X-Vision XC960VA Bedienungsanleitung

Professional HD 960H Vandal Resisant

Discreet Dome Camera

User Manual

Version 1

Thank you purchasing the XC960VA camera from Xvision.

Please ensure that you read and understand this User Guide before operating the camera.

Please store this User Guide in an easily accessible location.

HD 960H

XC960VA

HD 960H

www.xvision.com

Contents

1. Product Overview .................................................................................. 3

1.2 Package Contents .......................................................................... 3

2. Installaon ............................................................................................ 4

3. How to Operate the Camera .................................................................. 5

4. Camera Menu ........................................................................................ 5

4.1 Lens ............................................................................................... 6

4.2 Exposure ....................................................................................... 6

4.3 White Balance ............................................................................... 6

4.4 Backlight ........................................................................................ 6

4.5 Day/Night ...................................................................................... 7

4.6 DPC ................................................................................................ 7

4.7 Special ........................................................................................... 7

5. Specicaons ........................................................................................ 9

XC960VA

HD 960H

www.xvision.com

Safety Precauons

1. Do not install the equipment in an environment with too much moisture, dust or smoke dust as this

may result in re or electric shock.

2. In the unlikely event that the equipment should malfuncon and emit an abnormal smell or smoke,

please immediately stop it, shut o the power and contact your supplier.

3. Please do not place this equipment near a heat source to avoid risk of re.

4. Please do not store, install and use this product in danger areas with inammable or explosive

substances.

5. Please make sure the power is turned o when installing the product.

6. Please ensure that you install the camera in an area with good venlaon.

7. When installing the camera, please make sure that it does not face any objects giving out strong lights

as this will damage the CCD of the camera.

8. Please do not use the camera in an environment where temperatures exceed either -20°C to +55°C.

XC960VA

HD 960H

www.xvision.com

Thank you for purchasing the HD 960H XC960VA from Xvision. Please read through this manual carefully

and make sure you understand before operang the camera.

1.1 Features

• Up to 30m Smart IR Night Vision

• Sony 960H CCD Sensor

• Xvision X3K DSP

• Xvision 2.8 to 12mm HD Megapixel Auto Iris Lens for a Viewing Angle between 23 and 92°

• Advanced Wide Dynamic Range

• High Speed Digital Slow Shuer

• 3D Digital Noise Reducon

• Programmable High Light Suppression

• Up to 6m Number Plate Recognion

• Designed for Wall or Ceiling Mount

• Vandal Resistant

• Waterproof to IP66

1.2 Package Contents

The packaged box for the XC960VA comes with the following items:

• XC960VA Camera

• Screws

• Allen Key

• Mini at head screw driver

• DC Plug with screw terminals

• Ceiling mount stencil

• User Manual

Should any of these items be missing, please contact your local distributor.

1. Product Overview

XC960VA

HD 960H

www.xvision.com

1. Product Overview

2. Installaon

The XC960VA camera can be wall or ceiling mounted. To install the camera on the ceiling or wall, please

follow the steps below.

3. Next, remove the base from the camera by

unscrewing away from the main part of the

camera. You will need a cross head scew driver to

do this.

1. Use the stencil to drill holes for the camera to be

mounted.

4. Then, place the screws through the holes in the

base of the camera and screw in.

2. Make sure you use the correct drill bit for the

wall/ceiling drilling into. Then when drilled, insert

wall plugs.

5. Now, screw the main camera bracket back on to

the camera base.

6. Adjust the the angle of the lens to gain the

desired view.

7. Lastly, screw the dome cover back onto the

camera using the allen key.

6. You can adjust the angle 180° in any direcons

using the magnec base (below).

XC960VA

HD 960H

www.xvision.com

1. Product Overview

3. How to Operate the Camera

To operate the camera, rstly you will need to connect the BNC and DC sockets to the BNC and DC sockets

of a PNP cable (20, 40, 80 or 120 metres available from www.y3k.com).

You can then connect the DC socket to a 12V DC Power Supply and the BNC socket to back of your

compable DVR or monitor.

BNC Socket for

video

DC Socket for

power

1. Product Overview

4. Camera Menu

To access the camera menu, rstly unscrew the cover using the allen keys. This will expose the joysck on

the camera lens houseing. Turn the camera on and then press the joysck buon. When the menu has

appeared, you will be presented with the following opons:

• Lens

• Exposure

• White Balance

• Backlight

• D/N (Day/Night)

• DPC

• Special

Le

Down

Right

XC960VA

HD 960H

www.xvision.com

4.1 Lens Opon: DC / Manual

Select the lens type from either DC or Manual. Use the joysck to navigate between the opons and

when on the desired opon, press the joysck in to select. Both opons have a sub-menu as follows:

DC: Brightness - adjust the brightness of the image between

0-255. Iris Speed - adjust the iris speed between 0-255.

Manual: Brightness - adjust the brightness of the image

between 0-255.

Return: Save / End and return to the previous menu.

