X-Vision XSD35ZDN Bedienungsanleitung

Model: XSD35ZDN

Colour 550 TVL 560x Zoom

Speed Dome Camera

CCTV

Model:

XSD35ZDN

Colour 550 TVL 560x Zoom

Speed Dome Camera

Before you begin

•Please unpack the box carefully and identify that all the parts are present.

•Do not cut the cables, this will void the warranty.

•Make sure you use only the recommended power supply.Damage caused to the unit by

incorrect voltage or wiring is not covered by the warranty.

USER MANUAL

Contents

1. Safety Precautions.................................................................................................... 2

2. Symbol Description.................................................................................................. 3

3. Features.................................................................................................................... 4

4. Contents................................................................................................................... 5

5. Component and Structure Description ................................................................... 6

6. Camera Setting........................................................................................................ 7

7. Camera Mounting Options ..................................................................................... 11

8. System Installation ..................................................................................................12

9. Operation ................................................................................................................ 13

10. MENU Operational Description............................................................................. 16

11. Quick Reference Table .......................................................................................... 18

12. Quick Reference Table............................................................................................ 19

13. Troubleshooting...................................................................................................... 20

14. Specifications ........................................................................................................ 21

The author assumes no responsibility for any errors or omissions that may appear in this

document nor does the author make a commitment to update the information herein.

WARNING: This symbol is intended to alert the user to the presence of un-insulated “

dangerous voltage”.

CAUTION: This symbol is intended to alert the user to presence of important operating

and maintenance (Servicing) instructions in the literature accompanying the appliance.

Disposal of Old Electrical & Electronic Equipment (Applicable in the European

Union and other European countries with separate collection systems).

This symbol on the product or on its packaging indicates that this product shall not be

treated as household waste. Instead it shall be handed over to the applicable collection

point for the recycling of electrical and electronic equipment. By ensuring this product is

disposed of correctly, you will help prevent potential negative consequences for the

environment and human health, which could otherwise be caused by inappropriate waste

handling of this product. The recycling of materials will help to conserve natural

resources. For more detailed information about recycling of this product, please contact

your local city office, your household waste disposal service or the shop where you

purchased the product.

Do not install the product in an environment where the humidity is high. Unless the product is

waterproof or weatherproof, otherwise poor image quality may occur.

Please take extreme care when cleaning the dome surface. The plastic material that the dome is

made of is,by necessity, relatively soft and prone to nicks and scratches which will impair vision

through the dome.

Do not plug and unplug the power cord, it may result product malfunction.

Make sure to use only the power source specified in the specification.

Before operation, please make sure that the product has been properly installed.

1. Safety Precautions

It is advised to read the Safety Precaution Guide through

carefully before operating the product, to prevent any

possible danger.

1. Keyboard function keys are shown by, framed BOLD CAPITAL letters.

Example: ENTER ,AUTO FOCUS , etc.

2. Function key “+” indicates the order sequence.

Example: 28+ ENTER meaning, press the function key “ 2“,

“ 8”, and then ENTER .

3. Indicate messages from the device and is shown on the control keyboard LCD

display.

4. “n” indicates the ID number of the nth device (ID numbers ranges from 001~127).

2. Symbol Description

DEVICE 001:_

lSpeedy response with 35x continuous

auto-focus zoom lens and 16x Electronic

Zoom.

lDay & Night (IR Cut Filter Change

Mechanism).

lAuto Iris and Manual Iris Control.

lAdvanced DSP Camera, including Auto White

Balance, Backlight Compensation and Auto

Iris Control.

l360° Continuous Pan Rotation.

l80 Preset Points Setup.

lAuto pan at preset point.

lPan Speed up to 300°/Sec and Tilt Speed up

to 200°/Sec.

lHorizontal Rotation of 180°.

lBuilt in 6 Alarm Inputs and one Relay

Output.

lTwo types of Alarm out signal are provided:

NO and NC.

lRemote Control via RS-485.

lConnects up to 127 Speed Dome Cameras.

lSupports PELCO Protocol (D and P Protocol).

lPC control software is applicable.

lAC24V or DC12V Power Input.

lBuilt-in heater device and fan to maintain

camera in normal operating temperature.

lInstallation Option: Wall Mount/ Pendant

Mount/ Corner Mount

lWeatherproof to IP66.

3. Features

DC12V TYPE

1. DC Adaptor (x1)

2. Power Line (x1)

3. Power Connector (x1)

4. Speed Dome (x1)

5. Speed Dome Cover (x1)

4. Contents

1. Wall Mount Bracket/ Ceiling Mount Bracket/ Corner Mount Bracket

2. Machine Housing

3. Transparent Cover

4. ID Number/ Protocol/ Baud Rate Setting

5. Alarm Input or Output / Video Output / Power Input Terminal

5. Component and Structure Description

Wall Mount

Ceiling Mount

Corner Mount

SW1: ID Number Setting

Connection of up to 127 Speed Dome

Cameras, each camera has its own ID

Number.

Setting 000, then the image display will show: DEVICE N/A.

Does not affect setup.

DIP Switch setting, shown below:

6. Camera Setting

Settings

Switch Number

1 2 3 4

Off Off Off Off

On Off Off Off

Off On Off Off

On On Off Off

Baud Rate

9600 BPS

4800 BPS

2400 BPS

19200 BPS

*BOLD: Default Settings

SW2: Protocol Settings

SW2: Baud Rate Settings

Settings

Switch Number

5 6 7 8

Off Off Off Off

On Off Off Off

Off On Off Off

On On Off Off

Protocol

NATIVE

PELCO

Reserved

* Speed Dome automatically detects the type of PELCO Protocol. No switch settings are

required to set D and P Protocols.

* BOLD: Default Settings.

Terminal base Connection, Data Line, and Signal Line Regulation

1. Power Input Terminal

DC 12V Input and power consumption of 2.5A.

AC 24V Input and power consumption of 2.2A.

Video Output Terminal

Video Signal Output: CVBS 1.0 Vp-p 75 Ohms BNC.

2. Alarm Input/ Output Terminal

Each Speed Dome camera is equipped with 6 external alarm inputs and 2 sets of alarm outputs

(1 set NO and 1 set NC). Alarm Input voltage: 5.6V max and Alarm Output Specification: 0.35A

120V AC/ 0.5A 24V AC.

3. Communication Control Input/ Output Terminal

RS-485 Input Terminal has two terminal points (D+, D-), using the twisted pair wire to connect

onto the next Speed Dome Camera.

10pin Green Terminal Block

SENSOR/RELAY

PIN No. Definition

1 GND

2 Sensor 1

3 Sensor 2

4Sensor 3

5 Sensor 4

6 Sensor 5

7 Sensor 6

8 NO

9COM

10 NC

4pin Green Terminal Block

RS485 CONNECTOR

PIN No. Definition

1 D-

2 D-

3 D+

4 D+

2pin Green Terminal Power-Input

PIN No. Definition

1 AC24V

2 GND

2pin Green Terminal Power-Input

PIN No. Definition

1 DC12V

2 GND
