Bedienungsanleitung
X-Vision
X-Vision XSD27ZS Bedienungsanleitung
X-Vision
X-Vision XSD27ZIR-2 Bedienungsanleitung
X-Vision
X-Vision XSD27ZIR-2 Bedienungsanleitung
X-Vision
X-Vision VIS249DX Bedienungsanleitung
X-Vision
X-Vision XPT600 Bedienungsanleitung
X-Vision
X-Vision XC960DA Bedienungsanleitung
X-Vision
X-Vision VIS430R Leitfaden
X-Vision
X-Vision XC960VA Bedienungsanleitung
X-Vision
X-Vision XC960BN Bedienungsanleitung
X-Vision
X-Vision XP1080S20 Bedienungsanleitung