4.2 Exposure Opon: Shuer / AGC / DWDR

The exposure menu allows you to adjust the shuer speed, Automac Gain Control (AGC) and the Digital

Wide Dynamic Range (DWDR) on the camera.

Shuer: Adjust the shuer speed to auto or choose from

the following shuer speeds (1/25, FLK, 1/50, 1/100, 1/2000,

1/5000, 1/10000).

AGC: Adjust the AGC to either Auto, Low, Middle or High.

DWDR: Turn the DWDR on or o. If you choose to turn it on,

you can adjust the sensivity level (0-63).

Return: Save / End and return to the previous menu.

4.3 White Balance Opon: AWB / ATW / An CRL / Manual

Adjust the White Balance and set the Automac White Balance (AWB), ATW, An Colour Rolling (An CRL)

and choose to set the white balance manually.

AWB: Set the white balance to Automac

ATW: Turns this funcon on so the camera will detect

the colour temperature automacally.

An CRL: Turn on the an colour rolling funcon

Manual: Set the white balance to manual. If this opon is

chosen, you will need to adjust the colour temperature.

To do this, adjust the colour temperature from Manual, Indoor

or Outdoor. In each of these opons you will need to

set the blue and red gain.

Return: Save / End and return to the previous menu.

XC960VA

HD 960H

www.xvision.com

4.5 Day/Night Opon: D&N Auto / B&W / EXT / Colour

Day/Night: Set the camera to Day/Night mode. When selected, you can set the Day/Night mode to Auto,

Black and White, EXT or Colour.

D/N Auto: When choosing Auto you can adjust the lux

level from which the camera will switch from day to

night mode (0-255) and the delay from when the

camera reaches that lux level to turn to night mode

(0-30). You can also do this from night to day.

B/W: When choosing B/W you will put the cameras

image to black and white. You can also choose to turn

on the burst funcon, turn on the IR Smart and set

the IR level.

EXT: Choose the EXT funcon to set the day to night

funcon to be decided by external signals, for example

IR LEDs. Set the delay to (0-30 seconds) and night to

day funcon delay (0-30 secs).

Colour: Set the camera’s image to colour.

Return: Save / End and return to the previous menu.

4.4 Backlight Opon: O / BLC / HLC

This opon allows you adjust the advance backlight sengs, giving the following opons; Backlight

Compensaon (BLC), Highlight Compensaon (HLC), Day/Night, Black & White mode, EXT and Colour

Mode.

BLC: Select this opon to allow objects in front of

bright lights to be seen clearer, by making the background

darker. Once selected, you will be presented with a

further 2 opons; area select and state. Select the area gain

control (30-255), Height, Width (both 0-13), Le/Right

and Top/Boom (Both 0-5). You can also turn the state

on or o.

HLC: Select this opon to mask bright areas in an image,

for example, car headlights. Once selected, you can set the

sensivity level (0-240), set HLC to All Day or Mask Skip.

If you select Mask Skip, you can set the height, width,

le/right and top/boom of the masked areas between

0-15 values.

XC960VA

HD 960H

www.xvision.com

4.6 DPC Opon: Start / DPC View / LS Value / Di / Area

Start: Once selected, you will be asked to cover the lens

and press the joysck in. Please note that this is for

factory use only, if iniated power the camera down

and then power the camera to back up.

DPC View: Turn the DPC View on or o.

LS Value: Set the shuer value for searching dead pixels

Di: Set the di. value for searching dead pixels

Area: Set the area of the DPC. There are areas to

adjust; HS, HE, VS and VE (0-255).

Return: Save / End and return to the previous menu.

4.7 Special Opon: Camera Title / Moon / Privacy / Park Line / Image Adjust

Cam Adjust / Display ID / Language / Version

The special opon allows you to adjust various sengs on the camera from camera tle, privacy masking,

moon detecon and language etc.

Camera Title: Turn the camera tle on or o. When choosing on,

you will be presented with an on screen keyboard to set the

camera tle. Move the joysck to navigate between the

leers/numbers and then press the joysck in to conrm

selecon.

Moon: Turn the moon detecon funcon on or o.

If set to on, you will be presented with the following opons:

Area Select: Select 1-4 areas

Area State: Turns the selected moon zone on or o

Height: 0-50

Width: 0-50

Top: 0-50

Boom: 0-50

Degree: 0-255

View: On or o

Privacy: Turn the privacy funcon on or o. If set to on, you

will be presented with the following opons:

Area Select: Select 1-8 areas

Area State: Turns the selected privacy zone on or o

Height: 0-255

Width: 0-255

Le/Right: 0-255

Top/Boom: 0-255

Colour: 0-15 - choose between 15 colour opons to show the masked areas.

XC960VA

HD 960H

www.xvision.com

4.7 Special Connued...

Park Line: Turn the park line funcon on or o. This feature all the user to set on-screen parking lines

for vehicle use. If turned on, you will be presented with the following opons to adjust the parking lines’

posion and width:

LT: 0-255

LB: 0-255

RT: 0-255

RB: 0-255

F: 0-255

N: 0-255

T: 0-15

V1: 0-255

V2: 0-255

V3: 0-255

Image Adjust: The image adjust opons allows you to change various sengs to create the perfect image

for your needs. When entering the image adjust opon, you will be presented with the following

sub-menu.

Lense Shadow: Sets the amount of light available to the lense to provide clearer images. Turn this

funcon and you can alter the light level (0-255), H-centre (0-255) and V-centre (0-255).

2DNR: Turn on to acvate the Dynamic Noise Reducon funcon. When turned on, you can set

the level from 0-255.

Mirror: Provides a mirror reecon (horizontal) of the image. This funcon can be turned on or

o.

Font Colour: Change the font colour for the on-screen display. When turned on you can choose

between 15 colours and the ID/Title of the camera.

Contrast: Adjust the contrast colour (0-255)

Sharpness: Adjust the sharpness of the image (0-255)

Display: Choose the display from LCD, User, CRT or Neg Image. The LCD opon allows you to

adjust Gamma (0.3 - 1.0), Ped Level (0-63) and Colour Gain (0-255). The user opon allows you to

adjust the same opons as LCD and the CRT opon allows you to adjust Ped Level (0-63) and

Colour Gain (0-255).

Com Adjust: This feature is for RS485 sengs. Here you can adjust the baudrate (2400, 4800,

9600), Protocol (Pelco D, Pelco P) and the Cam ID (1-255).

Display ID: Turn the ID of the camera on or o. If set to on, you can choose the on screen posion

of the ID.

Language: Set the language on the camera.

Version: View the current rmware version on the camera.

Return: Save / End and return to the previous menu.

Exit: Exit the menu and go back to camera view. You will be asked to either exit without saving,save the

sengs or reset the camera back to the factory sengs.

Inhaltsverzeichnis

Andere X-Vision Sicherheitskamera Handbücher

X-Vision

X-Vision VIS338D Bedienungsanleitung

X-Vision

X-Vision XPD700WIR-2 Bedienungsanleitung

X-Vision

X-Vision XIR621 Bedienungsanleitung

X-Vision

X-Vision XC960BN Bedienungsanleitung

X-Vision

X-Vision VIS249D Bedienungsanleitung

X-Vision

X-Vision VIS249D-2 Bedienungsanleitung

X-Vision

X-Vision HD 960H Bedienungsanleitung

X-Vision

X-Vision XSD27ZIR-2 Bedienungsanleitung

X-Vision

X-Vision XIR501 Bedienungsanleitung

X-Vision

X-Vision XC960DA Bedienungsanleitung

X-Vision

X-Vision XSD27ZDN Bedienungsanleitung

X-Vision

X-Vision XPD700W-2 Bedienungsanleitung

X-Vision

X-Vision VIS338DX-3 Bedienungsanleitung

X-Vision

X-Vision XSD27ZS Bedienungsanleitung

X-Vision

X-Vision XSD27ZIR Bedienungsanleitung

X-Vision

X-Vision XC960S30IRN Bedienungsanleitung

X-Vision

X-Vision PCC435 Bedienungsanleitung

X-Vision

X-Vision XSD27ZDN2 Bedienungsanleitung

X-Vision

X-Vision PCC422E Bedienungsanleitung

X-Vision

X-Vision XC960BA Bedienungsanleitung

X-Vision

X-Vision XSD27ZIR-2 Bedienungsanleitung

X-Vision

X-Vision XPS036 Bedienungsanleitung

X-Vision

X-Vision XSD27ZIR-2 Bedienungsanleitung

X-Vision

X-Vision XSD27ZIR-2 Bedienungsanleitung

Beliebte Sicherheitskamera Handbücher anderer Marken

Okina USA

Okina USA SIR36-870VF650LP Bedienungsanleitung

Divio

Divio NDR155PA Bedienungsanleitung

Canon

Canon VB-C500D Bedienungsanleitung

Easy Access

Easy Access EasyGuard Bedienungsanleitung

Vivotek

Vivotek FD9389-EHV-v2 Bedienungsanleitung

TUYA

TUYA COSMO W2 Bedienungsanleitung

Eusso

Eusso UNC7500-IR Einrichtungshandbuch

urmet domus

urmet domus 1096/204 Bedienungsanleitung

VC VC20 series Bedienungsanleitung

Axis

Axis Q1614 Bedienungsanleitung

ieGeek

ieGeek DD201 Bedienungsanleitung

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Bedienungsanleitung

Vicon

Vicon V662-D-1 Betriebsanleitung

Grundig

Grundig GCH-K0274P Bedienungsanleitung

Lorex

Lorex VANTAGE LBC7032 Bedienungsanleitung

4xem

4xem WPT Bedienungsanleitung

Samsung

Samsung SCV-3082 Bedienungsanleitung

Vitek

Vitek VTC-C544 Bedienungsanleitung
